Tripp Lite B036-002-R Manuale utente

2-Port In-Line DVI KVM

Switch with Audio

Model: B036-002-R

Owner’s Manual

Warranty

Registration

chance to win a FREE Tripp Lite

product! www.tripplite.com/warranty

Tripp Lite World Headquarters

1111 W. 35th Street, Chicago, IL 60609 USA

(773) 869-1234 • www.tripplite.com

NOTE: Follow these instructions to ensure proper operation and prevent damage to this device

and its connected equipment.

Package Contents ..........................................................................2

Features ..........................................................................................2

Product Diagram ..........................................................................3

Specifications..................................................................................4

System Requirements ....................................................................4

Hardware Installation ..................................................................5

Operation (Hotkey Switching)......................................................5

Warranty Registration ..................................................................6

Limited Warranty..........................................................................6

FCC Statement ..............................................................................7

Table of Contents:

200608009--93-2603 Inline DVI KVM Switch manual.qxd 8/23/2006 2:50 PM Page 1

Package Contents

1 B036-002-R KVM Switch

1 Owner's Manual

Features

• Control two DVI-enabled computers from a single USB console (USB mouse, USB keyboard

and digital video monitor)

• Listen to stereo audio from your console speakers

• Innovative built-in cables for quick and easy setup

• Supports Microsoft®IntelliMouse®, Logitech®mice and many others

• Convenient hotkeys for fast computer switching

• USB keyboard and mouse emulation for error-free booting

• Hot-pluggable to add or remove computers without powering off the KVM switch

• Self-powered, compact design

• Plug-and-play monitor support

• No software or drivers required

• Superior video resolution (up to 1600 x 1200 @ 60Hz)

200608009--93-2603 Inline DVI KVM Switch manual.qxd 8/23/2006 2:50 PM Page 2

Product Diagram

1DVI Video Connector (Console)

2USB Keyboard Port (Console)

3USB Mouse Port (Console)

4USB Keyboard/Mouse Connector (PC)

5DVI Video Connector (PC)

6Audio Port (Console)

7Audio Connector (PC)

200608009--93-2603 Inline DVI KVM Switch manual.qxd 8/23/2006 2:50 PM Page 3

Specifications

Computer Connections 2

Port Selection Hotkeys

Computer Ports

Monitor 2 sets: DVI-D male

Keyboard/Mouse 2 sets: USB Type A male

Audio 2 sets: Audio Jack male

Console Ports

Monitor 1 set: DVI-D male

Keyboard 1 set: USB Type A female

Mouse 1 set: USB Type A female

Audio 1 set: Audio Jack female

Resolution 1600 x 1200 @ 60Hz

Dimensions (W x D x H) 2.0 x 1.5 x 1.0 in

Weight 0.85 lb

Material of Construction Plastic

Built-in Cable Length 4.6 ft

Power Supply Bus-Powered

Operation and Storage Parameters

Operating Temperature 32° to 104° F (0°to 40° C)

Storage Temperature -4° to 104° F (-20°to 60° C)

Humidity 0-80% RH, non-condensing

Note: Tripp Lite follows a policy of continuous improvement. Specifications are subject to change without notice.

System Requirements

Operating Systems:

Microsoft®Windows®98, 2000, ME, XP (Full Function)

Microsoft®Windows®95, Linux®, FreeBSD®(Port Switch Function Only)

Hardware:

Keyboard/Mouse Port: USB Type A Female

Monitor/Display Port: DVI-D Female

200608009--93-2603 Inline DVI KVM Switch manual.qxd 8/23/2006 2:50 PM Page 4

Hardware Installation

Connecting the Console

1. Power off all computers.

2. Connect your USB keyboard and mouse directly to the USB keyboard and mouse ports (female)

of the KVM.

3. Connect the DVI video connector to your monitor.

4. (Optional) Connect your speakers to the console audio port.

Connecting the Computers

1. Connect the KVM's built-in USB keyboard and mouse cables to the USB ports on your computer.

2. Connect the KVM's DVI video connector to your computer.

3. (Optional) Connect the built-in audio jack to the audio port on your computer.

4. Repeat Steps 1 to 3 for your second computer.

5. Power on your computers and refer to the "Operation" section.

WARNING: Before connecting or disconnecting your devices to the KVM switch,

make sure your devices are powered off. Also make sure that your devices are

properly grounded before installation to prevent damage. Failure to follow these

instructions will void your product warranty. Tripp Lite will not be responsible for

damage to improperly grounded equipment.

Operation

The KVM allows you to switch between computers with a simple keyboard command. Simply press the

"Scroll Lock" key twice within a two-second period to switch the KVM focus to the other computer.

200608009--93-2603 Inline DVI KVM Switch manual.qxd 8/23/2006 2:50 PM Page 5

Warranty Registration

Visit www.tripplite.com/warranty today to register the warranty

for your new Tripp Lite product. You'll automatically be entered

into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

1-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of

one (1) year from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to

repairing or replacing (at its sole option) any such defective products. To obtain service under this

warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an

authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized

TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief

description of the problem encountered and proof of date and place of purchase. This warranty does not

apply to equipment which has been damaged by accident, negligence or misapplication or has been

altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR

IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR

A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties;

therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT,

INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE

USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment,

loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties,

or otherwise.

200608009--93-2603 Inline DVI KVM Switch manual.qxd 8/23/2006 2:50 PM Page 6

FCC Radio / TV Interference Notice

Note: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy, and if not installed and used in accordance with the instruction manual, may cause

interference to radio communications. However, there is no guarantee that interference will not occur in

a particular installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference using one or more of the following measures: reorient or relocate the receiving antenna;

increase the separation between the equipment and the receiver; connect the equipment into an outlet on

a circuit different from that which the receiver is connected; consult the dealer or an experienced

radio/television technician for help. The user must use shielded cables and connectors with this product.

Any changes or modifications to this product not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment. This device complies with part 15

of the FCC rules. Operation is subject to the following 2 conditions: (1) This device may not cause

harmful interference, and (2) This device must accept any interference received, including interference

that may cause undesired operation.

Tripp Lite follows a policy of continuous improvement. Specifications are subject to change

without notice.

200608009--93-2603 Inline DVI KVM Switch manual.qxd 8/23/2006 2:50 PM Page 7

Tripp Lite World Headquarters

1111 W. 35th Street, Chicago, IL 60609 USA

(773) 869-1234 • www.tripplite.com

200608009 93-2603

200608009--93-2603 Inline DVI KVM Switch manual.qxd 8/23/2006 2:50 PM Page 8
