Tripp Lite PDUMV40 Manuale utente
Single-Phase Metered PDU, 3.8kW 20A 120V two
independent circuits, 0U vertical mount, 32 NEMA
5-15/20R outlets two L5-20P / 5-20P inputs
MODEL NUMBER: PDUMV40
Description
The PDUMV40 provides an efficient and manageable power distribution solution for multiple servers with dual
redundant power supplies, or any other application that requires numerous outlets, high capacity, and a compact
form factor. Dual input current monitoring display shows AC power consumption for each independent circuit.
Switchless design eliminates accidental shutoff of connected equipment. Unfiltered electrical pass-through
without a power switch makes the PDUMV40 ideal for distributing alternate waveform UPS or generator power in
rack enclosures, network closets, and more. Each of two independent circuits' supports 16 outlets and
equipment loads up to 2,400 watts32 outlets and 4,800 watts total capacity without consuming additional rack
space.
Features
All-in-one Zero U form factor enables efficient, single-enclosure installations
Dual independent circuit design delivers high capacity across 32 outlets in minimal space
Input plugs, input power cords, breakers and outlets are color-coded to match each independent 20A circuit,
allowing simplified cable management for multi-server configurations (each circuit is Agency de-rated to 16A
continuous)
Dual digital current monitoring displays (1 for each circuit)
10 ft. dual input power cords increase mounting flexibility; mounting hardware included
Combines the advantages of two separate high-current PDU's without the extra expense, increased space requirements and added management
complexity
Includes two adapters that convert NEMA L5-20P input plugs to NEMA 5-20P. Twist-lock interface ensures secure connection
Switchless design prevents accidental shutdown of connected equipment
Toolless mounting supported in button-mount compatible racks, plus nut-and-bolt mounting brackets for other mounting applications
Specifications
Highlights
Dual Circuit 71 inch PDU
Dual Independent Current
Monitoring Displays
32 NEMA 5-15/20R 120V outlets
color coded for each circuit
Two 20A independent circuits of
16 outlets each
Color-coded input power cords
for each circuit
Supports connection to NEMA
L5-20R or 5-20R 120V 20A wall
receptacle
Applications
Ideal means of powering servers
and networking equipment with
dual redundant power supplies
and other applications requiring
numerous outlets, high capacity
and a compact form factor. Ideal
distribution of alternate and
sinewave UPS and generator
power or commercially derived
AC power to connected
equipment.
Package Includes
PDUMV40 Dual Vertical
Circuit/Metered PDU
Mounting Hardware
Two NEMA L5-20P to 5-20P plug
adapters
Owner's Manual with warranty
information
1 / 4
OVERVIEW
PDU Type Metered
OUTPUT
Output Capacity Details
3.8kW total, 1.9kW per circuit (120V input); 4.0kW total, 2.0kW per circuit (127V input); 3.2kW total, 1.6kW per
circuit (100V input), 40A maximum total, 20A maximum per circuit (Agency de-rated to 32A continuous total, 16A
continuous per circuit)
Frequency compatibility 50 / 60 Hz
Output watts 4800
Output nominal voltage 100-127V nominal, single phase
Overload protection Two 20A breakers
Outlet quantity / type 32 NEMA 5-15/20R
Outlet Type NEMA 5-15R, NEMA 5-20R
INPUT
PDU Input Voltage 100; 120; 127
Maximum Input Amps (A) 40
Maximum Input Amps (A) Details Each circuit supports 20A maximum (Agency de-rated to 16A continuous)
PDU Plug Type NEMA 5-20P; NEMA L5-20P
Input cord length (ft.) 10
Input cord length (m) 3.05
Phase Single-Phase
LEDS ALARMS & SWITCHES
Switches Switchless design
Front panel LEDs Dual digital current monitoring displays (1 color-coded ammeter for each circuit)
PHYSICAL
Shipping Dimensions (HWD/in) 5 x 71.50 x 2.25
Shipping Dimensions (HWD/cm) 12.7 x 181.61 x 5.72
Shipping weight (lbs) 9.2
Shipping weight (kg) 4.17
Unit Dimensions (HWD/in) 3 x 71.25 x 1.5
Unit Dimensions (HWD/cm) 7.62 x 180.98 x 3.81
Unit weight (lbs) 8.2
Unit weight (kg) 3.72
2 / 4
Material of construction Aluminum
Style Vertical Rackmount, Wallmount, Raceway, Workbench
Form factors supported Zero U vertical rackmount, wall-mount, raceway, workbench and more
PDU Form Factor Vertical (0U)
SPECIAL FEATURES
Appearance Attractive black housing with color-coded circuit identification
CERTIFICATIONS
Certifications Tested to UL60950-1 (USA) and CAN/CSA C22.2 No. 60950-1-03 (Canada), RoHS Compliant
WARRANTY
Product Warranty Period (Worldwide) 2-year limited warranty
Related Items
Optional Products
Model Number Description Qty.
P006-006-13LA 6-ft. 18AWG Power cord (NEMA 5-15P to IEC-320-C13 Left Angle) 1
P006-006-13RA 6-ft. 18AWG Power cord (NEMA 5-15P to IEC-320-C13 Right Angle) 1
P007-002 2-ft. Heavy-Duty 14AWG Power cord
(IEC-320-C13 to NEMA 5-15P) 1
P030-002-5 5-Pack of 2-ft. 18AWG Power Cords NEMA 5-15P to IEC-320-C13) 1
P006-003 3-ft. 18AWG Power cord (NEMA 5-15P to IEC-320-C13) 1
P006-004 4-ft. 18AWG Power cord (NEMA 5-15P to IEC-320-C13) 1
P006-004-BL 4-ft. 18AWG Power Cord (NEMA 5-15P to IEC-320-C13) with Blue Connectors 1
P006-004-GN 4-ft. 18AWG Power Cord (NEMA 5-15P to IEC-320-C13) with Green Connectors 1
P006-004-RD 4-ft. 18AWG Power Cord (NEMA 5-15P to IEC-320-C13) with Red Connectors 1
P006-004-YW 4-ft. 18AWG Power Cord (NEMA 5-15P to IEC-320-C13) with Yellow Connectors 1
P006-006 6-ft. 18AWG Power cord (NEMA 5-15P to IEC-320-C13) 1
P007-006 6-ft. Heavy-Duty 14AWG Power cord
(IEC-320-C13 to NEMA 5-15P) 1
P006-006-2 6-ft. AC Power Splitter Cable (NEMA 5-15P to 2 x IEC-320-C13) 1
P006-006-515MF 6 ft. Piggyback Power Cord (NEMA 5-15P/R to IEC-320-C13 ) 1
P007-010 10-ft. Heavy-Duty 14AWG Power cord
(IEC-320-C13 to NEMA 5-15P) 1
P049-010 10-ft. 12AWG Heavy Duty Power cord
(IEC-320-C19 to NEMA 5-20P) 1
3 / 4
P006-010 10-ft. 18AWG Power cord ( NEMA 5-15P to IEC-320-C13) 1
P010-012 12-ft. 18AWG Power cord
(NEMA 5-15P to IEC-320-C13) 1
P043-002 2-ft. 10AWG Heavy Duty Power Cord with 20 AMP Breaker, (NEMA L5-30P to NEMA L5-20R) 1
P044-06I 6-inch 12AWG Heavy Duty Power Adapter cord (NEMA-L5-20R to NEMA-5-20P) 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at:
http://www.tripplite.com/sku/PDUMV40.
© 2014 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice. Photos may differ slightly from final products.
4 / 4
