Valor Fires 347 Manuale di istruzioni
5112105/03
Model 347
RADIANT / CONVECTOR GAS FIRE
Fitted with one of the following fascia
Firelite 4 Oxysafe or
Regency 4 Oxysafe
(GC No. 32-032-62)
INSTALLER: Please leave this guide with the owner
INSTALLATION AND OWNER GUIDE
We trust that this guide gives
sufficient details to enable this
appliance to be installed and
maintained satisfactorily. However, if
further information is required, our
Valor Fires Technical Helpline will
be pleased to help.
Telephone 0844 8711 565 (National
call rates apply in the United
Kingdom).
In the Republic of Ireland
Telephone 0044 844 8711 565.
© Baxi Heating U.K. Limited 2008.
Baxi Heating U.K. Limited 2008.
All rights reserved. No part of this publication may be reproduced in any material form
(including photocopying), stored in any medium by electronic means (including in any
retrieval system or database) or transmitted, in any form or by any means, whether
electronic, mechanical, recording or otherwise, without the prior written permission of
the copyright owner.
Applications for the copyright owner's permission to reproduce any part of this
publication should be made, giving details of the proposed use, to the following
address: The Company Secretary, Baxi Heating UK Limited, The Wyvern Business
Park, Stanier Way, Derby, DE21 6BF.
Warning: Any person who does any unauthorised act in relation to a copyright work
may be liable to criminal prosecution and civil claims for damages.
Valor Fires, Erdington, Birmingham B24 9QP
www.firesandstoves.co.uk
Because our policy is one of constant development and improvement, details may vary slightly from
those given in this publication
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20).
WHEN CONVERTED USING CONVERSION KIT NUMBER 05347F1 THIS
APPLIANCE IS FOR USE WITH PROPANE GAS (G31).
THIS APPLIANCE IS SUITABLE ONLY FOR INSTALLATION IN THE UNITED
KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE).
© Baxi Heating U.K. Limited 2008. Page 2
Safety First.
Valor Fires fires are CE Approved and designed to meet the appropriate British
Standards and Safety Marks.
Quality and Excellence.
All Valor Fires fires are manufactured to the highest standards of quality and
excellence and are manufactured under a BS EN ISO 9001 quality system accepted
by the British Standards Institute.
The Highest Standards
Valor Fires is a member of SBGI and HHIC (Heating and Hot water Industry Council)
that work to ensure high standards of safety, quality and performance.
Careful Installation
Valor Fires is a CORGI registered company. All our gas fires must be installed by a
competent CORGI Registered Installer in accordance with our Installer Guide and
should not be fitted directly on to a carpet or floor of combustible material.
© Baxi Heating U.K. Limited 2008. Page 3
Page 4
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2008.
INSTALLER GUIDE
FOR OWNER GUIDE SEE PAGES 27 TO 39
CONTENTS
Section Heading Page
INSTALLER GUIDE 4 - 26
OWNER GUIDE 27 - 39
1 SAFETY 6
2 LIST OF ACCESSORIES 6
3 APPLIANCE DATA 7
4 GENERAL INSTALLATION REQUIREMENTS 8
5 PRE-INSTALLATION PREPARATION 14
5.1 Unpacking. 14
5.2 Fireplace flue pull. 15
5.3 Appliance preparation. 15
5.4 Fitting the battery to electronic ignition models. 15
5.5 Checking the ignition. 15
5.5.1 Manual ignition. 15
5.5.2 Electronic ignition. 16
5.6 Fitting the closure plate. 16
6 APPLIANCE INSTALLATION 18
6.1 Installing to a hearth. 18
6.2 Wall mounting. 18
6.3 Gas supply connection. 18
6.4 Radiants installation. 18
6.5 Flue restrictor adjustment. 19
7 CONTROL AND PRESSURE CHECKS 20
7.1 Check control settings. 20
7.2 Flame supervision and spillage monitoring system. 20
7.3 Check reference pressure. 21
8 FASCIA FITTING 21
9 SPILLAGE CHECK 22
10 FINAL REVIEW 23
11 SERVICING AND PARTS REPLACEMENT 24
11.1 To remove the fascia. 24
11.2 To replace radiant(s). 24
11.3 To replace the pilot unit. 24
11.4 To remove the piezo generator (Manual ignition models). 25
11.5 Note for electronic ignition. 25
11.6 To remove the complete burner module, pipes and pilot. 25
11.7 To grease the gas tap. 26
INSTALLER GUIDE
Page 5
© Baxi Heating U.K. Limited 2008.
1. SAFETY
Installer
Before continuing any further with the installation of this appliance please read
the following guide to manual handling.
The lifting weight (kg) of this appliance is as below:
Heat Engine Fascia
9.35 5.05
One person should be sufficient to lift the fire. If for any reason this weight is
considered too heavy then obtain assistance.
When lifting always keep your back straight. Bend your legs and not your back.
Avoid twisting at the waist. It is better to reposition your feet.
Avoid upper body/top heavy bending. Do not lean forward or sideways whilst
handling the fire.
Always grip with the palm of the hand. Do not use the tips of fingers for support.
Always keep the fire as close to the body as possible. This will minimise the
cantilever action.
Use gloves to provide additional grip.
Always use assistance if required.
2. LIST OF ACCESSORIES
Description Part number
Flue Spigot extension 0595191
LPG Conversion kit 05347F1
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2008. Page 6
3. APPLIANCE DATA
*When converted using kit 05347F1.
The appliance information label is on the inner face of the back panel at the lower left
hand side. It is visible when the fascia is removed.
This appliance does not contain any component manufactured from asbestos or
asbestos related products.
The efficiency of this appliance has been measured as specified in BS 7977 - 1 and
the result is as below:
Model Efficiency % (Gross)
347 Firelite and Regency 71
The gross calorific value of the fuel has been used for this efficiency calculation. The
test data from which it has been calculated has been certified by Advantica
Certification services (0087). The efficiency value may be used in the UK
Government's Standard Assessment Procedure (SAP) for energy rating of dwellings.
INSTALLER GUIDE
Gas Natural (G20) Propane (G31) *
Inlet Pressure 20mbar 37mbar
Input - Max. (Gross) 5.6kW (19,100 Btu/h) 5.3kW (18,084 Btu/h)
Input - Min. (Gross) 1.57W (5,357 Btu/h) 2.35kW (8,018 Btu/h)
Burner Test Pressure (Cold) 17.95 + 0.75mbar
(7.2 + 0.3in w.g.)
36.4 ± 0.75 mbar
(14.85 ± 0.3in w.g.)
Gas Connection 8mm pipe 8mm pipe
Burner Injector - Upper
(Centre Radiants) Cat 28 - 185 Size 80
Burner Injector - Lower
(Outer Radiants) Cat 28 - 185 Size 80
Pilot & Atmosphere Sensing
Device OPNG9093 OPLPG9222
Ignition Integral twin spark piezo
(Mounted on gas valve)
Integral twin spark piezo
(Mounted on gas valve)
Aeration Non-adjustable Non-adjustable
© Baxi Heating U.K. Limited 2008. Page 7
The conversion of net efficiency to gross was achieved by multiplying the net
efficiency by the following conversion factor from Table E3 of SAP 2005, rounding
down to the nearest whole number.
4. GENERAL INSTALLATION REQUIREMENTS
4.1 The installation must be in accordance with these instructions.
For the user’s protection, in the United Kingdom it is the law that all gas appliances
are installed by competent persons in accordance with the current edition of the Gas
Safety (Installation and Use) Regulations. Failure to install the appliance correctly
could lead to prosecution. CORGI requires its members to work to recognised
standards.
In the United Kingdom the installation must also be in accordance with:
All the relevant parts of local regulations.
All relevant codes of practice.
The relevant parts of the current editions of the following British Standards:-
BS 715
BS EN 1806 which replaces BS 1289 Part 2
BS 5440 Part 1
BS 5440 Part 2
BS 6891
BS 1251
BS EN 1856 Part 1 which replaces BS 4543 Part 2
BS 5871 Part 1
BS EN 1858 which replaces BS 1289 Part 1
BS 6461 Part 1
In England and Wales, the current edition of the Building Regulations issued by
the Department of the Environment and the Welsh Office.
In Scotland, the current edition of the Building Standards (Scotland) Regulations
issued by the Scottish Executive.
In Northern Ireland, the current edition of the Building regulations (Northern
Ireland) issued by the Department of the Environment for Northern Ireland.
In the Republic of Ireland the installation must be carried out by a competent
person and installed in accordance with:
a) The current edition of IS 813 “Domestic gas installations”.
b) All relevant national and local rules in force.
c) The current building regulations
INSTALLER GUIDE
Gas Conversion factor from net to gross efficiency
Natural Gas 0.901
LPG 0.921
© Baxi Heating U.K. Limited 2008. Page 8
Where no specific instructions are given, reference should be made to the relevant
British Standard Code of Practice.
4.2 If the appliance is intended to be installed to a chimney that was previously
used for solid fuel, the flue must be swept clean prior to installation. All flues should
be inspected for soundness and freedom from blockages.
4.3 Any chimney dampers or restrictors should be removed. If removal is not
possible they must be fixed in the open position.
4.4 Normal adventitious ventilation is usually sufficient to satisfy the ventilation
requirements of this appliance. In GB reference should be made to BS 5871 Part 2
and in IE reference should be made to the current edition of IS 813 “Domestic gas
Installations” which makes clear the conditions that must be met to demonstrate that
sufficient ventilation is available
4.5 Note that soft wall coverings (e.g. embossed vinyl, etc.) are easily affected by
heat. They may scorch or become discoloured when close to a heating appliance.
Please bear this in mind when installing.
4.6 The minimum allowable distance from the outside of the appliance fascia to a
corner wall having combustible material or any other combustible surface which
projects beyond the front of the appliance is 50mm at either side (See figure 1). No
side clearance is necessary to non-combustible surfaces.
INSTALLER GUIDE
Figure 1. Dimensions and clearances
© Baxi Heating U.K. Limited 2008. Page 9
4.7 The appliance must not be installed in any room, which contains a bath, or
shower or where steam is regularly present.
4.8 An extractor fan may only be used in the same room as this appliance, or in any
area from which ventilation for the appliance is taken, if it does not affect the safe
performance of the appliance. Note the spillage test requirements detailed further on
in this manual. If the fan is likely to affect the appliance, the appliance must not be
installed unless the fan is permanently disconnected.
4.9 The appliance is fitted with an A.S.D (Atmosphere sensing device). If the
appliance closes down after a period of operation for no apparent reason, the
consumer should be informed to stop using the appliance until the installation and
appliance have been thoroughly checked. The A.S.D will shut the appliance down if
an unacceptable amount of harmful products of combustion accumulate. Under no
circumstances should the A.S.D be altered or bypassed in any way. Only genuine
manufacturers’ replacement parts should be fitted.
4.10 Allow a minimum clearance of 90mm from the top surface of the appliance
fascia to the underside of any shelf whether it is made from combustible or non-
combustible materials. This clearance is necessary to allow the fascia to be lifted off
for servicing and also allows the owner sufficient access to operate the control knob.
For a shelf made from wood or other combustible materials deeper than 150mm,
add 12.5mm to the clearance for every 25mm of additional shelf depth (See graph 1).
Graph 1. Shelf clearances
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2008. Page 10
Indice
Altri manuali Valor Fires Camino da interno
Valor Fires
Valor Fires Artura 958 Manuale di istruzioni
Valor Fires
Valor Fires 347 Brava 4 Oxysafe Manuale di istruzioni
Valor Fires
Valor Fires Artura 958 Manuale di istruzioni
Valor Fires
Valor Fires 961 Homeflame Dream Manuale di istruzioni
Valor Fires
Valor Fires Artura 958 Istruzioni per l’uso
Valor Fires
Valor Fires 942 Istruzioni per l’uso
Valor Fires
Valor Fires 752 Istruzioni per l’uso
Valor Fires
Valor Fires 761 Manuale di istruzioni
Valor Fires
Valor Fires 940 Istruzioni per l’uso
Valor Fires
Valor Fires 824 Blenheim Longlite Istruzioni per l’uso
Valor Fires
Valor Fires 762 Istruzioni per l’uso
Valor Fires
Valor Fires 752 Istruzioni per l’uso
Valor Fires
Valor Fires 762 Istruzioni per l’uso
Valor Fires
Valor Fires 756 Istruzioni per l’uso
Valor Fires
Valor Fires 341 black beauty slimline Manuale di istruzioni
Valor Fires
Valor Fires 541 Istruzioni per l’uso
Valor Fires
Valor Fires 752 Istruzioni per l’uso
Valor Fires
Valor Fires 541 Camden Istruzioni per l’uso
Valor Fires
Valor Fires 339 Heartbeat Oxysafe 2 Istruzioni per l’uso
Valor Fires
Valor Fires 844 Istruzioni per l’uso
