Tripp Lite SR4POST25 Manuale utente

25U 4-Post SmartRack Open Frame Rack - Organize

and Secure Network Rack Equipment

MODEL NUMBER: SR4POST25

Description

SmartRack 4-post open frame racks are ideal for cost conscious 19 inch rack mount applications. Multiple units can be bolted together side by side.

Features

Supports 1000lbs of rackmount equipment

Adjustable mounting depth (22 to 39 inches)

Textured powder coat finish

Heavy-duty cold-rolled steel construction

Numbered mounting positions

Bolt down provisions

Self squaring design

Black finish

Easy assembly

Specifications

PHYSICAL

Installed whole system maximum

rack depth (inches) 39.3

Installed whole system maximum

rack depth (cm) 99.82

Installed whole system minimum

rack depth (inches) 22

Installed whole system minimum

rack depth (cm) 55.88

Highlights

25U 4-post open frame rack

Black steel with square,

numbered mounting holes

Toolless button holes to accept

PDUs or cable managers

Package Includes

SR4POST25

Installation hardware

32x pieces of M6 cage nuts,

screws, and washers for

equipment mounting

Cable management hooks

Owner's manual with warranty

information

1 / 3

Rack Height 25U

Shipping Dimensions (HWD/in) 4.13 x 5.71 x 56.5

Shipping Dimensions (HWD/cm) 10.5 x 14.5 x 143.51

Shipping weight (lbs) 46

Shipping weight (kg) 20.7

Unit Dimensions (HWD/cm) 125.2 x 51.3 x 55.9~99.8 (depth adjustable)

Unit Dimensions (in.) 49.3 x 20.2 x 22~39.3 (depth adjustable)

Unit weight (lbs) 45

Unit weight (kg) 20.25

Unit Dimensions (cm) 125.2 x 51.31 x 55.88~99.1 (depth adjustable)

Color Black

Style 4-Post

Weight Capacity - Stationary (lbs) 1000

Weight Capacity - Stationary (kg) 453.6

SPECIAL FEATURES

Grounding lug Included screws, nuts, and washers secure user-supplied grounding wire to Front or Back frames

CERTIFICATIONS

NOM (Mexico) Tested to NOM (Mexico)

Approvals EIA-310-D, IEC 60297-3-100, DIN 41494, RoHS

WARRANTY

Product Warranty Period (Worldwide) 5-year limited warranty

Related Items

Optional Products

Model Number Description Qty.

SRFAN3U 3U Fan Panel, 120V (3 high-performance fans; 210 CFM; 5-15P plug.) 1

SRXFAN3U 3U Fan Panel, 230V (3 high-performance fans; 210 CFM; C14 inlet.) 1

SR1UBRUSH 1U Cable Pass-Through Panel with Brush Strip 1

SR1UPANEL10 1U Blanking Panel Kit (10 pieces; toolless mounting.) 1

SRCABLEDUCT1U 1U Horizontal Cable Manager (Finger duct with cover.) 1

SRCABLERING1U 1U Horizontal Cable Manager (Flexible ring type.) 1

SRCABLERING2U 2U Horizontal Cable Manager (Flexible ring type.) 1

2 / 3

SRSHELF4PHD Heavy-Duty Fixed Shelf (250 lb / 113 kg capacity; 26 in / 660 mm depth.) 1

SRSHELF4PKYBD Keyboard Shelf (25 lb / 11 kg capacity; 16-in. / 406 mm depth.) 1

SRBOLTDOWN Bolt-Down Kit (Secures included stabilizing brackets or optional stabilizing plates to facility floor.) 1

SRCAGENUTS Square Hole Hardware Kit (Includes 50 M6 screws and washers.) 1

SRCASTER Heavy-Duty Rolling Caster Kit (Includes 4 casters) 1

UPSHDEARKIT Heavy-Duty Mounting Ear Kit - Supports 2U cabinets up to 65 lb / 29 kg from front vertical rails in

4-post or 2-post racks and enclosures. ) 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at:

http://www.tripplite.com/sku/SR4POST25.

Specifications are subject to change without notice. Photos may differ slightly from final products.

3 / 3
