TCX 805

Accessory Handset

OWNER'S

MANUAL

–2 –

Welcome

Congratulations on your purchase of the Uniden TCX805 accessory

handset and charger. This expansion handset is compatible with the

TRU8866 2-line base (model numbers may vary.) You can place a fully

featured cordless handset anywhere in your home where you have AC

power.

IMPORTANT

The TCX805 expansion handset will not operate unless it has been

registered to your main base. This manual describes how to set up and

connect your new handset; for more detailed instructions on operating

your new handset, refer to the owner's manual supplied with your main

base.

Backward / Forward Compatibility

Your phone is compatible with other Uniden 5.8GHz Digital Expandable

Systems. Compatible models include the Elite series (ELT560, ELBT585,

ELBT595), the CLX Series (CLX485 and CLX465), and the TRU8 series

(TRU8860, TRU8865, TRU8866, TRU8880, TRU8885, and TRU8888). The

Elite and CLX series bases contain advanced features that may not be

supported by this handset. Please visit our website at www.uniden.com

for feature comparisons.

Two-line operation is supported only when the handset

is registered to a two-line base.

Checking the Package Contents

Make sure you have received the following items in the package.

If any items are missing or damaged, contact Customer Service.

For answers to questions and to order genuine Uniden parts and

accessories 24 hours a day, visit our website at www.uniden.com.

Customer support is also available by calling 1-800-297-1023, Mon-Fri

7 a.m. to 7 p.m., Sat/Sun 9 a.m. to 5 p.m. CST. (Phone support is

closed on holidays.)

• Cordless Handset

•Charging Cradle

• AC Adapter (AD-0005)

(INPUT: 120V AC 60Hz)

(OUTPUT: 9V DC 210 mA)

• Battery Pack (BT-446)

(Capacity: 800 mAH, 3.6V)

•Beltclip

• This Owner’s Manual

• Other Printed Material

UU424BH(TCX805) OM.fm Page 2 Tuesday, June 21, 2005 9:37 AM

–3 –

Help for our Special Needs Customers

If you need special assistance due to a disability or have questions on

the accessibility features of this product, please call 1-800-874-9314

(voice or TTY).

Basic Setup

Install the Battery Pack

1Press down on the handset battery

case cover (use the finger indention

for a better grip) and slide the cover

downward to remove.

2Plug the battery pack connector

(red & black wires) into the jack

inside the battery compartment.

(The connector notches fit into the

grooves of the jack only one-way.)

Match the wire colors to the polarity

label in the battery compartment, and

push the connector in until you hear a

click.

3Make sure you have a good connection

by slightly pulling on the battery

wires. If the connection is secure, the

battery jack will remain in place.

4Place the battery case cover back on

the handset by sliding it upwards

until it clicks into place.

5Place the handset in the charging

cradle with the keypad facing forward.

•Use only the Uniden battery

(BT-446) supplied with your phone.

• Recharge your handset on a regular basis by

returning the handset to the charger after each

phone call.

Rechargeable Nickel-Metal-Hydride Batteries Must Be

Recycled or Disposed of Properly

UU424BH(TCX805) OM.fm Page 3 Tuesday, June 21, 2005 9:37 AM

–4 –

Connect the Charger

1Connect the AC adapter to the

DC IN 9V jack and to a standard

120V AC wall outlet.

2Set the charger on a desk or

tabletop, and place the handset

in the charger with the keypad

facing forward.

Make sure the

charge

LED

illuminates. If the LED does not

illuminate, check to see that the AC adapter is plugged in and that

the handset makes good contact with the charger's contacts.

Caution: To avoid risk of fire or shock, use only the supplied AD-0005

AC adapter. Do not use any other AC adapter.

4Charge the handset for 15-20 hours before using.

YOU NEED TO REGISTER THE TCX805 TO THE MAIN BASE BEFORE USE!

If the handset was registered to a different base, you

must de-register the handset before you can register it

to a new base. (See page 5.)

For Main Base Models TRU8860, TRU8865, TRU8866, TRU8880 and

TRU8885

1Be sure the handset battery is

fully charged.

2With the main base in standby

mode (i.e., not being used), place

the expansion handset in the main

base to begin registration.

3While the handset is registering,

Handset Registering

will

appear in the handset LCD. When

Registration Complete

displayed, the handset has been

registered to the base.

Registration Failed

appears, please try these steps

again.

TCX805

Handset

TCX805

Handset

Charger

Main Base

TCX805 Handset

Main Base

Charge the handset

for 15-20 hours.

Place the TCX805

handset in the main

base to register.

UU424BH(TCX805) OM.fm Page 4 Tuesday, June 21, 2005 9:37 AM

–5 –

For Main Base Model TRU8888 (corded base model)

1With the main base in standby mode (i.e. not being used), press the

MENU soft key on the base.

2Use the up/down key to select

HS Registration

, and then press

the OK soft key.

3Use the up/down key to select

4Base LCD screen will display the following prompt:

On handset press & hold "#" key for 2 sec

5On the handset, press and hold the #key until you hear a beep.

For Main Base Model ELT560

1Remove the battery compartment

cover from the back of the main base.

2Press and hold the Registration

button in the battery compartment.

3Keep pressing the Registration button

until the handset charge LED on main

base starts to blink.

4On the handset, press and hold the # key until you hear a beep.

For Main Base Models ELBT585, ELBT595, CLX465, and CLX485

1With the main base in standby mode (i.e. not being used), press

menu/select.

2Use the up/down key to select

System Setup

3Use the up/down key to select

4The base LCD screen will display the following prompt:

On handset, press & hold "#" key for 2 sec

5On the handset, press and hold the #key until you hear a beep.

De-register the handset

Press the MENU soft key. Scroll down to

Deregister HS

and press the

OK soft key. When the handset asks you to confirm, select

Yes

and

press the OK soft key.

Registration

button

UU424BH(TCX805) OM.fm Page 5 Tuesday, June 21, 2005 9:37 AM

–6 –

Installing the Beltclip

To attach the beltclip

Insert the beltclip into the holes on each side of the

handset. Press down until it clicks.

To remove the beltclip

Pull either side of the beltclip to release the tabs from the

holes.

Using Your Handset

Now that your new handset is registered, it can perform all the same

functions as the handsets originally included with your phone. With

your new handset, you can

• Transfer calls between handsets

• Use two handsets as an intercom

• Use two handsets as 2-way radios in DirectLink mode

• Use two handsets as a baby/room monitor

• Hold conference calls

See the owner's manual that came with your main base unit for

complete instructions on operating your new expanded digital phone.

You can also download owner's manuals from our website at

www.uniden.com.

•Two-line operation is supported only when the handset

is registered to a two-line base.

•The Elite and CLX series bases contain advanced

features that may not be supported by this handset.

Please visit our website at www.uniden.com for feature

comparisons.

UU424BH(TCX805) OM.fm Page 6 Tuesday, June 21, 2005 9:37 AM

–7 –

Controls & Functions

1. Handset Antenna

2. Beltclip Hole

3. Speakerphone Speaker and

Ringer

4.Handset Battery

Compartment

5. New Message LED

6. Handset Earpiece

7. LCD Display

8. soft Keys

9. cid/vol (volume up)

10. redial/p/vol (volume

down)

11.

/tone/<

12. speaker

13. intcom/hold

14. Headset Jack Cover

15. talk/flash

16. end

17. phonebook

18. #/>

19. /conference

20. Handset Microphone

21. Handset Charging

Contacts

UU424BH(TCX805) OM.fm Page 7 Tuesday, June 21, 2005 9:37 AM

–8 –

Reading the Display

Example of the standby mode display

ICON Appears

During DESCRIPTION

Standby/

Talk

Battery icons indicate the handset

battery status. This icon changes

depending on the battery status (empty,

low, medium and full).

(for two-line base model)

Standby The Ringer off icon indicates that ringer

is turned off.

(for two-line base model)

Standby/

Talk

The Line icon indicates the line in use

or the line received a new Caller ID

message(Line1 and/or Line2).

Talk The Mute icon appears when you mute

the handset.

Talk The Speaker icon appears when the

handset speaker phone is used.

Talk The Privacy icon appears when the

Privacy Mode is turned on.

Ringer off icon (when the ringer is off)/ day of

the week and time / battery icon

Handset ID and Banner

Number of new Caller ID calls received (If there

are no new Caller ID messages, the Handset ID

appears here.)

UU424BH(TCX805) OM.fm Page 8 Tuesday, June 21, 2005 9:37 AM

–9 –

Main Menu Options

Adjusting the Volume

• To adjust ringer volume, press the MENU soft key, select the Handset

Setup menu, and then the Ringer Volume submenu. Use or to

select "Hight", "Low", or "Off." Press the OK soft key.

• To adjust the earpiece or speaker volume, press the and keys

while the handset is on a call. The new setting will remain in effect

after the call has ended.

Submenu

Set TEL-LINE *

Edit Voice Mail **

Ringer Volume

Ringer Tones

Distinctive Ring

Auto Talk

Anykey Answer

Banner

Language

LCD Contrast

Key Touch Tone

Animation Screen

Room Monitor

Day & Time

CIDCW

Area Code

Dial Mode

Voice Mail Tone **

Security Code

Ring Time

Message Alert

Language

Call Screen

Main Menu

DirectLink Mode

Room Monitor

Handset Setup

Global Setup

Answ. Setup ***

Deregister HS

* Two-line base model only

** Caller ID base model only

*** Answering System base

model only

UU424BH(TCX805) OM.fm Page 9 Tuesday, June 21, 2005 9:37 AM

–10 –

Making and Receiving Calls

Using a Headset

Your phone may be used with an optional headset.

To use this feature, insert the headset plug into

the headset jack. Your phone is ready for hands-

free conversations. (Headset may be purchased by

calling the Uniden Parts Department or visiting the

web site. See page 2.)

Transferring Calls

1. To transfer a call, press intcom/hold. The call will be placed on

hold, and the display will show the list of available stations.

2. Select the station you want to transfer the call to and press the OK

soft key. To page all stations at once, select the ALL soft key.

3. When the other station answers, you can talk to the other station;

the call will still be on hold. If the other station connects to the

call, your handset will be disconnected.

If another station transfers a call to this handset, press talk/flash

to answer the transfer page. Press talk/flash again to connect to

the outside caller (the other station will be disconnected).

Making a call Remove the handset from the

charger. Dial the number you want

to call and press talk/flash. To

make a call with the

speakerphone, dial the number

and press speaker.

Answering a call Remove the handset from the

charger and press talk/flash. To

answer with the speakerphone,

press speaker.

Hanging up Press end.

Using Call Waiting If the call waiting tone sounds

while you are on the phone, press

talk/flash to speak to the waiting

caller. Use talk/flash to switch

back and forth between the callers.

Putting a Call on Hold Press intcom/hold to put the caller

on hold. Press talk/flash or

speaker to talk to the caller again.

UU424BH(TCX805) OM.fm Page 10 Tuesday, June 21, 2005 9:37 AM

Altri manuali per TCX 805

Indice

Altri manuali Uniden Cornetta

Uniden

Uniden DCX291 Manuale di servizio

Uniden

Uniden TCX 805 Manuale utente

Uniden

Uniden XDECT 8105WP Manuale utente

Uniden

Uniden DCX700 Manuale utente

Uniden

Uniden DCX170BT Manuale utente

Uniden

Uniden TCX4 Series Manuale utente

Uniden

Uniden D1484 series Manuale utente

Uniden

Uniden XDECT SSE07 Manuale utente

Uniden

Uniden XDECT 7005WP Manuale utente

Uniden

Uniden DSS7805 Manuale utente

Uniden

Uniden DCX220 Manuale utente

Uniden

Uniden XDECT 7005 Manuale utente

Uniden

Uniden DCX100 - DCX 100 Cordless Extension Handset Manuale utente

Uniden

Uniden TCX860 Manuale utente

Uniden

Uniden DCX170 Manuale di servizio

Uniden

Uniden DCX220 Manuale utente

Uniden

Uniden DCX 520 Manuale utente

Uniden

Uniden DECT 3005 Manuale utente

Uniden

Uniden WDECT 2355 Manuale utente

Uniden

Uniden DCX170BT Manuale utente

Uniden

Uniden DCX309 Manuale utente

Uniden

Uniden WDECT2380 Manuale utente

Uniden

Uniden XC631Plus Manuale utente

Uniden

Uniden DCX200 Series Manuale utente

Manuali Cornetta popolari di altre marche

Swissvoice

Swissvoice ePure HD Manuale utente

Philips

Philips TD6736/BH051P Manuale utente

ASCOM

ASCOM I62 - Manuale utente

LG-Ericsson

LG-Ericsson LIP-9010 Manuale utente

GE 1583 Manuale utente

iiNet

iiNet Handset Manuale utente

ASCOM

ASCOM 9p23 Manuale utente

AT&T

AT&T DLP70110 Manuale utente

AirCell

AirCell ST 3100 Manuale utente

Eaton

Eaton HHIR-LCD-PROG Istruzioni per il montaggio

Mitel

Mitel 112 Manuale utente

SBC

SBC SBC-381H Manuale utente

Mitel

Mitel 5602 Manuale utente

ASCOM

ASCOM d81 Messenger Istruzioni per l'installazione

SpectraLink

SpectraLink 7522 Manuale utente

Avaya

Avaya L100 Series Come usare

ooma

ooma HD2 Handset Manuale utente

Yealink

Yealink IPW56 Manuale utente
