Universal Remote Control Easy Clicker UR3-SR3 Manuale utente

Universal Remote Control, Inc.

www.universalremote.com

UR3-SR3

Operating Manual

For Easy Clicker

This remote control is designed to operate most Digital

and Analog Cable Boxes, as well as TVs, and a VCR or

DVD player.

Introduction

Install two

AAA alkaline batteries

as shown here

Before you program or operate the remote control, you

must install two new AAA alkaline batteries.

STEP1 Remove the battery compartment cover from the

back of your remote control.

STEP2 Check battery polarity carefully, and install the

batteries as shown in the illustration below.

STEP3 Replace the battery compartment cover.

Replacing Batteries

Button Functions

Programming the Remote Control.

A. Manual Pr

A. Manual Programming

ogramming

The remote control can be programmed by entering a three-

digit code number that corresponds to particular brands and

models of equipment. The three-digit code numbers are listed

in the code tables sections of this instruction manual.

*Note : In this section, when you are instructed to press a

[DEVICE] button, that means you should press either

the CBL, TV, or DVD button, depending on which

device you are programming the remote to operate.

STEP1 Turn on the equipment that you want the remote

control to operate Cable Box, TV and DVD(VCR).

STEP2 Press the [DEVICE] button and the [OK/SEL]

button simultaneously for three seconds. The

corresponding device LED will turn on indicating

that it is ready to be programmed. The LED will

remain on for 20 seconds. The next step must be

entered while the LED is on.

STEP3 Point the remote control toward the equipment

and enter the three-digit code number assigned

to your brand from the code tables. If there are

more than one three-digit number listed for your

brand, try one code number at a time until your

equipment turns off.

*Note : You can verify that you have selected the correct

code by pressing the [MUTE] button. The

equipment should turn on or off.

STEP4 Store the three-digit code by pressing the same

[DEVICE] button once again. The device LED will

blink twice to confirm that the code has been

stored.

*Note : Try all the functions on the remote control. If any

of the functions do not operate as they should,

repeat the instructions from Step 2 using the next

three-digit code number from the same brand list.

B. Auto Sear

B. Auto Search Method

ch Method

If none of the three digit code numbers assigned to your

brand of equipment works, or the code table does not list

your brand, you can use the Auto Search Method to find the

correct three-digit code number for your equipment by

following steps:

STEP1 Turn on the equipment that you want the remote

control to operate (Cable Box, TV, VCR, or DVD).

STEP2 Press the [DEVICE] button and the [OK/SEL]

button simultaneously for three seconds. The

device LED will turn on indicating that it is ready

to be programmed. The LED will remain on for 20

seconds. The next step must be entered while

the LED is on.

STEP3

Press the [CH+] or [CH-] button one at a time or

keep it pressed. The remote will emit a series of

Power ON/OFF code signals. Release the [CH+] or

[CH-] button as soon as the equipment turns off.

*Note : You can verify that you selected the correct code

by pressing the [MUTE] button. The equipment

should turn On or Off.

STEP4 Press the same [DEVICE] button to store the

code. The Device LED will blink twice to confirm

that the code has been stored.

C. T

To find the Thr

o find the Three-Digit Code that W

ee-Digit Code that Was

Programmed using the Auto Sear

ogrammed using the Auto Search

Method

STEP1 Press the appropriate [DEVICE] button and the

[OK/SEL] button simultaneously for three

seconds. The device LED will turn on for 20

seconds. The next step must be performed while

the LED is on.

STEP2 Press the [INFO] button. The device LED will blink

a number of times indicating the number of each

digit for the code. Each digit is separated by a

one second interval of the LED being off.

Example : One blink, then three blinks, then eight blinks

indicates the code number 138.

*Note : Ten blinks indicates the number 0.

Programming a Second TV to the DVD Button

ogramming a Second TV to the DVD Button

STEP1 Press the [DVD] button and the [OK/SEL] button

simultaneously for 3 seconds. The DVD LED will

turn on for 20 seconds. The next step must be

performed while the LED is on.

STEP2 Press the [TV] button.

STEP3 Point the remote control toward the TV and enter the

three-digit code for your TV from the TV codes table.

STEP4 Store the three-digit code by pressing the [DVD]

button. The device LED will blink twice to confirm

that the code has been stored.

E. Pr

E. Programming for Advanced Functions.

ogramming for Advanced Functions.

In the CABLE device mode, the A,B,C,D and blank macro

buttons can be programmed to act as a 'Macro' or

Favorite Channel button. This allows you to program up to

five 2-digit channels, four 3-digit channels or three 4-digit

channels that can be accessed with on button press.

*Note : The A,B,C and D buttons are not programmable

if you have a Digital Cable Box made by Pace,

Pioneer or Scientific-Atlanta.

STEP1 Press the [CBL] button to select the CBL mode.

STEP2 Press the [MACRO] button and [OK/SEL] button

simultaneously for 3 seconds. The [CBL] button

will turn on for 20 seconds.

STEP3 Enter the the 2, 3 or 4-digit code for the channel you

want programmed first (for example, 007) using the

Number Pad, then press the [STOP] button. Then

enter the code for the next channel (for example,

050), then press the [STOP] button. Repeat this

process for the third channel. The [CBL] button will

blink once for each channel entered.

STEP4 Press the [CH+] button to store the channels that

were selected. The [CBL] button will blink twice

to confirm the storage of commands.

To access the programmed channels, press the [MACRO]

button once. This will bring up the first channel. Press

once again and it will bring up the second channel.

Press again and it will bring up the third channel.

To erase the Macro programming and return to the

original function:

STEP1 Press the [CBL] button to select the CABLE mode.

STEP2 Press a [MACRO] button and the [OK/SEL] button

simultaneously for 3 seconds. The CBL device

LED will turn on for 20 seconds. The next step

must be performed while the LED is on.

STEP3 Press the [CH+] button to erase the functions stored

in the button. The CBL device LED will blink twice to

confirm that the memory button has been erased.

. Assigning the V

Assigning the Volume and Mute keys to a

olume and Mute keys to a

Dif

Differ

ferent Device

ent Device

By default, the VOL+, VOL- and MUTE keys operate

through your TV. If you would like those keys to operate

those functions on a different device, follow these steps.

STEP1 Press the [OK/SEL] button and [CBL] button

simultaneously for three seconds. The device

LED will turn on for 20 seconds. The next step

must be performed while the LED is on.

STEP2 Press the [VOL +] button. The device LED will

blink.

STEP3 Press the [DEVICE] button corresponding to the

device that you would like the volume and mute

buttons to control. The device LED will blink

twice to confirm the programming.

Example : If you wish to have the volume and mute keys

operate your Cable Box, press the [CBL]

button in Step3.

G. Assigning the Channel keys to a

Assigning the Channel keys to a

Dif

Differ

ferent Device

ent Device

By default, the CH+, CH-, NUMERIC and LAST keys

operate through your Cable Box. If you would like those

keys to operate those functions on a different device,

follow these steps.

STEP1 Press the [OK/SEL] button and [CBL] button

simultaneously for three seconds. The device

LED will turn on for 20 seconds. The next step

must be performed while the LED is on.

STEP2 Press the [VOL -] button. The device LED will

blink.

STEP3 Press the [TV] button. The device LED will blink

twice to confirm the programming.

*Note : If you wish to have the channel keys operate your

Cable Box, press the [CBL] button instead of the

[TV] button in Step 3.

Assigning the VCR/DV

Assigning the VCR/DVD

–

VOD keys to

contr

control your VCR or DVD

ol your VCR or DVD

By default, the REW, Play, FF, Record, Stop and Pause keys

operate VOD (Video On Demand) through your Cable Box.

If you would like those keys to operate those functions on

your DVD or VCR, press the PLAY button for 3 seconds

until the DVD/VCR button lights. To return to your Cable

Box control, press the PLAY key again for 3 seconds until

the CBL button lights.

I. Low Batter

Low Battery W

y War

arning

ning

When the battery is low (2.3V-2.0V) and needs to be

replaced with fresh batteries, device LED will blink 2 times

in sequence whenever a [DEVICE] button is pressed to

turn on equipment.

J. Memor

Memory Lock System.

y Lock System.

This remote control is designed to retain programmed

memory for 10 years — even after batteries are removed

from the remote control.

Set-up Code Tables

MAKER(BRAND) NAME

CODE No

CONVERTER

CABLE TV

SCIENTIFIC ATLANTA EXPLORER Series 001

8600X 011

8600 021

8540,8570,8590 022

8500 023

IPN Series 051

MOTOROLA DCT Series (DVR Model) 002

VIP Series 053

GENERAL INSTRUMENT DCT Series,DCH Series, CFT2200 008

JERROLD BMC9012/BMC9022 006

DSR470 005

CFT2000 012

DRZ 024

DL4,DP(V),DQN(V),DPBB 025

DRX 002

Some Model 048

ADB ADB Series 054 055

ADB5810WX 115

AMINO AmiNET Series 049

AT&T U-VERSE 051

CISCO RNG200 113

IPN Series 051

COMCAST RNG200 113

DIGEO 2056-MSX 153

DIRECTV HR20, HR21 229

HAMLIN CR6000 042

CR6600,6800,CR83 043

CRX5000 044

MOXI MOXI MEDIA CENTER 006

MOXI HD DVR 052

2056-MSX 153

MYRIO Evo Series 054 055

NOW TV NOWTV 114

NSC IM781R 046

IM781 047

OAK SIGMAONE, P1,P2,P3, SIGMA 2000 037

RTC56,RKDM 038

SIGMA 2001,2002 039

SIGMA 450,500,550 040

PACE 500 Series 001

TDC Series 002

DTA Series 113

PANASONIC 140,145,170,175 030

110,120,130,150,160 031

PIONEER VOYAGER Series 001

BA9000 013

BA4100,4200,4500 028

BA-V1000 029

REGENCY ALL MODELS 045

SKY SKY+HD 230

SONY DHG-M55CV 003

TOCOM 5507 035

5503A 036

WEGENER SMD 515 050

ZENITH MN2500 032

PM 033

Z-TAC 034

Altri manuali per Easy Clicker UR3-SR3

Indice

Altri manuali Universal Remote Control Telecomando

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8500 Manuale utente

Universal Remote Control

Universal Remote Control Total Control TRC-1280 Manuale utente

Universal Remote Control

Universal Remote Control Total Control Manuale utente

Universal Remote Control

Universal Remote Control TRC-820 Manuale utente

Universal Remote Control

Universal Remote Control URC-A6 Manuale utente

Universal Remote Control

Universal Remote Control UR5L-9000L Manuale utente

Universal Remote Control

Universal Remote Control Complete Control MX-880 Manuale utente

Universal Remote Control

Universal Remote Control UR3-EXP Manuale utente

Universal Remote Control

Universal Remote Control UR3-J22TWM Manuale utente

Universal Remote Control

Universal Remote Control Complete Control MRF-260 Manuale utente

Universal Remote Control

Universal Remote Control PHAZR-5 UR5L-9000L-IP Manuale utente

Universal Remote Control

Universal Remote Control MX-500TM Manuale utente

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8800L Manuale utente

Universal Remote Control

Universal Remote Control Automator URC-200 Manuale utente

Universal Remote Control

Universal Remote Control Complete Control MX-900i Manuale utente

Universal Remote Control

Universal Remote Control UR4U-MDVR-CHD2 - MOTOROLA AND SCIENTIFIC ATLANTA... Manuale utente

Universal Remote Control

Universal Remote Control ORION MX-850 Manuale utente

Universal Remote Control

Universal Remote Control Easy Clicker UR2-211 Manuale utente

Universal Remote Control

Universal Remote Control PHAZR-5 Manuale utente

Universal Remote Control

Universal Remote Control ONE FOR ALL 5650CMN Manuale utente

Universal Remote Control

Universal Remote Control UR4-EXP Manuale utente

Universal Remote Control

Universal Remote Control Easy Clicker UR3L-SR4 Manuale utente

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8500 Manuale utente

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8500 Manuale utente

Manuali Telecomando popolari di altre marche

Panasonic

Panasonic EUR7622KB0 Manuale utente

Bang & Olufsen

Bang & Olufsen Beo4 Manuale utente

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuale utente

Multiplex

Multiplex PROFI TX 9 Manuale utente

One Remote

One Remote RMB4 Manuale utente

FUTABA

FUTABA 9ZAP - PART2 Manuale utente

HR Matic

HR Matic HR MULTI 3 Manuale utente

Yamaha

Yamaha ACC-GNRST-30-20 Manuale utente

EisSound

EisSound KBSOUND Manuale utente

Marantz

Marantz RC101 Manuale utente

Conrad

Conrad FS20 TC6 Manuale utente

Anritsu

Anritsu MP1777A Manuale utente

Niles

Niles WVC100 Guida alla risoluzione dei problemi

RCA

RCA RCU1300 Manuale utente

Bang & Olufsen

Bang & Olufsen BEO6 Manuale utente

GE 94901 Manuale utente

Onbon

Onbon YQ1-75 Manuale utente

FUTABA

FUTABA R7108SB Istruzioni per l'installazione
