Uniden UH755 Series Manuale utente
UH755 Series
Handheld UHF-CB Transceiver
For more exciting new products please visit our website:
Australia: www.uniden.com.au
SPLASHPROOF: IP54
Uniden’s UH755 radio is designed to meet the water & dust ingress
standard of IP54.
This Means:
Beingdenedasabletowithstandwatersplashesfromanydirection.
TheUH755willonlymeetthisratingiffullyassembledandall
knobs,coversandttingsarewellmaintainedandcorrectlytted.
Thismeansthattheaccessorycoverisfullyclosed,and
thebatterypackandantennaareattachedandsecurely
fastened.
LITHIUM ION BATTERY PACK WARNING
• ThisequipmentcontainsaLithiumIonBatteryPack.
• TheLithiumIonBatteryPackcontainedinthisequipmentmay
explodeifdisposedofinare.
• Donotshort-circuittheBatteryPack.
• DonotchargetheLithiumIonBatteryPackusedinthisequipmentin
anychargerotherthantheonedesignedtochargethisBatteryPack.
UsinganotherchargermaydamagetheBatteryPackorcausethe
BatteryPacktoexplode.
• LithiumIonbatteriesmustbedisposedofproperly.
NOTE
USER LICENSE INFORMATION
ThecitizenbandradioserviceislicencedinAustraliaby
ACMARadio-communications(CitizenBandRadio
Stations)ClassLicenceandinNewZealandbyMBIE
GeneralUserLicenceforCitizenBandRadioand
operationissubjecttoconditionscontainedinthose
licenses.
2
Warning
UNIDEN UH755 HandheldUHF-CBTransceiver
Introduction
Features 4
Included in your Package 5
OptionalAccessories 5
Controls and Indicators 6
Getting Started
AttachingtheAntenna 7
AttachingtheBeltclip 7
AttachingtheBatteryPack 8
ConnecttheDrop-inChargerwithACAdaptor 9
ChargingtheBatteryPack 9
BatteryLevelDisplay&AutomaticBatterySave 10
AccessoryJack(SPKR/MIC)Cover 10
ConnectingtheOptionalSPKR/MIC 10
Operation
PowerOn/Off 11
Volume 11
SelectingaChannel 12
InstantChannelFunction(PriorityChannel) 12
HowtoTransmitandReceive|High/LowTransmitPower 13
Squelch 14
CallFunction 15
UsingaRepeaterChannel 15
ToOperateUH755inDuplexMode 16
Scanning 17
WhatisOpenScan(OS)Mode? 17
WhatisGroupScan(GS)Mode? 17
Add/RemoveChannelsfromSCANMemory 18
ToStartChannelSCAN 18
MenuFunctions 20
CTCSS/DCS 20
BCL(BusyChannelLockout) 21
VOX(Built-inVoiceActivatedCircuit) 22
CallTone(SelectingaCallTone) 22
Scramble(VoiceScramble) 22
Compander 23
RogerBeep 23
KeyBeep 24
Backlight(Timer) 24
KeyLock 24
CTCSS & DCS Codes and Frequencies 25-26
UHF-CB Channel Guidelines, Channels & Frequencies 27-29
Warranty 30
3
Contents
UNIDEN UH755 HandheldUHF-CBTransceiver
4
Introduction
UNIDEN UH755 HandheldUHF-CBTransceiver
TheUH755isanIP54splashproof,portabletwo-wayUHF-CBradio.
ThishandheldUHF-CBradioisdesignedtogiveconsistent,outstanding
performanceinmanyconditionsandsituations.Toensurethatyougetthe
mostfromtheUH755features,pleasereadthisoperatingguidecarefully
beforeusingtheunit.
FEATURES
• NarrowBand(NB)80ChannelUHF-CBRadio1
• 5W Max TX Power
• 1W/5WSwitchableTXPower
• Splashproof(meetsIP54splashproofspecications)2
• NegativeLCDDotMatrixDisplaywithBacklighttimer
• 50Built-inCTCSSand104DCScodes
• DuplexModeforRepeaterAccess1
• One-touchInstantChannelkey
• 10CallTones
• OpenScanwithprogrammableCHmemory
• GroupScanwithPriority(InstantCH)Watch
• BusyChannelLockoutFunction
• VOXFunction
• VoiceScramble
• AudioCompander
• KeyBeep
• RogerBeep
• KeypadLock
• AccessoryJackforoptionalHeadsetorSpeakerMIC
• RechargeableLithium-lonBattery
• LowBatteryAlert
• BatterystrengthIndicator
• AutoBatterySave
¹ Refertopage28-page29forchannelinformation
2 TheUH754radiomeetssplashproof(IP54)specicationsonly
whenthebattery,theantennaandspeakerMICjackcaparecorrectly
installed.Note:TheUH755doesnotretainitsIP54ratingwhenan
accessoryEarpieceorSpeakerMICisconnected.
NOTE
Ifanyoftheseitemsaremissingfromthebox,contactyour
placeofpurchase,immediately.
Optional Accessories
• SpeakerMic
• EarpieceMic
VisittheUH755pageonthewebsiteformoreinformationonthe
availability&rangeofoptionalaccessories;
www.uniden.com.au
5
Included in your Package
UNIDEN UH755 HandheldUHF-CBTransceiver
Items UH755 UH755-2DLX
UH755UHFRadio 1 2
LithiumBattery
(1500mAh)
12
Antenna 1 2
Beltclip 1 2
Drop-InCharger 1 2
ACAdaptor 1 2
Cig-LeadAdaptor - 2
SpeakerMic - 2
EarpieceMic - 2
SoftCarryCase -1
Owner’sManual 1 1
6
Controls and Indicators
UNIDEN UH755 HandheldUHF-CBTransceiver
A SCRVoiceScrambleOn
B VOXVoiceActivationOn
C HI /LOTXPowerLevel
D INSTInstantChannel
E DUPDuplexOn
F MEMChannelisinMemory
G Channel
H COMAudioCompanderOn
I Keylock
J BatteryLevelIndicator
K OS/GSOpenScan/GroupScan
L CTCSS/DCSandcodenumber
M SCANScanning
N Transmit/ReceiveIndicator
1
2
5
6
7
3
4
12
8
9
10
11
13
14
15
16
17
18
1 Antenna
2 Beltclip
3 Battery
4 BatteryReleaseClip
5 [PTT] (PushtoTalk)Key
6 InstantChannelKey
7 [1/5 W] TransmitPowerkey/
[CALL]CallTonekey
8 Microphone
9 [MENU]Key
10 [CHANNEL] /MenulistChange
11 [ON/OFF VOL] Knob
12 Transmit/ReceiveLED
13 AccessoryJack&Cover
14 Speaker
15 LCDDisplay
16 [SCAN] /[MEM](memory)key
17 [ ] Channel/MenulistUPkey/
[OS/GS] OpenScan/GroupScan
select
18 [ ] Channel/MenulistDOWN
key/[LOCK] Keylock
UH755 Display Example r2
A
D
H
L
N
M
BI
J
K
G
F
C
E
7
Getting Started
UNIDEN UH755 HandheldUHF-CBTransceiver
Attaching the Antenna
TheUH755comeswithaprecisiontuned
477MHzantennaforUHF-CBuse.
AttachtheantennatotheUH755.
Besuretheantennaisrmlyseated.
Attaching the Beltclip
The belt clip may be pre-installed for convenience.
To attach the belt clip:
1.Alignthebeltclipoverthe2screwholes
onthebackoftheUH755body.
2.UseasuitablePhilipsscrewdrivertofasten
the2beltclipscrewstotheUH755body.
To remove the belt clip:
1.UseasuitablePhillipsscrewdrivertoloosen
the2beltclipscrewstoreleasethebeltclip
fromtheUH755body.
8
Getting Started
UNIDEN UH755 HandheldUHF-CBTransceiver
Attaching the Battery Pack
1.Ifthebeltclipisattachedtothe
radio,pressthetopofthebeltclip
toleverthebottomofthebeltclip
upwhileslidingthebatterypack
ontothebackoftheradio.Itwill
onlytinoneway.
2.Pushbatteryallthewayupuntilit
thebatterylatchatthebottom
locksintoplace.Besurethe
batterypacktstightlyagainstthe
UH755body.
CAUTION
AvoidexposingtheLithiumIonbattery,attachedor
unattachedtotheradio,indirectsunshine,heatedcars,or
inareaswithtemperaturesbelow–20°C(–4°F)orabove
+60°C(+140°F).
Exposingthechemicalscontainedwithinthebatterypackto
temperaturesabove+60°C(+140°F)maycausethebattery
torupture,failorreduceperformance.
Incaseofexposuretocellcontents,washtheaffectedarea
thoroughly,andseekmedicalattention.
Additionalbatterycautionsshouldbeappliedasdescribed
onpage2.
9
Getting Started
UNIDEN UH755 HandheldUHF-CBTransceiver
Connect the Drop-in Charger with AC Adaptor
PlugoneendoftheACadapterintoawalloutletandtheotherendinto
thedrop-incharger.
Ifyouusethedrop-inchargerinamobilevehiclewith12VDCpower,
usetheoptionalcig-leadadaptor.
Whenthechargerispowered,theLEDilluminatesgreen.
Charging the Battery Pack
YourradioispoweredbyaspeciallydesignedLithiumIonbatterypack.
• BeforeoperatingtheUH755,chargetheLithiumIonbatterypackfor5
hourswithoutinterruptioninthedrop-incharger.
NOTE
Fortheinitialbatterycharge,makesuretheradioisofffor
optimumcharging.
1.PlacetheUH755inthedrop-incharger.
2.Iftheradiobatteryischarging,theLED
illuminatesredandstayson,untilfully
charged,thenitilluminatesgreen.
• Thechargerwon’toverchargethebatterypack.
Whenchargingiscompleted,thechargeLED
changescolourfromredtogreen.
• YoucanmonitorincomingcallswhiletheUH755
isinthedrop-incharger.
• Do not transmit when the UH755 is in the drop-in charger!
10
UNIDEN UH755 HandheldUHF-CBTransceiver
Getting Started
Battery Level Display
LEVEL5 Battery100%full
LEVEL4 Batteryapprox.75%capacity
LEVEL3 Batteryapprox.50%capacity
LEVEL2 Batteryapprox.25%capacity
LEVEL1 Batterylow
NOTE
Rechargethebatteryatanytime.Fromempty,thebattery
willtakeupto5hourstofullycharge.
BatteryLife:35Hours(Typical)
ThisisbasedonthefollowingDutyCycle:
Transmit(LowPower) 5%
Receive 5%
Stand-by 90%
Automatic Battery Save
TheAutomaticBatterySavefeatureextendsthebatterylifebyswitching
topowersavemodeifitremainsoutofoperationfor10seconds.This
featureautomaticallyactivatesduringstandbymode(RXmodewithout
asignal).
Accessory Jack (SPKR/MIC) Cover
MakesuretheSPKR/MICjackcoverisrmlypushedintomaintain
splashproofrating.
Connecting the Optional SPKR/MIC
ReleasetheSPKR/MICjackcovertoplugintheSPKR/MIC.
UH755 Battery Levels
