V-tech Touch & Learn Activity Desk Istruzioni di montaggio

91-003220-005 UK

Parent’s Guide

INTRODUCTION

Thank you for purchasing the Touch & Learn Activity Desk!

The Touch & Learn Activity Desk features an interactive desktop with

activity cards that introduce letters, music, colours and more. The writing

pad with a light up display teaches how to write letters and numbers

stroke by stroke. Flip up the desktop and create a masterpiece by using

the art station or blackboard. For more fun, play with the toy phone or

listen to tunes on the music player.

INCLUDED IN THIS PACKAGE

• OneTouch & Learn Activity Desk (touch panel, base, four legs)

• Fourdouble-sidedactivitycards

• Onestool(seat,fourlegs)

• Oneparent’sguide

WARNING:

All packing materials such as tape, plastic sheets, packaging

locks, removable tags, cable ties and packaging screws are not

part of this toy, and should be discarded for your child’s safety.

NOTE: Please keep this parent’s guide as it contains important

information.

PRODUCT FEATURES

1LED Display (Writing Pad)

2Photo Frame

3Toy Phone Number Buttons

4Toy Phone Game Mode Buttons

5Activity Card Slot

6Activity Page Area

7Stool Seat

8Stool Legs

9Desk Legs

10 Activity Page Mode Icons

13 Music Player Controls

16 Letter and Number Selection Buttons

11 Volume Buttons

14 Music Style Buttons

17 Writing Pad Release Button

12 Power Button

15 Stylus

FEATURES ACTION

Power Button Press the Power Button to turn the unit

ON. Press the button again to turn the

unit OFF.

Volume Buttons Press the buttons to decrease or

increase the volume. There are five

volume levels.

Toy Phone Number Buttons Press the Number Buttons to learn and

explore numbers.

Toy Phone Game Press the button to learn numbers in

Learn It Mode.

Press the button to meet new friends

in Call A Friend Mode.

LED Display / Writing Pad Watch images and simple animations

appear on the LED Display. Transform it

into a Writing Pad and learn how to write

letters and numbers with proper stroke

order.

Activity Page Area Listen to the game instructions and touch

the correct objects on the activity page to

play.

Writing Pad Release Button Press the Release Button to release

the LED Display and transform it into a

Writing Pad.

Letter and Number Selection Press the buttons to select the

letters or numbers you would like to write.

Stylus (only works with writing pad) Practise writing letters and numbers by

using the Stylus to trace the flashing

lights.

Music Player Controls Press the button to play or stop the

music and press the buttons to

hear the previous or next song.

Activity Page Mode Icons Use your finger to touch any of the Mode

Icons on the activity page to play.

Activity Card Slot Insert one of the activity cards into the

Activity Card Slot to play.

WARNING:

Please do not use a stylus, pencil or other pointed object on the Activity

Page Area or activity cards.

ASSEMBLY INSTRUCTIONS

With the Touch & Learn Activity Desk safety comes first.

Toensureyourchild’ssafety,adultassemblyisrequired.

For the Desk:

1. Support the base by placing it on the floor. Insert the touch panel into

the base and press firmly down on the shoulders until you hear a click.

Caution: Do not place too much pressure on the touch panel itself.

2. Fully insert the four desk legs into

the slots on the bottom of the base.

For the stool:

Insert the four stool legs into the slots on the bottom

of the stool seat. Please make sure you have fully

inserted the legs into the seat to ensure the stool

is stable. Always make sure all four legs are fully

inserted before your child sits on the seat. The

recommended weight limit of the stool should not

exceed 34 kilograms.

Touch Panel

Shoulder Shoulder

Base

Easily Transforms from an Activity Desk to an

Art Station and Blackboard.

To use the Activity Desk as an Art Station, flip up the touch panel and

use the clip to hold paper on the blackboard surface. You can also draw

directly on the blackboard surface by using chalk (not included).

Use a cloth to remove the chalk and wipe away any remaining chalk dust

on the desk or activity cards.

CAUTION: Keep fingers away from the hinges or underneath the desk

before lowering the touch panel or closing the desk.

Activity Card Holder:

Flip up the touch panel to store your activity cards in the activity card holder.

How to Return the Writing Pad

1. Lift up the writing pad.

2. Push the writing pad back into place

until you hear a click sound indicating

it has been securely returned.

Art Station Blackboard

GETTING STARTED

BATTERY INSTALLATION

• MakesurethemainunitisturnedOFF.

• Locatethebatterycoveronthebackofthe

touch panel. Use a coin or screwdriver to

open the battery cover.

• Install 4 new AA (AM-3/LR6) batteries

following the diagram inside the battery

box. (The use of new alkaline batteries is

recommended for maximum performance).

• Replacethebatterycoverandtightenthescrewtosecure.

BATTERY NOTICE

• Usenewalkalinebatteriesformaximumperformance.

• Useonlybatteriesofthesameorequivalenttypeasrecommended.

• Donotmixdifferenttypesofbatteries:alkaline,standard(carbonzinc)

or rechargeable (Ni-Cd, Ni-MH), or new and used batteries.

• Donotusedamagedbatteries.

• Insertbatterieswiththecorrectpolarity.

• Donotshort-circuitthebatteryterminals.

• Removeexhaustedbatteriesfromthetoy.

• Removebatteriesduringlongperiodsofnon-use.

• Donotdisposeofbatteriesinfire.

• Donotchargenon-rechargeablebatteries.

• Remove rechargeable batteries from the toy before charging (if

removable).

• Rechargeablebatteriesareonlytobechargedunderadultsupervision.

Disposal of batteries and product

The crossed-out wheelie bin symbols on products and

batteries, or on their respective packaging, indicates they

must not be disposed of in domestic waste as they contain

substances that can be damaging to the environment and

human health.

The chemical symbols Hg, Cd or Pb, where marked, indicate

that the battery contains more than the specified value of

mercury (Hg), cadmium (Cd) or lead (Pb) set out in Battery

Directive(2006/66/EC).

The solid bar indicates that the product was placed on the

market after 13th August, 2005.

Help protect the environment by disposing of your product or batteries

responsibly.

Formoreinformation,pleasevisit:

www.recycle-more.co.uk

www.recyclenow.com

TO BEGIN PLAY

Press the Power Button to turn the main unit on.

Activity Page Area

Touch any object on the activity page to explore. Touch any of the

Mode Icons on the right of the page to play additional activities. Voice

instructions are included for each activity. The Activity Page Area will

not be responsive to touch if the writing pad is down.

Music Player

There are 10 popular music and 10 classical music melodies in the

Music Player.

In this mode, the Music Player will play the popular music by default.

The Music Player will stop when the popular music melodies have

played through twice. You can change the music by using the Music

Controls.OncetheMusic Player is in classical music mode, it will also

play through twice and then stop.

Writing Pad

Press the release button on the LED Display to transform it into an

interactive writing pad. Press the arrow buttons to select which letter or

number you would like to write.

When the Stylus is not in use, place it back in the stylus holder. Be

careful not to pull on the stylus wire too firmly.

NOTE:

• TheStylus only works when the desk is on.

• IftheLED Display is covered, do not use the Stylus to draw on it.

The sensitivity of the Stylus may be affected and it may not work

properly.

• DirectsunlightmayimpactthesensitivityoftheStylus.

Toy Phone

Learn It Mode

Touch the number buttons to learn numbers, counting

and number order. Then test your knowledge by

answeringquestions.

Call A Friend Mode

Follow the instructions and press the correct number

buttons to meet some new friends.

Battery Status

When the batteries are almost exhausted, the unit will show an empty

battery icon on the LED Display for a few seconds and then may

automatically power off. New batteries should be inserted before further

use.

Automatic Shut Off

To preserve battery life, the main unit will automatically turn off after

about two minutes without operation.

ACTIVITY CARDS

To play an activity card, insert it into

the Activity Card Slot.

WARNING:

• Pleaseinsertonlyoneactivitycard

at a time. Inserting more than one

activity card may damage the card

or the desk and may also result in

incorrect card detection.

• Do not try to insert anything other than the activity card into the

Activity Card Slot. To avoid any interference, please keep the slot

area clean and free from debris.
