Vaporesso TARGET PM30 Manuale utente
User Manual
VAPORESSO TARGET PM30
1English
PTF Slot
Drip Tip
Type-C Port
Power Button
Thank you for choosing Vaporesso product. Please read this instruction carefully before use to
ensure a perfect experience.
If there is any additional requirement about this product, please consult the local agent or
contact us through our website: www.vaporesso.com
ENGLISH
EXPLODED VIEW SPECIFICATIONS
Dimensions 22x26.7x117.1mm
POD Capacity 2ml / 3.5ml
Resistance GTX 0.6Ω MESH Coil (20-30W)
GTX 1.2Ω REGULAR Coil (8-12W)
Battery Capacity 1200mAh
Wattage 3-level adjustable wattage
Charging 5V/1A, Type-C
Battery Display Single 3-color LED Indicator
2English
USE INSTRUCTIONS
1. Install or replace the coil
Pull out the pod and then pull out the used coil. Install a new one rmly. Please make
sure the bottom notch of the coil is aligned with the both sides of the pod, or it may
cause leakage.
Correct Installation Incorrect Installation
X
2. Filling the E-juice
Slide the top cap to reveal the PTF slot, insert the e-liquid bottle nozzle to squeeze the
e-liquid through the slot. If it’s your rst time lling the e-liquid of this pod, please wait for
5 minutes for the e-liquid to soak into the coil.
1 2
3English
3. Power on/off
Click the power button 5 times in 2 seconds to power on or power off the device.
4. Waage adjustment
Click the power button 3 times continuously to adjust wattage levels.
LED Color GTX 0.6Ω MESH Coil GTX 1.2Ω REGULAR Coil
25W 12W
22W 10W
20W 8W
5. Start vaping
Press the power button to vape. For your safety, if you vape for more than 10 seconds
continuously, the light will ash 3 times and device will stop working temporarily.
1 2 3
4English
6. Charge the Baery
Connect the device and the standard charger via Type-C cable.
PROTECTIONS
Protections
Overtime Protection
Open-circuit Protection
Short-circuit Protection
Low Voltage
Over Discharge Protection
Over Charge Protection
Vape
High (70%-100%)
Medium (30%-70%)
Low (0-30%)
Baery StatusLED Color
Charge
Charged Completed
-
Under Charging
LED Status
Current color x 3
Current color x 3
x 5
x 3
x 3
Situation
Constantly vape for more than 10 seconds.
The device detects an open-circuit.
The device detects a short-circuit.
The voltage drops extremely low.
Press the re button when the voltage drops
extremely low.
Charging completed.
5English
1. Please turn off the device when it is not in use.
2. Do not leave the charging device unattended.
3. Do not drop, throw or abuse your device, which may cause damage.
4. Please use a standard USB output charger with proper charging current and voltage
range.
5. Keep away from the water or any ammable gas, liquid .
6. Do not expose the device to direct sunlight, dust, moisture or mechanical shock.
7. Do not expose the device to extreme temperature. (Recommended temperature range:
14~140 ℉while using and 14~113 ℉ while storing).
8. EEE Recycling: the product should not be treated as household waste, instead, it
should be handed over to the applicable collection point for the recycling of electrical and
electronic equipment.
9. Battery Recycling: the product battery should not be treated as household waste, instead,
it should be handed over to the applicable used battery collection point for recycling.
10. Only have your device repaired by Vaporesso. Do not attempt to repair it by yourself as
damage or personal injury may occur.
CAUTIONS
6English
WARNINGS
This refillable electronic cigarette is intended for use with compatible e-liquid, which may
contain nicotine. Nicotine is an addictive substance and it is not suitable or recommended to use
in following cases:
1. This device is not suitable for:
- Persons under the legal smoking age.
- Persons experiencing heart disease, stomach or duodenal ulcers, liver or kidney problems, long-
term throat disease or difcult breathing due to bronchitis, emphysema or asthma.
- Persons with an overactive thyroid gland or experiencing phaeochromocytoma (a tumour of the
adrenal gland that can affect blood pressure).
- Persons taking certain medications like Theophylline, Ropinirole or Clozapine and etc..
2. This device is not recommended for:
- Non-smokers
- Pregnant or breastfeeding women
3. You may experience the following results if you use nicotine containing e-liquid with this
product. If it happens, please consult a healthcare professional and show them this leaet if
possible:
Feeling faint/Nausea/Dizziness/Headache/Coughing/Irritation of the mouth or throat/Stomach
discomfort/Hiccups/Nasal congestion/Vomiting/Chest palpitations/pain or an irregular heart rate
This device should not be used by persons under the legal smoking age.
