UniGuard UM666A Manuale utente

UniGuard Technology Limited

- - www.uniguardgps.com

Magnetic GPS Tracker

User Manual

UM666A

Attention:

Charge is forbidden.

24Hrs per locate: 3 Years (Default)

Text message: 109# (Change reply to English language)

UniGuard Technology Limited

- - www.uniguardgps.com

1 GPS Tracking System Introduction

Portable GPS Tracker UM666A integrates GPS and GSM functions, which could

send vehicle location and status to mobile and Internet. It utilizes GPS and LBS double

locating. Its advantage is that the builtin battery can last 3 years at reporting interval

every 24hrs. No wires connection. Place and Work. The system structure is as below:

UniGuard Technology Limited

- - www.uniguardgps.com

2 Product Description

2.1 Specification

Content

Specifications

Dimensions

80*68*23 mm

Weight

133g

Network

GSM/GPRS

Band

850/900/1800/1900Mhz

GPS chip

UBLOX-7020

GSM Module

MTK6260D

GPS sensitivity

-159dBm

GPS accuracy

10m

Time to First Fix

Cold status 45-120s

Warm status 35s

Hot status 1s

Battery

Non-rechargeable dry battery

6000 mAh

Standby

3 years

Storage Temperature

-40 to 85 ℃

Operation Temp e r a t u r e

-20 to 55 ℃

Humidity

5%-95% non-condensing

UniGuard Technology Limited

- - www.uniguardgps.com

2.2 Picture and main functions:

3 Commands

Function

SMS command

Query current location

G1234

Set Domain and Port

IP www.gpspos.net 8000

Set APN

apn123456 aaa bbb ccc

Set Admin number

101#Tel# (e.g. 101#150123456#)

Check Device Status

cxzt

Restart Device

UniGuard Technology Limited

- - www.uniguardgps.com

Working Mode explanation:

【24HRS Tracking】: Device every 24 hours wakeup 1 time to send GPS data

Send command: WT24,TimeA,TimeB

E.g: WT24,1212,0800

Device starts 24hrs interval tracking at 12:12pm, and device currently wakes up at

8:00am.

【99HRS Tracking】: Device every 99 hours wake up 1 time to send GPS data

Send command: WT99,TimeA,Timeb

E.g.: WT99,1815,1345

Device starts 99hrs interval tracking at 18:15pm, and device currently wakes up at

13:45pm.

【999HRS Tracking】: Device every 999 hours wake up 1 time to send GPS data

Send command: WS099901,TimeA,TimeB

WS099901,1500,1345

Device starts 999hrs interval tracking at 15:00pm, and device currently wakes up at

13:45pm.

【Continuous Tracking】： Device keeps sending GPS data to server at set interval.

This command is only used for emergency, otherwise it consumes power fast.

Send command: DWX X=5~300

E.g. DW005, device shall work continuously for 5 mins and then go to 24Hr sleep

UniGuard Technology Limited

- - www.uniguardgps.com

mode.

DW000 is to activate continuous tracking forever.

4 Web Tracking

5.1Login www.gpspos.net to start web tracking service with your own

account

5.2 Download APP: Search GPSPOS at Appstore or Google Play.

6 Cautions

6.1 Keep the unit dry.

6.2 Don’t use & store the unit in dusty places.

6.3 Don’t put the unit in overheated or overcooled places.

6.4 Handle carefully. Don’t vibrate or shake it violently.

6.5 Clear the unit with a piece of dry cloth.

6.6 Don’t paint the unit.
