Tripp Lite U460-003-3AGALC Manuale utente
1
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Quick Start Guide
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR®surge protector in our monthly drawing!
tripplite.com/warranty
3-Port USB-C Hub with
Gigabit Ethernet, 100W PD
Charging and QC Charging
Model: U460-003-3AGALC
USB Type-C®and USB-C®are registered trademarks of USB
Implementers Forum.
Este manual está disponible en español en la página
de Tripp Lite:tripplite.com
Ce manuel est disponible en français sur le site Web
de Tripp Lite : tripplite.com
Русскоязычная версия настоящего руководства
представлена на веб-сайте компании Tripp Lite по
адресу: tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der
Tripp Lite-Website verfügbar: tripplite.com
2
• 3 USB-A ports support USB 3.2 Gen 1 data transfer
speeds up to 5 Gbps
• One USB port also supports charging up to 5V 1.5A
(7.5W)
• USB-C PD Charging 3.0 port supports 20V 5A
(100W) power output and Fast Role Swap for
charging host device, as well as simultaneous data
transmission at speeds up to 5 Gbps
• USB ports backward compatible with USB 2.0
legacy equipment
• RJ45 port allows connection to 10/100/1000 Mbps
(1 Gbps) Gigabit Ethernet network
• Compact size allows convenient transport in a
backpack or laptop bag for connections anywhere
Product Features
3
• U460-003-3AGALC 3-Port USB-C Hub
• Quick Start Guide
• N201-Series Cat6 Gigabit Snagless Ethernet Cables
• U420-Series USB-C (USB 3.2 Gen 1) Cables, M/M
Package Contents
Optional Accessories
4
1. Connect the built-in USB-C cable to your
MacBook, Chromebook or other USB-C host.
2. Connect the USB-C PD Charging port to your host
device or an AC wall charger with a user-supplied
USB cable (see Optional Accessories).
3. Connect USB peripherals, such as a thumb drive,
mouse and keyboard, to the USB-A ports.
4. Connect the RJ45 port to a Gigabit Ethernet
network or router with a user-supplied Ethernet
cable (see Optional Accessories).
5. Automatically or manually set the host device’s IP
address.
Operation
5
Operation
Ethernet Router
USB Devices Type-C Host PC
Type-C
Device
Type-C PD
Adapter
OR
6
Specifications
Input/Output
Input USB-C (Male)
Output (3x) USB-A (Female)
USB-C PD Charging (Female)
RJ45 (Female)
USB Version USB 3.2 Gen 1 (5 Gbps)
PD Charging 100W PD Charging
Mechanical
Size 3.7 x 1.8 x 0.5 in. /
95 x 45 x 13 mm
Weight 2.4 oz. / 68.5 g
Environmental
Operating
Temperature Range
32° to 113°F
(0° to 45°C)
Storage
Temperature Range
14° to 158°F
(-10° to 70°C)
Operating
Humidity Range
10 to 85% RH,
Non-Condensing
Storage
Humidity Range
5 to 90% RH,
Non-Condensing
Warranty
Limited Warranty 1 Year
Regulatory Approvals
Certifications FCC, CE, ICES, RoHS, REACH
7
Warranty and Product Registration
3-Year Limited Warranty
Seller warrants this product, if used in accordance with all
applicable instructions, to be free from original defects in
material and workmanship for a period of three (3) years
from the date of initial purchase. If the product should prove
defective in material or workmanship within that period, Seller
will repair or replace the product, at its sole discretion.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR
TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE
OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES
OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW,
ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF
MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION
TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS
WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND
CONSEQUENTIAL DAMAGES. (Some states do not allow
limitations on how long an implied warranty lasts, and some
states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitations or exclusions
may not apply to you. This warranty gives you specific legal
rights, and you may have other rights which vary from
jurisdiction to jurisdiction.)
WARNING: The individual user should take care to determine
prior to use whether this device is suitable, adequate or safe
for the use intended. Since individual applications are subject
to great variation, the manufacturer makes no representation
or warranty as to the suitability or fitness of these devices for
any specific application.
8
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
21-03-058 • 93-3E2D_RevB
Warranty and Product Registration
Product Registration
Visit tripplite.com/warranty today to register your new Tripp Lite
product. You’ll be automatically entered into a drawing for a
chance to win a FREE Tripp Lite product!*
*No purchase necessary. Void where prohibited. Some
restrictions apply. See website for details.
WEEE Compliance Information for Tripp Lite Customers
and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment
(WEEE) Directive and implementing regulations,
when customers buy new electrical and electronic
equipment from Tripp Lite, they are entitled to:
• Send old equipment for recycling on a one-for-one,
like-for-like basis (this varies depending on the
country)
• Send the new equipment back for recycling when
this ultimately becomes waste
Use of this equipment in life support applications where failure
of this equipment can reasonably be expected to cause the
failure of the life support equipment or to significantly affect its
safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice. Photos
and illustrations may differ slightly from actual products.
