Ultra Start 15 SERIES Manuale utente

O

WNER S MANUAL

REMOTE VEHICLE STARTER

PAGE 14

Auxiliary Outputs

Auxiliary 5

(15xx series)

(16xx series)

Auxiliary 6

(15xx series)

(16xx series)

Mode 1

Mode 2

1. Press and hold and buttons simultaneously. The park lights will flash

and the horn (optional) will honk one time to confirm.

1. Press and hold the (left) button. The park lights will flash and the horn

(optional) will honk one time to confirm.

1. Press and hold and buttons simultaneously. The park lights will flash

and the horn (optional) will honk one time to confirm.

1. Press and hold the (right) button. The park lights will flash and the horn

(optional) will honk one time to confirm.

The doors will unlock (optional) as soon as the buttons

for the auxiliary output is pressed. The system will confirm with two

park light flashes and horn (optional) honks. Continue holding the

auxiliary output buttons until the system confirms the auxiliary output

with a park light flash and horn (optional) honk.

The system will confirm an auxiliary output with

one park light flash and horn (optional) honk without door unlock

(optional).

The outputs will be inactive when the ignition key is in the ON position.

The outputs will sta

y

active up to five seconds until the buttons are released.

* The auxiliary outputs have two program modes (see dealer).

(with unlock)-

(without unlock)-

NOTE:

5sec

Remote Transmitters and Antenna

REMOTE VEHICLE STARTER

O

WNER S MANUAL

PAGE 5

Program Button

LEDs

Active RF antenna with built in LEDs and Program Button.

OE series XR series 16xx series

NOTE:Remote transmitter s and antenna ma

y

not be exactl

y

as shown.
