Tripp Lite SmartPro SMART3000RM2UN Guida all'installazione

SmartPro 3kVA 2.25kW Line Interactive Sine Wave

UPS, Pre-installed SNMPWEBCARD, 2U, LCD, USB,

Serial, EPO, 120V

MODEL NUMBER: SMART3000RM2UN

Description

Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for

critical server, network and telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS)

with built-in Auto-Voltage Regulation (AVR) actively corrects brownouts and overvoltages back to usable levels

while maintaining a full battery charge in case of power failure. Tripp Lite's unique configuration excels in

exceptionally poor-power environments with two separate levels of voltage boost to correct both slight

undervoltages and severe brownout conditions. Interactive LCD interface reports UPS operating mode, detailed

UPS and site-power data, plus enables a variety of UPS setup and configuration options. Super-fast switchover

from line to battery power occurs within milliseconds to maintain operation of connected equipment without

interruption or reboot. 98% line-mode efficiency offers reduced heat emissions and operating costs. Network

management interfaces support communications via USB, RS-232 and pre-installed SNMPWEBCARD network

interface. HID-compliant USB interface enables integration with built-in power management and auto shutdown

features of Windows and Mac OS X. Network communications ports enable detailed monitoring of equipment

load levels, self-test data and utility power conditions. Includes PowerAlert monitoring software and complete cabling. Switched output load banks enable

scheduled and real-time remote reboot and load shedding of select outlets. Emergency Power Off (EPO) interface. LCD display panel easily rotates for

viewing in rackmount or tower configurations. Audible alarm with push-button momentary alarm-cancel and silent-mode configuration options. Programmable

self-test. Field-replaceable, hot-swappable battery modules.

Features

Tripp Lite SMART3000RM2UN line interactive 2U rack/tower UPS with 3000VA / 3kVA capacity (1600W maximum load with external battery packs)

Line interactive UPS with Automatic Voltage Regulation (AVR) corrects brownouts and overvoltages from 83 to 145V

NEMA L5-30P input plug; 8 NEMA 5-15/20R and 1 L5-30R output receptacles, Two independently switchable output load banks

Maintains uninterrupted operation of connected networking equipment during blackouts, surges, brownouts and overvoltages

High 98% efficiency rating in line-power mode offers reduced power consumption and BTU emisssions

Internal batteries offer 10 minutes at 50% load (1125W) and 3.5 minutes at 100% load (2250W)

Highlights

3kVA / 3000VA / 2250W line

interactive 2U rack/tower UPS

120V nominal output during

brownouts to 83V and

overvoltages to 145V

Interactive LCD provides UPS

status information and advanced

configuration options

USB, RS232, EPO and

Pre-installed SNMPWEBCARD

interface

Hot-swap batteries, 98%

efficiency, Sine wave output

2 independently switchable

output load banks

NEMA L5-30P input, 8 NEMA

5-15/20R & 1 L5-30R outlets

This product is ENERGY STAR

qualified for its ability to save

customers money while

helping to protect the

environment

Package Includes

SMART3000RM2UN UPS

System with Pre-installed

SNMPWEBCARD

PowerAlert Software with USB,

Serial & EPO cabling

4-post rackmount installation kit

Instruction manual

1 / 6

Extended runtime is available with optional BP48V24-2U (limit 1), BP48V60RT-3U (multi-pack compatible) and BP48V27-2US (multi-pack compatible)

external battery packs (max output de-rates to 1600 watts with external batteries)

External battery configurations require the use of Tripp Lite's External Battery Configuration Software (see manual)

Hot-swappable, user-replaceable internal batteries and external battery packs can be replaced with no disruption to connected equipment

Front panel LCD monitoring screen with MODE and ENTER buttons reports operating mode with 5-bar battery charge graphic, plus 7 selectable screens

of detailed UPS and site power information

LCD interface also supports a number of advanced user setup and operating preferences

Ships with 4 post rackmount installation hardware; Optional 2POSTRMKITWM enables 2 post rackmount/wallmount installation; Optional 2-9USTAND

enables tower placement

Built-in USB, RS-232 and pre-installed SNMPWEBCARD accessory

HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X

Included PowerAlert UPS monitoring software; Built-in Emergency Power Off (EPO) interface with cable

Specifications

OUTPUT

Output Volt Amp Capacity (VA) 3000

Output kVA capacity (kVA) 3

Output Watt Capacity (watts) 2250

Output kW capacity 2.25

Output power factor 0.75

Nominal Output Voltage(s)

Supported 120V

Frequency compatibility 60 Hz

Output voltage regulation (line mode) -14%, +6%

Output voltage regulation (Battery

mode) +/- 5%

Built-in UPS output receptacles 8 5-15/20R outlet(s); 1 L5-30R outlet(s)

Built-in controllable switched load

banks Two switchable single-outlet load banks

Output circuit breaker Two 20A output breakers protect 4 5-15/20R outlets each

Output AC waveform (AC mode) Pure Sine wave

Output AC waveform (battery mode) Pure Sine wave

INPUT

Rated input current (at maximum

load) 24A

Nominal Input Voltage(s) Supported 120V AC

UPS input connection type L5-30P

UPS Input cord length (ft.) 10

2 / 6

UPS Input cord length (m) 3

Recommended Electrical Service 30A 120V

Phase Single-Phase

BATTERY

Full load runtime (minutes) 3.5 min. (2250w)

Half load runtime (minutes) 10 min. (1125w)

Expandable battery runtime Output with external battery pack configurations is limited to 1600 watts maximum

External battery pack compatibility BP48V24-2U (limit 1); BP48V60RT-3U (multi-pack compatible); BP48V27-2US (multi-pack compatible)

DC system voltage (VDC) 48

Battery recharge rate (included

batteries) Less than 4.5 hours from 10% to 90%

Replacement battery cartridge

(internal UPS battery replacement) RBC94-2U

Battery Access Front panel battery access door

Battery replacement description Hot-swappable, user replaceable batteries

VOLTAGE REGULATION

Voltage regulation description Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 145

Overvoltage correction Input voltages between 127 and 145 are reduced by 12%

Undervoltage correction Input voltages between 108 and 96 are boosted by 12%

Severe undervoltage correction Input voltages between 83 and 95 are boosted by 24%

LEDS ALARMS & SWITCHES

Front panel LCD display

Front panel LCD information and configuration screen offers detailed UPS and site power status and operating

data, plus configuration of voltage, operating mode, alarm function and a variety of additional options (see manual

for detailed LCD configuration and monitoring options)

Alarms Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown conditions

Alarm cancel operation Power-fail alarm can be temporarily silenced using alarm-cancel switch; silent mode alarm configuration option

available

Switches 3 pushbutton switches control OFF / ON power status, MODE selection and MUTE / ENTER control functions

SURGE / NOISE SUPPRESSION

UPS AC suppression joule rating 570

UPS AC suppression response time Instantaneous

EMI / RFI AC noise suppression Yes

PHYSICAL

3 / 6

Installation form factors supported

with included accessories 4 post 19 inch rackmount

Installation form factors supported

with optional accessories 2 post rackmount (2POSTRMKITWM); Wallmount (2POSTRMKITWM); Tower (2-9USTAND)

Primary form factor Rackmount

UPS / Power Module dimensions in

primary form factor (height x width x

depth / inches)

3.5 x 17.5 x 19.5

UPS / Power Module dimensions in

primary form factor (height x width x

depth / cm)

8.9 x 44.4 x 49.5

Rack Height 2U

Secondary form factor Tower (requires 2-9USTAND)

UPS / Power Module weight (lbs) 62.8

UPS / Power Module weight (kg) 28.5

UPS Shipping dimensions (height x

width x depth / inches) 7.9 x 21.7 x 24.2

UPS Shipping dimensions (height x

width x depth / cm) 20.1 x 61.5 x 62

Shipping weight (lbs) 73.8

Shipping weight (kg) 33.5

Cooling method Fan

UPS housing material Steel

ENVIRONMENTAL

Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC mode BTU / hr. (full load) 189

AC mode efficiency rating (100%

load) 98%

Operating Elevation (ft.) 0-3000m / 0-10,000 ft.

COMMUNICATIONS

Communications interface USB (HID enabled); DB9 Serial; Slot for SNMP/Web interface

Network monitoring port description Includes pre-installed SNMPWEBCARD interface; Supports detailed monitoring of UPS and site power conditions

PowerAlert software Included

Communications cable USB and DB9 cabling included

WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications

4 / 6

LINE / BATTERY TRANSFER

Transfer time 5 milliseconds (AC to battery); 1 millisecond (battery to AC)

Low voltage transfer to battery

power (setpoint) 83

High voltage transfer to battery

power (setpoint) 145

SPECIAL FEATURES

Grounding lug Includes back panel grounding lug

Cold Start (startup in battery mode

during a power failure) Cold-start operation supported

High availability UPS features Hot swappable batteries

Green & high efficiency features Greater than 95% efficiency - GREEN UPS; Individually controllable load banks

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A

(EMI); ENERGY STAR Qualified

WARRANTY

Product Warranty Period (Worldwide) 2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.

Connected Equipment Insurance

(U.S., Canada & Puerto Rico) $250,000 Ultimate Lifetime Insurance

Related Items

Optional Products

Model Number Description Qty.

WEXT5-2200-3000 5-Year Extended Warranty - For Smart Line-Interactive and Online Tower or Rack models,

2200-3000VA or less 1

BP48V27-2US BP48V27-2US - 2U External 48V Rack/Tower Battery pack for select Tripp Lite UPS Systems 1

BP48V24-2U External Battery Pack for UPS System 1

BP48V60RT-3U External Battery Pack and Cable. 3U, Expandable, Blue 2-Point Connector 1

ENVIROSENSE Monitors temperature, humidity and contact-closure inputs. (Requires UPS with SNMPWEBCARD,

monitored PDU or switched PDU.) 1

SRSWITCH Magnetic Door Switch Kit for front and rear doors; requires ENVIROSENSE 1

2-9USTAND Enables Tower Placement of Rackmount UPS Systems 1

2POSTRMKITWM Enables 2-Post Rackmount or Wallmount Installation of Select Rackmount UPS Systems 1

WATCHDOGSW WatchDog Service Monitoring / Reboot Software 1

5 / 6

PDU1220 Single-Phase Basic PDU, 20A 120V, 1U Horizontal Rackmount, 13 NEMA 5-15/20R outlets, NEMA

5-20P input plug 1

PDUV20 Single-Phase Basic PDU, 20A 120V, 0U Vertical Rackmount, 14 NEMA 5-15/20R outlets, NEMA

L5-20P input with 5-20P adapter 1

PDUMH20 Single-Phase Metered PDU, 20A 120V, 1U Horizontal Rackmount, 12 NEMA 5-15/20R outlets,

NEMA L5-20P input with 5-20P adapter 1

PDUNV Single-Phase Basic PDU, 16A 100-240V, 1U Rackmount, C13 C19 outlets, C20 input and C14,

L6-20P, L5-20P, 5-20P and 5-15P adapters 1

PDUMV20 Single-Phase Metered PDU, 20A 120V, 0U Vertical Rackmount, 28 NEMA 5-15/20R outlets, NEMA

L5-20P input with 5-20P adapter 1

PDUMNV20 Single-Phase Monitored PDU, 20A 120V, 70 in. 0U Vertical Rackmount, 24 NEMA 5-15/20R outlets,

NEMA L5-20P input with 5-20P adapter 1

PDUMNH20 Single-Phase Monitored PDU, 20A 120V, 1U Horizontal Rackmount, 8 NEMA 5-15/20R outlets,

NEMA L5-20P input with 5-20P adapter 1

PDUMV20NET Single-Phase Switched PDU, 20A 120V, 0U Vertical Rackmount, 24 NEMA 5-15/20R outlets, NEMA

L5-20P input with 5-20P adapter 1

PDUMH20AT Single-Phase Auto Transfer Switch / Metered PDU, 20A 120V, 1U Horizontal Rackmount, 16

5-15/20R outlets, 2 L5-20P / 5-20P adapters 1

PDUMH20ATNET Single-Phase Auto Transfer Switch / Switched PDU 20A 120V, 1U Horizontal Rackmount, 16

5-15/20R outlets, 2 L5-20P / 5-20P inputs 1

PDUB20 Single-Phase Hot-Swap PDU, 20A 120V, 2U Horizontal Rackmount, 4 NEMA 5-15R & 4 NEMA

5-15/20R outlets, 2 NEMA 5-20P input plugs 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at:

http://www.tripplite.com/sku/SMART3000RM2UN.

Specifications are subject to change without notice. Photos may differ slightly from final products.

6 / 6

Indice

Altri manuali Tripp Lite UPS

Tripp Lite

Tripp Lite OMNISMART OMNIVS500 Manuale utente

Tripp Lite

Tripp Lite SmartPro SMART5000RT3U Manuale utente

Tripp Lite

Tripp Lite SmartPro VS Manuale utente

Tripp Lite

Tripp Lite POS Series Manuale utente

Tripp Lite

Tripp Lite SmartOnline SUPDMB5 Manuale utente

Tripp Lite

Tripp Lite SmartPro AGSM8207 Series Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU2200XLNAFTA Manuale utente

Tripp Lite

Tripp Lite AGOM5515 Manuale utente

Tripp Lite

Tripp Lite SM3000RMNAFTA Manuale utente

Tripp Lite

Tripp Lite SMART5000TEL3U Manuale utente

Tripp Lite

Tripp Lite SmartPro SMART700SER Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU16KRTHW Guida all'installazione

Tripp Lite

Tripp Lite SmartOnline SU60KX Manuale utente

Tripp Lite

Tripp Lite SmartPro VS SMART2200VSXL Manuale utente

Tripp Lite

Tripp Lite SmartPro INT Rackmount Intelligent Network UPS... Manuale utente

Tripp Lite

Tripp Lite OmniSmart RMX 500 VA OM500RMX Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU3000RTXL3UHV Manuale utente

Tripp Lite

Tripp Lite SMART5000XFMRXL Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU6000RT3UHV Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU8000RT3UG Manuale utente

Tripp Lite

Tripp Lite OmniSmart 725 Manuale utente

Tripp Lite

Tripp Lite SmartOnline AGPS8294 Series Manuale utente

Tripp Lite

Tripp Lite OmniPro INT 300 Istruzioni per l'installazione e il funzionamento

Tripp Lite

Tripp Lite SMART1500LCD Manuale utente

Manuali UPS popolari di altre marche

Pylontech

Pylontech Victron & Pylontech US5000 Manuale utente

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuale utente

Mecer

Mecer ME-1000-WTU Manuale utente

Mustek

Mustek PowerMust 530(B) Plus Manuale di installazione e funzionamento

Emerson

Emerson Liebert NXL series Manuale utente

MAKELSAN

MAKELSAN BOXER SERIES Manuale utente

Block

Block PC-0524-400-0 Manuale utente

CyberPower

CyberPower CP585LCD Manuale utente

Eaton

Eaton 3S Istruzioni per il montaggio

CyberPower

CyberPower Office Tower Series UPS 1000 Manuale utente

CyberPower

CyberPower BM100 Manuale utente

Best Power

Best Power 610 Manuale utente

Best Power

Best Power Unity/I UT3K Manuale utente

Mustek

Mustek PowerMust 400 Offline Manuale utente

Xantrex

Xantrex Trace 512 UR-UPS Manuale utente

Forza

Forza SL-1501UL Manuale utente

LEGRAND

LEGRAND keor 310081 Manuale utente

ABB

ABB Conceptpower DPA 500 Manuale utente
