Tripp Lite PDU1420T Manuale utente

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: PDU1420T

Single-Phase Basic PDU, 20A 120V, 0U Vertical Rackmount, NEMA 5-15/20R outlets, NEMA L5-20P input plug

Highlights

Basic single phase 20A 120V PDU

0U vertical rackmount installation

NEMA L5-20P locking input; 15 ft. / 4.5m line cord

14 NEMA 5-15/20R outlets

24 in. / 61cm height

Description

Tripp Lite Basic Power Distribution Units / PDU systems offer reliable rackmount power distribution. Supplies equipment with continuous power from

any protected UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation

with included mounting accessories.

Applications

Multi-outlet power distribution unit is the ideal means of powering multiple loads in racks, wallmount and other applications, such as

internetworking, PC systems, telecommunications, audio/video, security, sound reinforcement and more. Ideal for distribution of UPS,

generator or commercially derived AC power to protected equipment.

Package Includes

PDU1420T power strip

Instruction manual with warranty information

Features

20A single phase 120V Basic Power Distribution Unit / PDU

Attached NEMA L5-20P 20A 120V input plug with 15 ft. / 4.5m line cord

0U, 24 in. / 61cm vertical form factor supports installation in 2 or 4 post equipment racks

Toolless mounting supported in button-mount compatible racks, plus nut-and-bolt mounting brackets for other mounting applications

Specifications

OVERVIEW

Model Type Basic

PDU Type Basic

OUTPUT

Frequency compatibility 50 / 60 Hz

Output watts 2400

Output nominal voltage 120V

Overload protection 20A

Outlet quantity / type 14 NEMA 5-15/20R

Outlet Type NEMA 5-15R, NEMA 5-20R

INPUT

PDU Input Voltage 100; 120; 127

Maximum Input Amps (A) 20

PDU Plug Type NEMA L5-20P

Input cord length (ft.) 15

Input cord length (m) 4.57

Voltage compatibility (VAC) 120

Phase Single-Phase

LEDS ALARMS & SWITCHES

Switches No switch

PHYSICAL

Shipping weight (lbs) 6.2

Shipping weight (kg) 2.8

Unit Dimensions (HWD/in) 1.75 x 25.75 x 2.25

Unit Dimensions (HWD/cm) 4.45 x 65.4 x 5.7

Shipping Dimensions

(HWD/in)

2.75 x 27.25 x 8.25

Shipping Dimensions

(HWD/cm)

7 x 69.2 x 21

Unit weight (lbs) 5.6

Unit weight (kg) 2.5

Material of construction Steel

Style Rackmount, Vertical Rackmount, Wallmount/Under-Counter

Form factors supported Vertical or horizontal mounting supported in wallmount applications, racks and a variety of other surface

types

PDU Form Factor Vertical (0U)

CERTIFICATIONS

Certifications Tested to UL60950-1 (USA) and CAN/CSA C22.2 No. 60950-1-03 (Canada)

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

Power Cables P007-002 2-ft. Heavy-Duty 14AWG Power cord

(IEC-320-C13 to NEMA 5-15P)

Power Cables P007-006 6-ft. Heavy-Duty 14AWG Power cord

(IEC-320-C13 to NEMA 5-15P)

Power Cables P007-010 10-ft. Heavy-Duty 14AWG Power cord

(IEC-320-C13 to NEMA 5-15P)

Power Cables P010-012 12-ft. 18AWG Power cord

(NEMA 5-15P to IEC-320-C13)

Power Cables P012-006 6-ft. Notebook Power cord

(NEMA 1-15P to IEC-320-C7)

Power Cables P022-001 1-ft. 18AWG Power Extension cord

(NEMA 5-15R to NEMA 5-15P)

Power Cables P023-001 1-ft. 14AWG Power Adapter cord

(NEMA L5-15R to NEMA 5-15P)

Power Cables P034-010 10-ft. 14AWG Heavy Duty Power cord

( IEC-320-C19 to NEMA 5-15P)

Power Cables P043-002 2-ft. 10AWG Heavy Duty Power Cord with 20 AMP Breaker, (NEMA

L5-30P to NEMA L5-20R)

Power Cables P044-06I 6-inch 12AWG Heavy Duty Power Adapter cord

(NEMA-L5-20R to NEMA-5-20P)

Power Cables P049-010 10-ft. 12AWG Heavy Duty Power cord

(IEC-320-C19 to NEMA 5-20P)

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=2951.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
