Tripp Lite SUPDMB6KIEC Manuale utente

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model Number: SUPDMB6KIEC

Detachable PDU option for compatible SmartOnline UPS Systems

Highlights

Detachable PDU backplate with manual bypass switch serves as a

replacement PDU for configured SU6000RT4UHVG UPS systems

Can also be used to convert any high voltage UPS configuration using the

SU6000RT4UHVPM power module to include C19 outlets

4 C19 output receptacles

Hardwire input supported

Attaches via unit-specific back panel electrical and bolt-on connections

Manual bypass feature ensures maximum equipment availability

Description

The SUPDMB6KIEC UPS backplate with manual transfer switch serves as a replacement for the original backplate provided with SU6000RT4UHVG

configurations. Can also be used to convert any high voltage UPS configuration using the SU6000RT4UHVPM power module to support

hardwire input and 4 C19 output receptacles. Manual bypass feature ensures maximum availability of connected equipment while UPS maintenance

occurs. Can accept input voltages of 200-240 VAC. Hardwire input / 4 C19 output connections.

System Requirements

Requires SU6000RT4UHVPM UPS power module in any 200-240V AC configuration

Package Includes

SUPDMB6KIEC detachable PDU

Features

Specifications

OVERVIEW

Model Type PDU Modules

OUTPUT

Frequency compatibility 50 / 60 Hz

Output nominal voltage 200, 208, 220, 230, 240 VAC

Overload protection 2 double pole 20A breakers protect 2 C19 outlets each

Outlet quantity / type 2 C19

INPUT

Nominal Input Voltage(s)

Supported

200V AC; 208V AC; 230V AC; 240V AC; 220V AC

Input connection type Hardwire

Voltage compatibility (VAC) 200; 208; 220; 230; 240

PHYSICAL

Shipping Dimensions

(HWD/in)

6.9 x 20.1 x 10.8

Shipping Dimensions

(HWD/cm)

17.5 x 51.1 x 27.4

Shipping weight (lbs) 7.7

Shipping weight (kg) 3.5

Unit Dimensions (HWD/in) 3.3 x 17.2 x 3.2

Unit Dimensions (HWD/cm) 8.4 x 43.7 x 8.1

Unit weight (lbs) 7.7

Unit weight (kg) 3.5

Material of construction Sheet metal

SPECIAL FEATURES

Appearance All-black color scheme

CERTIFICATIONS

Certifications Tested to UL1778 (USA), CSA (Canada), CE (EU)

WARRANTY

Product Warranty Period

(Worldwide)

2-year limited warranty

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

http://www.tripplite.com/sku/SUPDMB6KIEC.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
