Universal Remote Control MX-900 Manuale utente
Operating Your System
With The Genesis MX-900
COMPLETE ™
Universal Remote Control®
CONTROL
COMPLETE
This remote control was
Custom Programmed for you by:
For questions about your Custom Programming call:
Custom Programming of a complex home theater and/or a multi-room
system is one of the most challenging tasks within an audio/video instal-
lation. It involves an intimate knowledge of how the components interact
and exact details on the proper sequences of control.
Only a Complete Control dealer has the requisite experience and training
to quickly and effectively customize a remote control for true automated
operation.
Congratulations on your choice!
MX-900 Owners Manual © 2006 Universal Remote Control, Inc.
Front Cover Photo courtesy of Robert Ridenour of Connected Technologies,
www.connected-technologies.com
The information in this manual is copyright protected. No part of this manual may
be copied or reproduced in any form without prior written consent from Universal
Remote Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR OPERATIONAL,
TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN THIS MANUAL.
The information in this manual may be subject to change without prior notice.
Complete Control is a registered trademark of Universal Remote Control, Inc.
Entertainment Made Simple is a trademark of Universal Remote Control, Inc.
All other brand or product names are trademarks or registered trademarks of their
respective companies or organizations.
Universal Remote Control, Inc.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
TABLE OFCONTENTS
Introduction 1
The LIGHT Button 1
Optional RF “No Rules” Operation 2
Installing Batteries 3
Programming the Genesis 4
Selecting a New “Activity” 5
Using the Genesis to Control an “Activity” 6
Displaying the Setup Screen 7
Selecting from the Setup Screen 7
Setting the LCD 8
Sound Volume 10
Light Settings 10
System Settings 11
Version Information Displays 11
Warranty 12
Specifications 12
Page 1
GENESIS OWNERS MANUAL
Congratulations!
You’ve purchased a unique synthesis of hardware and software engineering,
the Complete Control Genesis. The Genesis achieves a magnificent combina-
tion of power and flexibility, simplifying and automating operation of even the
most complex system.
One Touch Blue Backlighting
Simply press the LIGHT button to backlight the screen.
Integrated Sound Signaling
The Genesis incorporates a small speaker for beeps. Anytime you press a
button, the Genesis signals that it has understood your command with a
beep sound.
Custom Labeled Buttons
The Genesis is equipped with a bright easy to read LCD screen which
labels the six buttons to the right of the screeen. These button labels
change based on what you are watching or listening to. Thus, if you have
selected Watching TV, you will see a list of buttons that are useful to that
activity, while if you select DVD, the buttons will control the DVD.
LIGHT Button
Press the Light button on the
side of the Genesis to back-
light the LCD display and all
of the buttons.
Page 2
GENESIS OWNERS MANUAL
Optional RF “No Rules” Operation
In combination with a Complete Control RF Base Station, the Genesis can
control your system without being in line-of-sight of the equipment.
Either the MRF-300 or the MRF-250 RF base station is compatible with the
Genesis. Both incorporate RF addressing. RF Addressing gives you the ability to
control equipment locations throughout your home, even if they are concealed
in other rooms or are behind closed doors.
4. Self-adhesive “Flashers” affix to the
Infrared sensors on the front panels of your
components. The Flashers relay commands
to components out of sight of the MRF-
300’s Front Blaster. The flashers plug in to
the MRF-300’s rear flasher line outputs via
their 10 foot cables. Uniquely, the MRF-300
can also connect to rear panel IR Inputs via
its adjustable IR Line Outputs.
3.The MRF-300’s built-in Front Blaster sends commands to
components in the same cabinet space as the MRF-300.
1.The Genesis sends radio waves
in every direction, so you don’t
have to point the remote any-
more!
2.The RFX-150 RF Sensor can be freely
positioned for optimal reception.
Page 3
GENESIS OWNERS MANUAL
Installing Batteries
Open the battery cover by pressing
the release and pulling back the
cover on the back of the control.
Remove the cover.
Observe the + and - polarity
indications inside the battery
compartment.
Place the four AAA batteries into
their positions in the battery com-
partment observing the + and -
polarity indicators on the batteries.
Now, replace the battery cover by
inserting the hinged end in first,
then snapping the cover back into
place.
Page 4
GENESIS OWNERS MANUAL
Programming the Genesis
The Genesis is programmed via a Windows PC equipped with a USB port
(programming cable included), using our proprietary software, MX-900
Editor. You can download this software from our website:
www.universalremote.com
Basic setup takes only a few minutes with this software. However, to fully
automate an audio/video system the user must have a detailed knowledge
of each component, you the user (and your preferences) and how the sys-
tem is connected and operated. We highly recommend that you use a
professional audio/video installer to program your Genesis so you will be
able to enjoy all the benefits of the Genesis as well as one touch opera-
tion via macros.
Page 5
GENESIS OWNERS MANUAL
Selecting a New “Activity”
The Genesis’s WATCH and LISTEN buttons display the activities you can
control with your Genesis. When you want to watch something else (a
DVD movie, a videotape or an HDTV broadcast), simply press the
WATCH button and select the new activity. When you want to listen to
the radio or to a CD, touch the LISTEN button and select what you would
like to listen to.
Your installer will have programmed the button you pressed to totally con-
figure your system to watch or listen to whatever you selected. Now, the
screen will change, and all of the LCD buttons will be reconfigured to
give you full control of your system while watching or listening to your
selection!
Press either of the PAGE buttons to see any other available choices.
When you press the LISTEN button,
you can see the most frequently used
activities you have for listening in
your system.
PAGE DISPLAY
At the bottom of the LCD screen, the
page display informs you if there are
other pages of buttons available.
When you press the WATCH button,
you can see the most frequently used
activities you have for watching the
sources in your system.
Page 6
GENESIS OWNERS MANUAL
Using the Genesis to Control an “Activity”
Once you’ve selected a new activity, the Genesis displays the title of the
activity at the top of the screen. Below the title, the LCD displays the cus-
tomized names of any special features you need for the activity. All the
hard buttons of the Genesis have now changed to functions optimized for
this activity.
The Title displays
what activity you
can control.
The Volume and
Mute buttons always
control the sound
regardless of what
screen is displayed.
Press either of the
PAGE buttons to
see any other avail-
able choices.
The transport buttons
(Play, Stop, Skip-, Skip+,
FF, REW and Pause)
operate when the select-
ed activity requires them
(for example, if you
watch CABLETV with a
TiVo type of DVR, these
buttons will control the
built-in DVR, while if
you are watching a
DVD, these buttons will
control the DVD player).
The 4 way cursor
buttons enable you
to navigate on
screen guides and
menus with ease.
The Channel and
Previous Channel
buttons will change
channels when you
have selected an
activity like Watch
CABLETV or
Watch SAT TV .
The Number keypad
will enter numbers
for the activity you’ve
selected. Thus, for
watching Cable TV,
you use the number
keypad to enter chan-
nel numbers, while
when listening to CD,
the number keypad
enters track numbers.
The LCD button
labels describe
special features
for this activity.
Displaying the Setup Screen
You can adjust the settings of the Genesis whenever you
like by pressing and holding both the WATCH and the
ENTER button at the same time for three seconds. When
you do, the screen will change to the SETUP screen. If
you do not press any button on the SETUP screen within
30 seconds, the Genesis will time out and automatically
return to normal operation. You can return to normal
operation before that by pressing either the WATCH or
the LISTEN button.
Selecting from the Setup Screen
Simply touch the button for the setting you’d like to adjust:
At the same time, press and
hold both the WATCH but-
ton and the ENTER button.
When the SETUP screen
appears, you can release the
two buttons.
Page 7
GENESIS OWNERS MANUAL
SETUP
LCD
LIGHT
SOUND
SYSTEM
VERSION
LCD - The appearance of the
screen.
LIGHT - What the LIGHT button
does.
SOUND - The volume of the
beeps.
SYSTEM - The battery low warn-
ing.
VERSION - No adjustments are
possible. Displays factory info.
Altri manuali per MX-900
1
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali Universal Remote Control Telecomando
Universal Remote Control
Universal Remote Control PHAZR-5 Manuale utente
Universal Remote Control
Universal Remote Control MX600 Manuale utente
Universal Remote Control
Universal Remote Control UR5U-8520 Manuale utente
Universal Remote Control
Universal Remote Control CLIKR-5 UR5U-8500 Manuale utente
Universal Remote Control
Universal Remote Control Complete Control MX-880 Manuale utente
Universal Remote Control
Universal Remote Control Easy Clicker UR3-SR2 Manuale utente
Universal Remote Control
Universal Remote Control OCE-0040A Manuale utente
Universal Remote Control
Universal Remote Control CLIKR-5 UR5U-8500 Manuale utente
Universal Remote Control
Universal Remote Control UR4-DCT Manuale utente
Universal Remote Control
Universal Remote Control CLIKR-5 UR5U-8780L Manuale utente
Universal Remote Control
Universal Remote Control Complete Control MX-900i Manuale utente
Universal Remote Control
Universal Remote Control RF10 MASTERCONTROL Manuale utente
Universal Remote Control
Universal Remote Control Complete Control MX-980 Manuale del proprietario
Universal Remote Control
Universal Remote Control URC-SR3 Manuale utente
Universal Remote Control
Universal Remote Control UR4U-MDVR2 Manuale utente
Universal Remote Control
Universal Remote Control total control TRC-780 Manuale utente
Universal Remote Control
Universal Remote Control UR4U-MDVR-CHD2 - SPECS SHEET Manuale utente
Universal Remote Control
Universal Remote Control Medius TX-1000 Complete Control Manuale utente
Universal Remote Control
Universal Remote Control UR5-8400A Manuale utente
Universal Remote Control
Universal Remote Control UR5U-8720L Manuale utente
Universal Remote Control
Universal Remote Control UR4-EXP Manuale utente
Universal Remote Control
Universal Remote Control UR5U-BH8000 Manuale utente
Universal Remote Control
Universal Remote Control MX-980 Manuale utente
Universal Remote Control
Universal Remote Control Easy Clicker UR3L-SR4 Manuale utente
