Universal Remote Control LIGHTING Manuale utente

Native Lighting Control

Control Dimmers, Lamp Dimmers and Switches

Directly from URC Remote Controls

greenbriar

bluestone

URC Lighting Control by Lutron™

Give Your Clients Control of the Lights

in the Room They’re In...

MX-6000

MX-3000B KP-900

Lighting Control backed by two of the biggest names in the

business-Universal Remote Control and Lutron Electronics-both

relentlessly committed to quality, reliability, service and support.

MX-980 MX-880 MX-810 MX-450

URC Remotes

control the dimmers &

switches directly via RF!

URC-Lutron Compatible Remotes

Model

MX-6000 Yes

MX-3000 Black Yes

MX-3000 Yes*

MX-980 Yes

MX-950 Yes*

MX-900 Yes*

MX-880 Yes

MX-850 Yes*

MX-810 Yes

MX-650 Yes*

MX-450 Yes

MX-350 Yes*

MX-350N Yes*

TX-1000 Yes*

KP-900 Yes

Yes=Preprogrammed.

*Some models require Learning.

Native Control

No interface required when used with URC remotes. URC remotes

control the dimmers and switches directly via RF. No additional parts

are ever needed.

Easy Operation

Simply press-and-hold to re-program lighting scenes. Homeowners can

change the lighting scenes as often as they like-all by themselves. No

truck rolls or late-night visits required.

Scalable Solutions

Flexible entree into installing lighting control. Build a small system, one

dimmer at a time. Low cost of entry: one dimmer and one URC remote

is a lighting system that can “control the lights in the room you’re in.”

Your client will enjoy all of the benefits of lighting control. Lighting

control can help save energy and associated energy costs, improve

homeowner security and create comfortable ambiance. Add lighting

control to every job.

URC Lighting Control by Lutron™

Add Lighting Control to Every Job...

black

Dimmer Dimensions

snow

hot

In less time than it takes to speed dial the installer, the

homeowner can reset the lighting scenes using a simple

press-and-hold operation.

10% 10% 3 years $97

25% 20% 6 years $173

60% 50% 10+ years $358

Dimming Saves Bulbs Last 10 Year

the Lights Electricity on average Savings

Numbers based on (4) 75watt bulbs, operating for 5 hours a day, at 10¢ per

kilowatt hour (1500 hour incandescent bulbs at $1.75 each or many 3000

hour halogen bulbs at $3.35 each). Designed for 10+ year lifetime.

Technical Information

Individual URC RF Dimmers, RF Lamp Dimmers and RF Switches can

store up to three (3) “Lighting Addresses.” Each address has twelve

(12) commands: On; Off; Brighten; Dim; Scenes 1~8.

In a typical installation, addresses might be applied as in one of the following:

With one address stored in all dimmers:

Eight (8) Lighting Scenes involving all RF Dimmers and RF Switches.

On, Off, Brighten and Dim control ALL the dimmers in the room.

With one address stored in all dimmers and one unique address stored in each dimmer:

Eight (8) Lighting Scenes involving all RF Dimmers and RF Switches.

All: On, Off, Brighten and Dim.

Each: On, Off, Brighten and Dim individually.

With two addresses stored in all dimmers and one unique address stored in each dimmer:

Sixteen (16) Lighting Scenes involving all RF Dimmers and RF Switches.

All: On, Off, Brighten and Dim.

Each: On, Off, Brighten and Dim individually.

URC Lighting Control by Lutron™

Lighting Control Can Help Conserve

Energy – and Save Cash for Your Clients!

brown

Ganging and Derating

Incandescent Dimmer 60W 600W 500W 400W

MLV Dimmer 40W/VA 600VA/ 500VA/ 400VA/

450W* 400W* 300W*

Wallbox Switch 10W 6A light/ 5A light/ 3.5A light/

3A fan** 3A fan** 3A fan**

Lamp Dimmer 25W 300W

Accessory Dimmer 8.3A

Accessory Switch 8.3A

Min No fins 1 side Both sides

Load broken of fins of fins

broken broken

*Note: The maximum lamp wattage is determined by the efficiency of the transformer, with 70–85%

as typical. For actual transformer efficiency, contact either the fixture or transformer manufacturer.

The total VA rating of the transformer(s) shall not exceed the VA rating of the dimmer.

**Note: When controlling a combined fan and light load, the total cannot exceed 3A.

Build a small lighting control system one dimmer at a time...

Lighting Control uses Wall Dimmers, Lamp Dimmers and Switches-rated for the

correct

Load

– to create

Scenes

for different

Activities

Load

The load on the dimmer (or switch) is determined by the total wattage of ALL of the lights controlled

by the dimmer, i.e., everything that is on that circuit.

The load is calculated by adding together the wattage of each light. Each light’s highest allowable

wattage (“worse case”) light bulb is used for purposes of calculation. For example, even if the

client currently has a 60 watt bulb installed, if the fixture is labeled “100 Watts Maximum” they

might install a 100 watt bulb. Therefore, you must use 100 Watts as the wattage when calculating

the load on the dimmer. (This information is provided for specification purposes only-do not install

high voltage wall dimmers or switches unless you are legally and technically qualified to do so.)

Scene

A group of Loads controlled altogether and at the same time.

A Scene can include a multiple of RF Switches and/or RF Dimmers. Every RF Dimmer in a scene

operates at a stored brightness setting. Every RF switch in a scene either turns on or off. Scenes

are only directly controlled from the remote. Every RF Dimmer and RF Switch must be in the

range of the remote control (but not necessarily line-of-sight).

Activities

Things people do-like watching movies or playing video games-that can be made more enjoyable

by controlling the lighting within that environment.

Different Activities require different lighting Scenes. Loads are turned On or Off depending on

the Activity. Lights are dimmed to different levels depending on the Activity. For example, in the

Family Room, people might watch TV, read, play video games, entertain guests, an so forth.

Other rooms have unique Activities.

Style

Contemporary design with LED indicator lights.

Color

Available in 28 designer colors and finishes.

Quality

Products feature world famous Lutron technology and design.

Gloss Finish:

white, light almond, black, almond, brown, gray, ivory

Satin Finish:

biscuit, bluestone, desert stone, eggshell, goldstone,

greenbriar, hot, limestone, merlot, midnight, mocha stone, palladium,

plum, sea glass, sienna, snow, stone, taupe, terracotta, turquoise

Metal Finish:

stainless steel (wallplates only)

Footnote: Standard Wall Dimmer and Switch colors are White, Black

and Light Almond. Other colors and finishes are special order only and

may incur additional cost and longer delivery time. Lamp Dimmers are

available in White and Black only. Contact your Sales Representative or

Distributor for more details and availability information.

Available exclusively from:

white light almond black almond brown gray ivory

biscuit bluestone desert stone

limestone merlot midnight

mocha stone palladium plum

sea glass sienna snow

stone taupe

turquoise stainless steel

(wallplates only)

terracotta

eggshell goldstone greenbriar hot

Universal Remote Control, Inc.

500 Mamaroneck Avenue, Harrison, NY 10528

Phone: (914) 835-4484 Fax: (914) 835-4532

www.universalremote.com

REV: 100108
