Uniden WDECT 2345+1 Manuale utente

Corded Telephone and

Digital Answering System

with Wide Band Digital

Cordless Handset

OWNER'S MANUAL

WDECT 2345+1

WELCOME/ FEATURES 2

TERMINOLOGY 4

CONTROLS & FUNCTIONS 5

DISPLAY AND ICONS 7

SOFT KEY FUNCTION (BASE ONLY) 9

GETTING STARTED 10

BASICS 29

PHONEBOOK 40

CALLER ID 49

THE INTEGRATED ANSWERING DEVICE 55

MULTI- HANDSET FEATURES 70

ADDITIONAL INFORMATION 76

TROUBLESHOOTING 79

MEMORY LIST 83

INDEX 87

REMOTE OPERATION CARD 88

WARRANTY 90

Setting up the Phone 10

Expanding Your Phone 16

Changing the Digital Security Code 18

Installing the Beltclip 18

Optional Headset Installation 18

Main Menu Options 19

Setting Menu Options 20

Using Your Phone 29

Call Waiting 32

Placing a Call on Hold 32

Redialing a Call 33

Adjusting the Ringer, Earpiece and

Speaker Volume 34

Muting the Ringer 35

Mute Microphone 36

Tone Dialing Switch- over 36

Traveling Out of Range 37

Clarity Booster (Handset only) 37

Privacy Mode 38

Conferencing 38

Find Handset 39

Setting up the Phonebook 40

Viewing the Phonebook 44

Making Calls Using the Phonebook 45

Speed Dialing 46

Editing or Erasing a Stored Name, Phone Number,

Distinctive Ring and Speed Dial 46

Copying Phonebook Locations 47

Caller ID and CIDCW

(Caller ID on Call Waiting) 49

The Integrated Telephone Answering Device 55

Turning the Answering System On/ Off 61

Setting Your Outgoing Message (Greeting) 61

New Message LED 62

Using Your Answering System 62

Remote Operation 66

Multi- Handset Features 70

Using DirectLink Mode 70

Intercom 72

Room/ Baby Monitor 75

Note on Power Sources 76

General Information 78

Troubleshooting 79

Liquid Damage 82

Contents

[1]

Congratulations on your purchase of the Uniden Digital Expandable Cordless Telephone

System! This is a "Corded/Cordless" Telephone unit. The corded handset (on base) can

make/ receive calls during power failure. When the base unit is connected to AC power

and a telephone line, it can support up to four cordless handsets. You can now place a

fully- featured cordless handset anywhere in your home or office where AC power is

available to connect the handset chargers. Extra handsets also allow you to establish a

4- way conference call among two handsets, the base speakerphone, and an

outside line.

Integrated Answering Device

Caller ID* at Handset and Base

Backward/Forward Compatibility

During Power Outage, Make and Receive Calls Using Corded Handset

Dual Keypad with LCD Screen at Base

Four Multi-Handset Expandability

Hands-Free Duplex Speakerphone at Handsets and Base

100 Programmable Memory Locations at Handsets and Base

Intercom/Call Transfer Between Handsets or Handset and Base

20 Distinctive Ring* Options (10 Tones/10 Melodies)

Mute/Hold

Do Not Disturb (DND)

Two-way Communication between Handsets** Anywhere without the Base

Room/Baby Monitoring

Battery Level Indicator

Clock Display

Note: Illustrations in this manual are used for explanation purposes. Some

illustrations in this manual may differ from the actual unit.

* Caller ID, Distinctive Ring features require subscription to the Caller Display service from your network

supplier. A fee normally applies for this.

** DirectLink mode: Optional additional cordless handset required for this feature.

Welcome

Features

[2]

This series features and AutoTalk allows you to answer a call by just

removing the handset from the cradle so you don't have to waste time pushing buttons. AutoStandby

allows you to hang up by simply returning the handset to the cradle.

To protect you against mis-billed calls that might result from your phone being activated by other

equipment, this series has digital security, which automatically selects one of about

130,000 digital security codes for the handset and base.

Built in sound quality which provides life-like conversations.

With mode, you can use two or more handsets as radio transceiver (walkie-talkies).

Be sure to visit our web site: www.uniden.com.au, www.uniden.co.nz

Your phone may be compatible with other Uniden Digital expandable systems

Look for the technology icon on our boxes!

AutoTalk AutoStandby

Random Code

IntegriSound

DirectLink

™™

™

[3]

Terminology

Standby Mode - talk/ flash

Talk Mode - talk/ flash

The handset maybe sitting on or off the cradle, but is NOT in use. or

has not been pressed. The corded base handset is on the base and

on the base has not been pressed. No dial tone is present.

The handset is off the cradle and or has been pressed, or pick

up the corded base handset and on the base is pressed, enabling a dial

tone.

[4]

Controls & Functions

1. Handset Antenna

2. Headset Jack Cover

3. Beltclip Hole

4. Hands-Free Speaker

5. Handset Battery Compartment

6. New Message LED

7. Handset Earpiece

8. LCD Display

9. (P.20 & 41)

10. (ring) Key (P.34 & 20)

a. ringer volume control

b. scroll keys for display screen

11. Key (P.36 & 41)

12. Key (P.30 & 33)

13. Key (P.30)

14. Key (P.20 & 67)

15. Key (P.51)

16. Key (P.29 & 32)

17. Key (P.31)

18. / Key

19. Key (P.40)

20 Key (P.32 & 72)

21. Handset Microphone

22. Handset Charging Contacts

menu /del Key

/vol / /

/tone

redial/pause

speaker

select /

call id

talk/flash

end

phonebook

. hold /transfer/int’com

(P.41)

[5]

23. (P. 62)

24.In use LED

25.New Message LED

26. (P. 51)

27. Corded Base Handset

28. Base Speaker

29. Curl Cord

30. (P. 64)

31. (P. 61)

32. /DND

LED (P. 35)

33. (P. 36 and 41)

34. LCD Display

35. Base Antenna

36.

(volume up/ down)

(P. 34 and 20)

37. (P. 9)

38. (P. 40)

39. (P.30 and 33)

40.

(P. 72 and 32)

41. (speaker) LED (P. 30)

42. mic (microphone)

43. (P. 41)

44. DC IN 9V Jack

45. TEL LINE Jack

46. Charging Contacts

47. Charge LED

48. DC IN 9V Jack

play/ stop

cid/ exit

delete

answer on/ off

do not disturb

tone

soft

phonebook

pause/redial

transfer/ int'com/ hold

volume

Keys

[6]

Display and Icons

Example of the standby mode display

!Handset

* appears if you have a new message.

appears if you turn your answering system off.

** appears when the message storage is full.

appears if you set your answering system to announce only.

Standby/Talk

Day of the week and time/battery icon

Handset ID and Banner

Number of new Caller ID calls received

Ringer off icon (when the ringer is off)

*Status of your answering machine Day of the week and time

**Number of message Number of new Caller ID calls

received

icons indicate the handset battery status.

This icon cycles depending on the battery status (full,

medium,low,and empty).

Standby off icon indicates that ringer is turned off.

• Base

Battery

Ringer

:OFF

ANSWER

NEW

OFF

FULL

Announce

ONLY

:OFF

SUN 12:00A

Handset #1

New: 5

[7]

Talk icon appears when you mute the handset or

the base.

Talk icon appears when the handset speaker

phone is used.

Talk icon appears when the Clarity Booster

feature is in use.

Talk icon appears when the Privacy Mode is

turned on.

Talk icon appears while recording a conversation.

Mute

Speaker

Booster

Privacy

Record

[8]

Soft Key Function (Base only)

"Soft" keys are keys that change function during the operation of the phone. There are three soft keys

on the base. Soft keys allow you to:

Access the main menu

Find a handset

Record Voice Memo

Complete information on the features controlled by the soft keys can be found under each feature.

The function of each soft key is determined by the icon that appears directly above it.

In standby mode

Base

Base (speaker phone) (Corded base handset)

SUN 12:00A

New CID: 5

FIND HS RECORD MENU

SP-Phone

FLASH RECORD MENU

0:00

Talk

FLASH MENU

0:00

[9]
