Tripp Lite B119-002-UHD Manuale utente

Owner’s Manual

4K x 2K UHD HDMI Switch

Models:

B119-002-UHD (2-Port),

B119-004-UHD (4-Port),

B119-005-UHD (5-Port)

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

Español 11 • Français 21 • Русский 31

18-08-475-9337C3.indb 1 9/13/2018 1:16:26 PM

Product Features

• Switch between multiple HDMI source

devices connected to a single HDMI port on

a monitor

• Switch devices via pushbutton or the

included remote control

• Intelligent Auto Switching functionality will

automatically switch to the next powered-on

device when the power to the current device

is turned off*

• Supports 4K x 2K Ultra High Deﬁnition

(UHD) video resolutions up to 3840 x 2160

@ 60 Hz

• Supports up to 48-bit Deep Color

(16 bits per channel)

• Supports DTS-HD, Dolby®TrueHD and

7.1 channel surround sound audio

• 3D, HDCP v2.2 and EDID compatible

• The B119-005-UHD model includes an

international power supply with compatible

North American, U.K., European and

Australian plug adapters.

• Plug and play; no software or drivers

required

18-08-475-9337C3.indb 2 9/13/2018 1:16:26 PM

Package Contents

• B119-002-UHD, B119-004-UHD or

B119-005-UHD

• Remote Control

• External Power Supply

B119-002-UHD Model:

(Input: 100-240V, 50/60 Hz, 0.4A;

Output: 5V 2A)

B119-004-UHD Model:

(Input: 100-240V, 50/60 Hz, 0.2A;

Output: 5V 1A)

B119-005-UHD Model:

(Input: 100-240V, 50/60 Hz, 0.3A;

Output: 5V 1A)*

• Owner’s Manual

*Includes NEMA 1-15P (North America), CEE 7/16

Schuko (Europe), BS 1363 (U.K.) and AS/NZS 3112

(Australia) plugs.

Product Features

*Auto switching will not work properly if you have a

device that is in sleep mode. Devices must be powered

off completely for auto switch to work properly.

18-08-475-9337C3.indb 3 9/13/2018 1:16:26 PM

Installation

1. Make sure the power to all devices that you

will be connecting is turned off.

2. Connect an HDMI source device to an

Input port on the switch.

Note: The length of the HDMI cable connecting

the source to the switch must not exceed 16 ft.

(5 m).

3. Repeat step 2 to connect source devices to

the remaining Input ports on the switch.

4. Connect the Output port on the switch to

the HDMI input port of your display.

Note: The length of the HDMI cable connecting

the switch to the display must not exceed 16 ft.

(5 m).

Optional Accessories

• P569-XXX-CERT Premium High-Speed HDMI

with Ethernet Cables

18-08-475-9337C3.indb 4 9/13/2018 1:16:26 PM

Installation

5. Connect the external power supply to the

switch, and then plug it into a Tripp Lite

Surge Protector, Uninterruptible Power

Supply (UPS), or Power Distribution Unit

(PDU). The red Power LED and green

Input 1 LED will illuminate to indicate that

power is being received.

6. Turn on the power to the HDMI source

devices and display.

7. Switch between source devices via the

Select pushbutton on the unit or the

included remote control. You can also let

the Auto Switch functionality automatically

switch to ports that are powered on. When

multiple ports have powered on devices

connected to them, the lowest numbered

port will be switched to. Once the device

connected to the lowest numbered port is

powered off, the next powered on port in

line will be switched to.

18-08-475-9337C3.indb 5 9/13/2018 1:16:26 PM

Troubleshooting

If you are unable to get an acceptable image

after following the installation instructions, try

the troubleshooting tips below.

1. Is the external power supply that came

with the product connected and plugged

into a working power source? For the

product to function properly, the switch must

be connected to and receiving power from

an external power supply.

2. Was the power to the connected devices

turned off prior to installation? If not,

restart them.

3. What resolution are you trying to reach?

Tripp Lite’s B119-002-UHD, B119-004-UHD

and B119-005-UHD are tested to support

4K x 2K Ultra High Deﬁnition (UHD) video

resolutions up to 3840 x 2160 @ 60 Hz,

and 48-bit Deep Color (16 bits per channel).

4. What length HDMI cable are you using?

(See the Installation section in this manual

for details on the maximum cable distance).

The shorter the cable being used, the higher

the resolution you will be able to obtain.

(continued)

18-08-475-9337C3.indb 6 9/13/2018 1:16:26 PM

Troubleshooting

If you are not able to get an acceptable

image, try using a shorter cable, or lowering

your source’s video resolution or color depth

settings.

5. What type of cabling are you using?

Inferior cabling can result in poor

performance, so it is important that you use

cables that can support the video resolution

you are trying to obtain. It is recommended

that you use Tripp Lite’s P569-Series High

Speed HDMI cables, as they have been

tested to work with the B119-002-UHD,

B119-004-UHD and B119-005-UHD.

6. Test your cables to ensure they are

working properly. For example, connect

your HDMI cable between a source and

monitor that you know works to see if the

cable is functioning.

7. Is the unit located in an area that

exposes it to higher temperatures? If the

product is overheated, it will not function

properly.

18-08-475-9337C3.indb 7 9/13/2018 1:16:26 PM

Speciﬁcations

Model B119-002-UHD B119-004-UHD B119-005-UHD

Connectors

Input (x2) HDMI Female (x4) HDMI Female (x5) HDMI Female

Output HDMI Female HDMI Female HDMI Female

Video

Maximum

Resolution

3840 x 2160

(60 Hz)

3840 x 2160

(60 Hz)

3840 x 2160

(60 Hz)

Color Depth 48-bit Deep Color

(16 bits per channel)

48-bit Deep Color

(16 bits per channel)

48-bit Deep Color

(16 bits per channel)

Video Ampliﬁer

Bandwidth

6Gbps / 600Mhz 6Gbps / 600Mhz 6Gbps / 600Mhz

Environmental

Operating

Temperature

32 to 104°F

(0 to 40°C)

32 to 104°F

(0 to 40°C)

32 to 104°F (0 to

40°C)

Operating

Humidity

10% to 85% RH,

Non-Condensing

10% to 85% RH,

Non-Condensing

10% to 85% RH,

Non-Condensing

Storage

Temperature

14 to 176°F

(-10 to 80°C)

14 to 176°F

(-10 to 80°C)

14 to 176°F (-10

to 80°C)

Storage Humidity 5% to 90% RH,

Non-Condensing

5% to 90% RH,

Non-Condensing

5% to 90% RH,

Non-Condensing

Physical

Unit Dimensions

(HxWxD, in.)

0.8 x 3.1 x 2.0 0.8 x 4.8 x 2.0 0.8 x 4.8 x 2.0

Unit Dimensions

(HxWxD, mm)

20 x 80 x 51 20 x 123 x 51 20 x 123 x 51

Unit Weight (lb.) 0.23 0.33 0.33

Unit Weight (kg) 0.1062 0.15 0.15

Power Requirements

External Power

Supply

5V/2A 5V/1A 5V/1A

Power

Consumption

(Max)

2W 2W 2.5W

18-08-475-9337C3.indb 8 9/13/2018 1:16:26 PM

Warranty and Product Registration

3-YEAR LIMITED WARRANTY

TRIPP LITE warrants its products to be free from defects in

materials and workmanship for a period of three (3) years

from the date of initial purchase. TRIPP LITE’s obligation

under this warranty is limited to repairing or replacing (at its

sole option) any such defective products. To obtain service

under this warranty, you must obtain a Returned Material

Authorization (RMA) number from TRIPP LITE or an authorized

TRIPP LITE service center. Products must be returned to

TRIPP LITE or an authorized TRIPP LITE service center with

transportation charges prepaid and must be accompanied by

a brief description of the problem encountered and proof of

date and place of purchase. This warranty does not apply to

equipment, which has been damaged by accident, negligence

or misapplication or has been altered or modiﬁed in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE.

Some states do not permit limitation or exclusion of implied

warranties; therefore, the aforesaid limitation(s) or exclusion(s)

may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE

BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR

CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF

THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGE. Speciﬁcally, TRIPP LITE is not liable for any

costs, such as lost proﬁts or revenue, loss of equipment, loss

of use of equipment, loss of software, loss of data, costs of

substitutes, claims by third parties, or otherwise.

18-08-475-9337C3.indb 9 9/13/2018 1:16:26 PM

Warranty and Product Registration

PRODUCT REGISTRATION

Visit www.tripplite.com/warranty today to register your new

Tripp Lite product. You’ll be automatically entered into a

drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some

restrictions apply. See website for details.

WEEE Compliance Information for Tripp Lite Customers

and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment

(WEEE) Directive and implementing regulations,

when customers buy new electrical and electronic

equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one,

like-for-like basis (this varies depending on the

country)

• Send the new equipment back for recycling when

this ultimately becomes waste

Use of this equipment in life support applications where failure

of this equipment can reasonably be expected to cause the

failure of the life support equipment or to signiﬁcantly affect its

safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement.

Speciﬁcations are subject to change without notice.

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

18-08-475-9337C3.indb 10 9/13/2018 1:16:26 PM

Altri manuali per B119-002-UHD

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Tripp Lite Interruttore

Tripp Lite

Tripp Lite Minicom 0SU70036 Manuale utente

Tripp Lite

Tripp Lite B005-004-R Manuale utente

Tripp Lite

Tripp Lite NetController B040-008-19 Guida rapida

Tripp Lite

Tripp Lite SmartRack SRSWITCH Manuale utente

Tripp Lite

Tripp Lite B004-VPA2-K-R Guida alla configurazione

Tripp Lite

Tripp Lite AVS5D Manuale utente

Tripp Lite

Tripp Lite PDUMH30AT Manuale utente

Tripp Lite

Tripp Lite B022-U16-IP Manuale utente

Tripp Lite

Tripp Lite B022-002-KT-R Manuale utente

Tripp Lite

Tripp Lite Minicom Smart 108 IP Manuale utente

Tripp Lite

Tripp Lite NetDirector B064-016-04-IP Manuale utente

Tripp Lite

Tripp Lite PDUMH20ATNET Manuale utente

Tripp Lite

Tripp Lite U280-004-OTG Manuale utente

Tripp Lite

Tripp Lite NetDirector B022-U08-IP Guida all'installazione

Tripp Lite

Tripp Lite U460-T04-2A2C-1 Manuale utente

Tripp Lite

Tripp Lite 4 Port USB 1.1 Self- or Bus-Powered Hub... Manuale utente

Tripp Lite

Tripp Lite B024-DUA8-SL Manuale utente

Tripp Lite

Tripp Lite NetDirector B024-H4U08 Manuale utente

Tripp Lite

Tripp Lite NSU-G16 Manuale utente

Tripp Lite

Tripp Lite NetController B042-004 Manuale utente

Tripp Lite

Tripp Lite PDUMH30NET Manuale utente

Tripp Lite

Tripp Lite B021-SWHD-K Manuale utente

Tripp Lite

Tripp Lite PDUMV20NET Manuale utente

Tripp Lite

Tripp Lite B64-032-04-IPG Manuale utente

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente
