TVS electronics Jus' Print RP-3200 Manuale utente

LINE THERMAL PRINTER

MODEL RP-3200

User’ s Manual

SAFETY PRECAUTIONS

...WHICH SHOULD BE STRICTLY OBSERVED

Before using this product for the first time, carefully read these SAFETY PRECAUTIONS.

Improper handling may result in accidents (fire, electric shock or injury).

In order to prevent injury to operators, third parties, or damage to property, special

warning symbols are used in the User’ s Manual to indicate important items to be strictly

observed.

After having read this Manual, keep it in a safe, readily accessible place for future

reference.

Some of the descriptions contained in this manual may not be relevant to some printer

models.

The following describes the degree of hazard and damage that could occur if the printer

is improperly operated by ignoring the instructions indicated by the warning symbols.

WARNING

Neglecting precautions indicated by this symbol may result in fatal or serious injury.

CAUTION

Neglecting precautions indicated by this symbol may result in injury or damage to

property.

This symbol is used to alert your attention to important items.

This symbol is used to alert you to the danger of electric shock or electrostatic

damage.

This symbol denotes a request to unplug the printer from the wall outlet.

This symbol is used to indicate that the power supply must be grounded.

This symbol is used to indicate useful information, such as procedures,

instructions or the like.

This symbol is used to indicate prohibited actions.

—2—

PRECAUTIONS ON PRINTER INSTALLATION

WARNING

Do not use or store this product in a place where it will be exposed to:

* Flames or moist air.

* Direct sunlight.

* Hot airflow or radiation from a heating device.

* Salty air or corrosive gases.

* Ill-ventilated atmosphere.

* Chemical reactions in a laboratory.

* Airborne oil, steel particles, or dust.

* Static electricity or strong magnetic fields.

· Neglecting these warnings may result in printer failure, overheating,

emission of smoke, fire, or electric shock.

Do not drop any foreign object nor spill liquid into the printer. Do not

place any object on the printer either.

Do not drop any metallic object such as paper clips, pins or screws

into the printer.

Do not place a flower vase, pot, or anything containing water on the

printer.

Do not spill coffee, soft drinks, or any other liquid into the printer.

Do not spray insecticide or any other chemical liquid over the printer.

· Dropping a metallic foreign object into the printer, may cause printer

failure, fire, or electric shock. Should it occur, immediately turn the

printer off, unplug it from the supply outlet, and call your local dealer.

Do not handle the printer in the following ways:

Do not subject the printer to strong impacts or hard jolts (e.g., being

stepped on, dropped or struck).

Never attempt to disassemble or modify the printer.

· Neglecting to handle properly may result in printer failure,

overheating, emission of smoke, fire, or electric shock.

Install, use, or store the printer out of the reach of children.

· Electric appliances could cause an unexpected injury or accident if

they are handled or used improperly.

· Keep the power cord and signal cables out of the reach of children.

Also children should not be allowed to gain access to any internal

part of the printer.

· The plastic bag the printer came in must be disposed of properly or

kept away from children. Wearing it over the head may lead to

suffocation.

—3—

CAUTION

Do not use the printer under the following conditions.

Avoid locations subject to vibration or instability.

Avoid locations where the printer is not level.

· The printer may fall and cause an injury.

· The quality of printing may deteriorate.

Do not obstruct the printer’ s air vents.

Do not place anything on the printer.

Do not cover or wrap the printer in cloth or blankets.

· Doing so could cause heat to build up and deform the case or start a

fire.

Avoid using the printer near a radio or TV set or from supplying it from

the same electric outlet as these appliances.

Avoid using the printer interconnected with a cable or cord that has

no protection against noise. (For interconnections, use shielded or a

twisted pair of cables and ferrite cores, or other anti-noise devices.)

Avoid using the printer with a device that is a strong source of noise.

· The printer may have an adverse effect on nearby radio or TV

transmissions. There may also be cases when nearby electrical

appliances adversely influence the printer, causing data errors or

malfunction.

Installed in any orientation other than those specified.

· Malfunction, failure, or electric shock may result.

Connect the printer to a ground.

· Electric leakage may cause an electric shock.

Do not connect the printer’ s ground to any of the following:

* Gas piping

· A gas explosion could result.

* Telephone line ground

* Lightning rod

· If lightning strikes a large surge of current may cause fire or

shock.

* Water pipes

· Plastic water pipes should not be used for grounding. (Those

approved by a Waterworks Department may be used.)

Before connecting or disconnecting the grounding lead to or from the

printer, always unplug it from the electric outlet.

—4—

PRECAUTIONS IN HANDLING THE PRINTER

WARNING

Please observe the following precautions for power source and power

cord:

Do not plug or unplug the power cord with a wet hand.

Use the printer only at the specified supply voltage and frequency.

Use only the specified AC adapter with the printer.

Check to make sure that the supply outlet from which the printer is

powered has a sufficient capacity.

Do not supply the printer from a power strip or current tap shared with

other appliances.

Do not plug the power cord into an electric outlet with dust or debris

left on the plug.

Do not use a deformed or damaged power cord.

Do not move the printer while its power is on.

· Neglecting to handle it properly may result in printer failure, emission

of smoke, fire, or electric shock.

· An overload may cause the power cord to overheat, catch fire, or the

circuit breaker to trip.

Do not allow anything to rest on the power cord. Do not place the

printer where the power cord may be stepped on.

Do not use or carry the printer with its power cord bent, twisted, or

pulled.

Do not attempt to modify the power cord unnecessarily.

Do not place the power cord near any heating device.

· Neglecting these cautions may cause wires or insulation to break,

which could result in electric leakage, electric shock, or printer failure.

If the power cord sustains damage, contact your dealer.

Do not leave things around the electric outlet.

Supply power to the printer from a convenient electric outlet, readily

accessible in an emergency.

· Pull the plug to immediately shut it down in an emergency.

Insert the power plug fully into the outlet.

If the printer will not be used for a long time, disconnect it from its

electric outlet.

Hold the plug and connector when plugging or unplugging the power

cord or signal cable after turning off the printer and the appliance

connected to it.

—5—

CAUTION

Caution label is attached in the position shown in the following figure. Carefully read

the handling precautions before using the printer.

THIS LABEL INDICATES THE

RISK OF BURNS DUE TO THE

HIGH TEMPERATURE OF THE

PRINT HEAD AND A RISK OF

BEING CUT BY THE MANUAL

AND AUTO CUTTERS WHILE

THE PAPER COVER IS OPEN.

Do not transport this printer with the paper roll inside.

· Printer failure or damage may occur.

To prevent possible malfunction or failure observe the following.

Avoid operating the printer without paper properly loaded.

Avoid the use of paper not complying with specifications.

· May result in poor print quality.

Avoid using torn pieces of paper or paper spliced with plastic adhesive

tape.

Avoid forcibly pulling already loaded paper by hand.

Avoid using a sharp pointed device to operate panel buttons.

Be sure to firmly insert the cable plugs into their mating sockets.

· A cross connection may damage the printer’ s internal electronics or

the host system’ s hardware.

Only use the printer with devices that have designated solenoid

specifications for the cash drawer interface connector.

· Neglecting this caution may result in malfunction or failure.

—6—

CAUTION

To prevent injury and printer failures from worsening, observe the following:

While the paper cover is open, be careful to not touch the manual

cutter that is in the paper eject slot.

Do not touch the printing surface of the thermal head.

Do not touch any of the moving parts (e.g., paper cutter, gears, active

electric parts) while the printer is working.

In case of trouble do not attempt to repair the printer. Ask TVSE

service for repair.

Be careful that the covers do not pinch your hands or fingers.

Be careful of the sharp edges on the printer. Do not allow them to

injure you or damage property.

· May result in electric shock, burn, or injury.

If the printer emits smoke, an odd smell, or unusual noise while

printing, immediately abort the current print session and

unplug the printer from the electric outlet.

DAILY MAINTENANCE

Observe the following precautions for daily maintenance.

When cleaning the printer, always turn it off and unplug it from the

electric outlet.

Use a soft, dry cloth for cleaning the surface of the printer case.

For severe stains, use a soft cloth slightly dampened with water.

Never use organic cleaning solvent such as alcohol, paint thinner,

trichloroethylene, benzene, or ketone. Never use a chemically

processed cleaning cloth.

To remove paper dust, use a soft brush.

CAUTION

· The thermal head is at a dangerously high temperature immediately after printing.

Allow it to cool off before starting maintenance work.

—7—

THE TABLE OF CONTENTS

1. GENERAL OUTLINE .................................................................... 9

1.1

1.2

Features .......................................................................................... 9

Basic Specifications..................................................................... 10

2. EXPLANATION OF PRINTER PARTS ....................................... 11

2.1 Printer Appearance...................................................................... 11

2.2 Inside the paper cover................................................................. 14

2.3 Other Built-in Functions .............................................................. 15

3. SETUP........................................................................................ 16

3.1 Connecting the AC Power Cord.................................................. 16

3.2 Connecting Interface Cables ....................................................... 17

3.3 Connecting the Cash Drawer ...................................................... 18

3.4 Precautions for Installing the Printer ......................................... 20

3.5 Partition for Paper Roll ................................................................ 21

3.6 Setting the DIP Switch on the Serial Interface Board ............... 22

3.7 Adjusting the Paper Near-end Sensor ....................................... 23

3.8 Setting Paper Thickness.............................................................. 24

3.9 Loading Paper .............................................................................. 25

3.10 Attaching the Power Switch Cover........................................... 26

3.11 Attaching the Interface Cover ................................................... 27

3.12 Removing the Interface Cover .................................................. 27

4. MAINTENANCE AND TROUBLESHOOTING........................... 28

4.1

4.2

4.3

4.4

4.5

4.6

Periodic Cleaning......................................................................... 28

Clearing a Cutter Lock (1)............................................................ 29

Clearing a Cutter Lock (2)............................................................ 30

Self-printing ................................................................................. 31

Hexadecimal Dump Printing....................................................... 32

Error Messages ............................................................................ 33

5. OTHER ....................................................................................... 35

5.1 External Views and Dimensions................................................. 35

5.2 Printing Paper .............................................................................. 36

5.3 Manual Setting of Memory Switches ........................................ 37

—8—

1. GENERAL OUTLINE

The RP-3200 line thermal printer series is designed for use with a broad array

of terminal equipment including data, POS, and kitchen terminals.

These printers have extensive features so they can be used in a wide range of

applications.

1.1 Features

High-speed (200 mm/s) printing.

Design so compact it can be installed anywhere (maximum 3-inch (83-mm)

paper roll size)

Choose from two models with either 3-inch (83/80 mm) or 2-inch (60/58 mm)

wide paper rolls.

Built-in power supply or AC adapter types available

Printer status and errors indicated by LED and a buzzer

Equipped with a fast and quiet cutter

Easy to clear cutter jams

Interchangeable interface

Built-in cash drawer kick-out interface

Memory switches make customization possible

Store user-defined characters and logos on user memory

Barcode and 2D barcode printing supported

2-color printing supported (when specified paper used)

Driver and utility software included

—9—

Item Specifications

Model RP-3200

Print method Line thermal dot print method

Print width *1 80 mm/640 dots, 72 mm/576 dots, 64 mm/512 dots, 54.5 mm/436 dots,

54 mm/432 dots, 52.5 mm/420 dots, 48 mm/384 dots, 45 mm/360 dots,

48.75 mm/390 dots, 68.25 mm/546 dots

Dot density 8 ⋅ 8 dots/mm (203 dpi)

Print speed 200 mm/s (fastest, print density 100%), 1600 dot-lines/s

Number of print

columns *2 — Maximum number of characters

(columns) Dot configuration

(dots)

Paper width

Font

83 mm 80 mm 60 mm 58 mm

Font A 53 48 36 35 12 ⋅ 24

Font B 71 64 48 46 9 ⋅ 17

Font C 80 72 54 52 8 ⋅ 16

Character size*3 Font A: 1.50 ⋅ 3.00 mm

Font B: 1.13 ⋅ 2.13 mm

Font C: 1.00 ⋅ 2.00 mm

Character type Alphanumeric, international, PC437/850/852/857/858/860/863/864/865/866/

WPC1252/katakana/Thai code 18

User memory 384 KB (capable of storing user-defined characters and logos)

Bar code types UPC-A/E, JAN (EAN) 13/8 columns, ITF, CODE39, CODE128, CODABAR (NW-7),

CODE93, PDF417, QR Code

Line spacing 4.25 mm (1/6 inch) (changeable using commands)

Paper roll +0 +0 +0 +0

Paper roll: 83 -1 mm/80 -1 mm/60 -1 mm/58 -1 mm ⋅ maximum ⎞83 mm

Paper thickness: 65-75 ⎧m (core tube diameter: inner 12 mm/outer 18 mm)

75-85 ⎧m (core tube diameter: inner 25.4 mm/outer 32 mm)

Interface parallel (IEEE 1284 compliant), USB

Cash drawer kick-out Supports 2 cash drawers

Buffer size 4 k bytes/45 bytes

Supply voltage DC 24 V ±5%

Power consumption Approximately 45 W (normal printing), 3 W (standby)

AC adapter *4

(36AD3)

Rated input: AC 100 to 240 V, 50/60 Hz, 150 VA

Rated output: DC 24 V, 2.1 A

Weight Approx. 2 kg

Outside dimensions 145 (W) ⋅ 192 (D) ⋅ 148 (H) mm

Operating temperature

and humidity

5 to 45°C, 10 to 90% RH (no condensation)

Storage temperature

and humidity

-20 to 60°C, 10 to 90% RH (no condensation)

Reliability Print head life: 150 km, 200 million pulses (at normal temperature and

humidity using recommended paper)

Auto cutter life: 2 million cuts (at normal temperature/humidity, using
