Unitron Latitude Moda 13 Manuale utente
Latitude™
BTE Guide
Moxi™13 / Moda™13
Guide
d'utilisation
LatitudeMC
MoxiMC 13
et
LatitudeMC
ModaMC 13
5773-Moxi13Moda13_BILING.qxd:360 BTEgd_eng 9/21/09 1:51 PM
5773-Moxi13Moda13_BILING.qxd:360 BTEgd_eng 9/21/09 1:51 PM
Table of Contents
Your Latitude™ Hearing Instruments .............................1
Overview of your Latitude™ Hearing Instrument ..........2
Features of your Latitude™ Hearing Instrument ...........4
Putting your Hearing Instruments on your Ears .............5
Turning your Hearing Instruments On and Off ..............6
Battery Information.........................................................7
Operating Instructions....................................................9
Using the Telephone ...................................................13
Caring for your Hearing Instruments.............................16
Cleaning your Hearing Instruments ..............................17
Signature Features of your Latitude™ Hearing
Instruments................................................................20
Assistive Listening Devices...........................................22
Warnings.......................................................................23
Troubleshooting Guide .................................................26
5773-Moxi13Moda13_BILING.qxd:360 BTEgd_eng 9/21/09 1:51 PM
Table des matières
Vos instruments auditifs LatitudeMC ..............................29
Aperçu de votre instrument auditif LatitudeMC..............30
Caractéristiques de votre instrument
auditif LatitudeMC ........................................................32
Mise en place de vos instruments auditifs
sur vos oreilles...........................................................33
Mise en marche et arrêt de
vos instruments auditifs ...........................................34
Informations sur la pile ................................................35
Instructions d'utilisation ..............................................37
Utilisation du téléphone ...............................................41
Entretien de vos instruments auditifs .........................44
Nettoyage de vos instruments auditifs .......................45
Fonctions distinctives de votre instrument
auditif LatitudeMC .......................................................49
Instruments d'aide à l'écoute ......................................51
Avertissements .............................................................52
Guide de dépannage ....................................................56
5773-Moxi13Moda13_BILING.qxd:360 BTEgd_eng 9/21/09 1:51 PM
Your Latitude™ Hearing Instruments
Hearing Healthcare Professional: _______________________
___________________________________________________
Telephone: _________________________________________
Model:_____________________________________________
Serial Number: ______________________________________
Replacement Batteries: Size 13
Warranty: __________________________________________
Program 1 is the Automatic Program
((Available with Latitude™16 and 8 only)
Program 2 is the manual program for: ___________________
Program 3 is the manual program for: ___________________
Program 4 is the manual program for: ___________________
Date of Purchase:____________________________________
1
5773-Moxi13Moda13_BILING.qxd:360 BTEgd_eng 9/21/09 1:51 PM
Overview of your Latitude™ Hearing
Instrument
The diagrams below identify some of the components
on your hearing instruments. Have your hearing
healthcare professional place a check beside the
diagram that best describes your hearing instrument
style and attachment.
2
Moda™13 with earmold
Moda™13 with slim tube and dome
1
2
3
4
8
9
1
2
3
4
6
5
7
Moda™13 Legend
1 Microphone and
Microphone Shield
2 Battery Door/
On & Off Switch
3 Program Button or
Volume Control
(depending on your
customized fitting)
4 Toggle for volume
control or
smartFocus™
(depending on your
customized fitting)
5 Tube
6 Dome
7 Retention Piece
8 Earhook
9 Earmold
Moda™13 Attachment Style (check one)
5773-Moxi13Moda13_BILING.qxd:360 BTEgd_eng 9/21/09 1:51 PM
3
Moxi™13 Legend
1 Microphone and
Microphone Shield
2 Battery Door/
On & Off Switch
3 Program Button or
Volume Control
(depending on your
customized fitting)
4 Toggle for volume
control or smartFocus™
(depending on your
customized fitting)
5 Tube
6 Speaker unit
7 Shell
8 Dome
9 Retention Piece
Moxi™13 with Shell
Moxi™13 with Dome
1
2
3
4
6
5
7
1
2
3
469
5
8
Moxi™13 Attachment Style (check one)
My hearing instrument has (check all that apply)
smartFocus™Toggle Push Button Program Button
Volume Control Toggle Push Button Volume Control
duoLink Binaural Phone
Optional Accessories (check all that apply)
Smart Control uDirect™
See Smart Control and uDirect User Guides for more information.
5773-Moxi13Moda13_BILING.qxd:360 BTEgd_eng 9/21/09 1:51 PM
4
Features of your Latitude™ Hearing
Instrument
Latitude™hearing instruments come equipped with
the following features:
• Automatic listening program for Latitude 16 and 8,
and 3additional manual program. Latitude 4has 4
manual programs.
• SmartFocus™or Speech Enhancement, with
personal adjustments for Clarity and Comfort
settings where available
• Wireless capability with duoLink
• Optional wireless connectivity to other devices
It may take some time for you to fully adjust to your
new hearing instruments. In the beginning, do not feel
as though you need to wear them for longer than is
comfortable. Depending on your previous experience
with hearing instruments you can increase wearing
time gradually until you have fully adjusted to them.
Eventually, you should wear your Latitude hearing
instruments all day every day.
Please consult your hearing healthcare professional
regarding any adjustments you may require to ensure
that you are happy with your hearing instrument. For
instance, pitch and loudness of the beeps can be
adjusted or turned off entirely. Also note that this is a
general guide and your hearing healthcare
5773-Moxi13Moda13_BILING.qxd:360 BTEgd_eng 9/21/09 1:51 PM
5
professional may have enabled or disengaged certain
features depending on your requirements.
Putting your Hearing Instruments on
your Ears
Your Latitude hearing instruments may be color-coded
red for your right ear and blue for your left ear. This
color indicator is located inside the battery door with a
small colored dot.
Latitude™ with Domes
1. Hold the tube where it attaches to
the dome and gently push the
dome into your ear canal. The tube
should lie flush against your head and not stick out.
2. Place Latitude over the top of your ear.
3. Place the retention piece in your ear so it rests at
the bottom of the opening of your ear canal.
Latitude™ with Earmolds/Shells
1. Carefully insert the
earmold/shell into
your ear. The earmold/
shell should fit into
your ear snugly and comfortably. The tube should
lie flush against your heard and not stick out.
2. Place Latitude over the top of your ear.
5773-Moxi13Moda13_BILING.qxd:360 BTEgd_eng 9/21/09 1:51 PM
Turning your Hearing Instruments On
and Off
Your hearing instruments have a three-position battery
door that acts as an off/on switch and that allows
access to the battery compartment.
ON:
To turn the hearing instruments on, close the battery door
fully. Note: It may take 5 seconds before the
hearing device turns on. Your hearing healthcare provider
can additionally increase the start up delay if required.
OFF:
To turn the hearing instrument off, partially open the
battery door. This position also allows excess moisture
to vent away from the battery compartment.
on off open
Note: When turning your hearing instrument
on and off while it is on the ear, grasp the top and
bottom of the instrument with your index finger
and thumb. Use the index finger of your opposite
hand to open and close the battery door.
6
5773-Moxi13Moda13_BILING.qxd:360 BTEgd_eng 9/21/09 1:51 PM
