Tripp Lite PDUMH30HV Manuale utente
Single Phase Metered PDU, 5/5.8kW 30A 208/240V,
2U Horizontal Rackmount, 16 C13 and 2 C19 outlets,
L6-30P input plug
MODEL NUMBER: PDUMH30HV
Description
Tripp Lite single phase Metered PDU / Power Distribution Units offer real-time local reporting of load level in
amps via built-in digital current metering. Enables visual monitoring of PDU output current to preserve proper
output balance and prevent circuit overloads as additional equipment is added. Offers reliable rackmount multi-outlet power distribution from any protected
UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting
accessories.
Features
30A single phase 208/240V Metered Power Distribution Unit / PDU (Agency derated to 24A continuous)
Set of two lighted meters report PDU output current in amps for each 9 outlet load bank
Attached NEMA L6-30P 30A 208/240V input plug and 12ft / 3.6m cord
2U horizontal rackmount format installs in two rack spaces
18 output receptacles (16 C13, 2 C19)
Outlets are arranged in two 9 outlet load banks, each with separate 20A breaker and current metering
Mounting flanges support installation in 2 and 4 post racks, with additional support for wall-mount and under-counter installation formats
Cord retention brackets keep vital equipment plugs connected
Grounding lug
TAA Compliant Version Available - Order Tripp Lite PDUMH30HVTAA
Specifications
OVERVIEW
PDU Type Metered
Highlights
Metered single phase 30A
208/240V 2U horizontal
rackmount PDU
Two built-in meters report output
current in amps for each load
bank
Attached 12ft / 3.6m cord with
NEMA L6-30P input plug
18 total outlets (16 C13, 2 C19)
Reversible housing, 2U 208/240V
rackmount metered PDU
Applications
Ideal for network configurations
requiring a metered PDU
Package Includes
2U rack PDU
Mounting brackets
Plug retention plates
User manual
1 / 4
OUTPUT
Output Capacity Details 5kW (208V input), 5.8kW (240V input), 4.8kW (200V input); 30A maximum (agency de-rated to 24A continuous)
Frequency compatibility 50 / 60 Hz
Output nominal voltage 200-240V nominal, single phase
Overload protection Outlets are arranged in two 9 outlet load banks; each load bank is protected by a separate 20A circuit breaker
Outlet quantity / type 16 C13 and 2 C19 outlets
Outlet Type IEC-C13, IEC-C19
INPUT
PDU Input Voltage 200; 208; 240
Maximum Input Amps (A) 30
Maximum Input Amps (A) Details Agency de-rated to 24A continuous
PDU Plug Type NEMA L6-30P
Input cord length (ft.) 12
Input cord length (m) 3.65
Phase Single-Phase
LEDS ALARMS & SWITCHES
Switches n/a
PHYSICAL
Shipping Dimensions (HWD/in) 8 x 20.5 x 17
Shipping Dimensions (HWD/cm) 20.3 x 52.1 x 43.2
Shipping weight (lbs) 16.9
Shipping weight (kg) 7.7
Unit Dimensions (HWD/in) 3.5 x 17.5 x 12.5
Unit Dimensions (HWD/cm) 8.8 x 44.4 x 31.8
Unit weight (lbs) 13.7
Unit weight (kg) 6.2
Material of construction Steel
Style Rackmount
Form factors supported 2U rackmount; mounting accessories included
PDU Form Factor Horizontal (1U, 2U, etc)
ENVIRONMENTAL
2 / 4
Relative Humidity 0-95% non-condensing
CERTIFICATIONS
TAA Compliant Option TAA Compliant Version Available - Order Tripp Lite PDUMH30HVTAA
Certifications Tested to UL 60950-1 (USA, Canada), Class A (Emissions), NOM (Mexico), RoHS compliant
WARRANTY
Product Warranty Period (Worldwide) 2-year limited warranty
Related Items
Optional Products
Model Number Description Qty.
P004-002-13LA AC Power Extension Cable - C13 Left Angle to C14 - 2' 1
P004-002-13RA AC Power Extension Cable - C13 Right Angle to C14 - 2 ft. 1
P036-002-20LA 2-ft. 12AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C20 Left Angle) 1
P036-002-20RA 2-ft. 12AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C20 Right Angle) 1
P005-12N 1-ft. (12 in.) Heavy-Duty 14AWG Power Cord (IEC-320-C13 to IEC-320-C14) 1
P005-18N 1.5-ft. (18 in.) Heavy-Duty 14AWG Power Cord (IEC-320-C13 to IEC-320-C14) 1
P005-002 2-ft. Heavy-Duty 14AWG Power cord ( IEC-320-C13 to IEC-320-C14) 1
P004-002-5 5-Pack of 2-ft. 18AWG Power cord (IEC-320-C14 to IEC-320-C13) 1
P004-004 4-ft. 18AWG Power cord (IEC-320-C14 to IEC-320-C13) 1
P004-004-BL 4-ft. 18 AWG Power Cord (IEC-320-C14 to IEC-320-C13) with Blue Connectors 1
P004-004-GN 4-ft. 18 AWG Power Cord (IEC-320-C14 to IEC-320-C13) with Green Connectors 1
P004-004-RD 4-ft. 18 AWG Power Cord (IEC-320-C14 to IEC-320-C13) with Red Connectors 1
P004-004-YW 4-ft. 18 AWG Power Cord (IEC-320-C14 to IEC-320-C13) with Yellow Connectors 1
P004-006 6-ft. 18AWG Power cord (IEC-320-C14 to IEC-320-C13) 1
P004-006-2C13 6-ft. AC Power Extension Splitter Cable ( C14 to 2 x C13 ) 1
P005-006 6-ft. Heavy-Duty 14AWG Power cord (IEC-320-C13 to IEC-320-C14) 1
P005-006-BL 6-ft. Heavy-Duty 14AWG Power cord (IEC-320-C13 to IEC-320-C14) Blue Connectors 1
P005-006-GN 6-ft. Heavy-Duty 14AWG Power cord (IEC-320-C13 to IEC-320-C14) Green Connectors 1
P005-006-RD 6-ft. Heavy-Duty 14AWG Power Cord (IEC-320-C13 to IEC-320-C14) with Red Connectors 1
P005-006-YW 6-ft. Heavy-Duty 14AWG Power cord (IEC-320-C13 to IEC-320-C14) Yellow Connectors 1
P004-010 10-ft. 18AWG Power cord (IEC-320-C14 to IEC-320-C13) 1
P005-010 10-ft. Heavy-Duty 14AWG Power cord (IEC-320-C13 to IEC-320-C14) 1
3 / 4
P047-002 2-ft. 14AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C14) 1
P047-004 4-ft. 14AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C14) 1
P047-006 6-ft. 14AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C14) 1
P047-010 10-ft. 14AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C14) 1
P036-002 2-ft. 12AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C20) 1
P036-006 6-ft. 12AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C20) 1
P036-006-2C19 6-ft. AC Power Splitter Cable ( C20 to 2 x C19 ) 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at:
http://www.tripplite.com/sku/PDUMH30HV.
© 2014 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice. Photos may differ slightly from final products.
