Tripp Lite PV600 Manuale utente

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: PV600

PowerVerter Ultra-Compact Inverter - Portable Power for All Applications

Highlights

600 watt continuous output; 1200 watt peak output (instantaneous)

Converts 12V DC (battery) power into 110-120V AC (household) power; 3 AC outlets

Installs in minutes (includes integrated mounting feet)

Provides a quiet alternative to generator noise and fumes

Includes "battery saver" low voltage alarm/shutdown

Description

Harness your vehicle's battery to efficiently power appliances, small electronics and office equipment on the road. Continuously supplies up to 600

watts of 120V AC power to 3 AC outlets from any 12V battery. Ultra-compact, lightweight metal case design is among the smallest, most rugged

inverters available.

Applications

Ideal for portable electronics, office equipment, RV and mobile appliances, video game and small entertainment systems, battery chargers

and more

Package Includes

PV600 Ultra-Compact DC-to-AC Inverter

Instruction manual

Features

Provides 120V AC power for a variety of mobile applications

600 watts continuous output power and 1200 watts peak output power (instantaneous)

3 AC outlets

Ultra-compact, extruded aluminum casing stands up to the toughest environments

Cooling fan lengthens inverter service life

Integrated mounting feet provide safe, fixed installation

Low battery alarm/shutdown detects low voltage and shuts down inverter

Overload alarm/shutdown detects wattage overload on inverter outlets and shuts down inverter as a protective measure

DC input terminals assure solid connection to battery with user-supplied cables

Lighted on/off switch shows inverter operations in cramped or dark environments

Specifications

OUTPUT

Frequency

compatibility

60 Hz

Output watts 600W (continuous)/1200W (peak)

Output nominal

voltage

120V

Output voltage

regulation

Maintains PWM sine wave output voltage of 115 V AC (+/- 8 V AC)

Output frequency

regulation

60 Hz (+/- 3 Hz)

Overload protection Via set of 2 40A automotive input fuses

Outlet quantity / type 3 NEMA 5-15R

INPUT

Recommended

Electrical Service

Requires 12V DC input source capable of delivering 64A for the required duration (when used at full capacity). For

automotive applications, professional hardwire installation with 80A battery system fusing is recommended.

Maximum input amps

/ watts

Full continuous load - 64A at 12V DC, No load - 0.95A at 12V DC, Shutdown - 150 microamps

Input connection type Set of 2 DC bolt-down wiring terminals

Input cord length

details

User supplies cabling. Minimum gauges for full load operation: 8 (6 ft max), Two 10 (8 ft max), 6 (10 ft max), 4 (15 ft

max).

Voltage compatibility

(VDC)

BATTERY

DC system voltage

(VDC)

LEDS ALARMS & SWITCHES

Alarms Dual function alarm indicates overload conditions or low DC input voltage of 10.5V or less.

Switches Lighted on/off power switch

PHYSICAL

Shipping Dimensions

(HWD/in)

4 x 6.5 x 10.25

Shipping Dimensions

(HWD/cm)

10.2 x 16.5 x 26

Shipping weight (lbs) 3

Shipping weight (kg) 1.4

Unit Dimensions

(HWD/in)

2.75 x 5 x 8.25

Unit Dimensions

(HWD/cm)

7 x 12.7 x 21

Unit weight (lbs) 2.5

Unit weight (kg) 1.1

Cooling method Fan

Material of

construction

Aluminum / sheet metal

ENVIRONMENTAL

Relative Humidity 0-95% non-condensing

SPECIAL FEATURES

Appearance Attractive, rugged, metallic gray color inverter system

WARRANTY

Product Warranty

Period (Worldwide)

1-year limited warranty

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=2651.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
