US Robotics Courier USR997624 Manuale utente

Gigabit Smart Switch

Quick Installation Guide

Guida per l'installazione rapida

HõzlõKurulum Kõlavuzu

#R24.0676.00

rev 3 01/07

Contents

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Introduction ............................................................................1

Installation ............................................................................ 5

Troubleshooting ...................................................................... 9

Additional Information ............................................................10

Italiano . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Introduzione .......................................................................... 11

Installazione .........................................................................15

Risoluzione di problemi ..........................................................19

Informazioni aggiuntive ......................................................... 20

Türkçe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Giriş...................................................................................... 21

Kurulum .................................................................................. 25

Sorun Giderme ........................................................................ 29

Ek Bilgiler ............................................................................... 30

Support / Assistance / Servizio assistenza / Asistencia téc-

nica / Destek ...............................................................31

English

Introduction

This guide covers installation of the following Gigabit Smart Switch models:

!7624—24-Port 10/100 PoE + 2-Port Gigabit Smart Switch

!7716—10/100/1000 Mbps 16-Port Smart Switch

!7724—10/100/1000 Mbps 24-Port Smart Switch

!7748—10/100/1000 Mbps 48-Port Smart Switch

Package Contents

Physical Features

7624 Front, Back, and LEDs

Model 7624. 24-Port 10/100 PoE + 2-Port Gigabit Smart Switch.

7624 LEDs

!Smart Switch !2 Mounting Brackets and Screws

!Power Cord !USRobotics Installation CD-ROM

!4 Rubber Feet !Quick Installation Guide

LED State Condition

POWER

On Receiving power

Off Not receiving power

SYSTEM

Blinking CPU is active

On CPU is not active

Off

PWR-MAX

On Not enough power for additional PoE-powered

device

Off Enough power for additional PoE-powered

device

AC IN

LEDs PoE ports Gigabit Ethernet

ports

Power connector

24-Port 10/100 + 2-Port 10/100/1000 Mbps

Smart Switch with PoE

1 3 5 7

POWER

SYSTEM

PWR MAX

1 3 5 7 9 11 1 3 15 17 1 9 21 23

2 4 6 8 10 12 14 16 1 8 20 22 24

1000BASE-T 1000BASE-T

Link/ACT

100Mbps

PoE Status

Link/ACT

100Mbps

PoE Status

1000Mbps

100Mbps

Link/ACT

2 4 6 8

9 1 1 13 15

10 12 14 1 6

17 19 21 2 3

18 20 22 2 4 25 26

RESET

25 26

Reset button

English

7716 Front, Back, and LEDs

Model 7716. 10/100/1000 Mbps 16-Port Smart Switch.

7716 LEDs

PoE Status

Green Port is supplying power to the connected

device

Red Port cannot supply power to the connected

device

Off No PoE-compatible device is connected

Link/ACT

On Link is up

Blinking Port is transmitting or receiving data

Off Link is down

1000 Mbps

On Link rate is 1000 Mbps

Off Link rate is not 1000 Mbps

100 Mbps

On Link rate is 100 Mbps

Off Link rate is not 100 Mbps

LED State Condition

POWER

On Receiving power

Off Not receiving power

SYSTEM

Blinking CPU is active

On CPU is not active

Off

Link/ACT

On Link is up

Blinking Port is transmitting or receiving data

Off Link is down

1000 Mbps

On Link rate is 1000 Mbps

Off Link rate is not 1000 Mbps

100 Mbps

On Link rate is 100 Mbps

Off Link rate is not 100 Mbps

LED State Condition

AC IN

RESET

153 713 159 11

2648 141610 12

POWER

SYSTEM

Link/ACT

1000Mbps

100Mbps

1000Mbps

Link / ACT

123456789

10 11 12 13 14 15 1516 16

15 16

mini-GBIC

10/100/1000 Mbps

16-Port Smart Switch

LEDs Ethernet ports GBIC

ports

Reset button Power connector

English

7724 Front, Back, and LEDs

Model 7724. 10/100/1000 Mbps 24-Port Smart Switch.

7724 LEDs

LED State Condition

Power

On Receiving power

Off Not receiving power

System

Blinking CPU is active

On CPU is not active

Off

Link/ACT

On Link is up

Blinking Port is transmitting or receiving data

Off Link is down

1000 Mbps

On Link rate is 1000 Mbps

Off Link rate is not 1000 Mbps

100 Mbps

On Link rate is 100 Mbps

Off Link rate is not 100 Mbps

LEDs Ethernet ports GBIC

ports

Reset button Power connector

100Mbps

1000Mbps

1537

2648

91311 15 17 2119 23

10 1412 16 18 2220 24

Power

System

12345678910 11 12 13 14 15 16 17 18 20 21

Link / ACT

23 24

mini-GBIC

10/100/1000 Mbps

24-Port Smart Switch

AC IN

RESET

English

7748 Front, Back, and LEDs

Model 7748. 10/100/1000 Mbps 48-Port Smart Switch.

7748 LEDs

Default Values

All of the smart switches covered in this guide have the following default values:

IP address: 192.168.0.1

Password: admin

LED State Condition

POWER

On Receiving power

Off Not receiving power

SYSTEM

Blinking CPU is active

On CPU is not active

Off

1–48

(Ethernet)

Green Solid or

blinking Link rate is 1000 Mbps

Blinking Port is transmitting or receiving data

Amber Solid or

blinking Link rate is 10 Mbps or 100 Mbps

Blinking Port is transmitting or receiving data

Off Link is down

45–48

mini-GBIC

On Mini-GBIC module is installed and connected

Blinking Port is transmitting or receiving data

Off No mini-GBIC module is installed

10/100/1000 Mbps

48-Port Smart Switch

LEDs

Ethernet ports GBIC

ports

Reset button

Power connector

AC LINE 100-240 VAC

50-60Hz 1.4A

English

System Requirements

To install the switch, you need the following:

!A computer with an Ethernet adapter installed

!An Ethernet cable

For access to the switch’s Web User Interface, you need the following:

!A computer with an Ethernet adapter installed

!An HTML 4.01-compliant Web Browser (such as Internet Explorer 5.5 or

later or Netscape 8.0 or later) with JavaScript enabled

To use the Smart Switch Configuration Utility, the computer must be running

Windows XP or 2000. If you are not using a Windows operating system, you can

perform all configuration functions through the Web User Interface.

Installation

Step One: Mount the Hardware

The switch can be mounted on a flat surface or on an equipment rack.

Surface Mounting

Attach the rubber feet to the bottom of each device. Install the Switch on a

sturdy, level surface that can support its weight.

Rack Mounting

You can mount the switch on an EIA standard-size, 19-inch rack.

English

1. Attach a bracket to each side of the switch, and secure the brackets with

the provided screws:

2. Use screws provided with the equipment rack to mount the switch in the

rack.:

Step Two: Attach Cables

1. Use an Ethernet cable to connect any Ethernet port on the switch to the

Ethernet port on a computer. The computer will be used to set the switch’s

IP address.

153 713 15911

264 8 14 1610 12

POWER

SYSTEM

Link/ACT

1000Mbps

100Mbps

1000Mbps

Link/ ACT

123456789

10 11 12 13 14 15 1516 16

15 16

mini-GBIC

10/100/1000Mbps

16-PortSmart Switch
