Vaporesso Polar Manuale utente
Thank you for choosing Vaporesso Products!
Polar is the perfect match of brains and looks, packing in a beautiful 2
inch color screen, an elegant prismatic appearance along with the
featured Cascade Baby SE Sub-Ohm Tank.
0.001s Firing Speed brings you the most rapid and safe heating and
the purest rich flavor from the first puff to the last!
The upgraded OMNI Board 4.0 integrates Insta-Fire, Super Player
Mode and multiple protections. 2.5A quick charge can halve your
charging time.
Polar is optimized for users looking for some serious power output
with minimal fire delay. Experience instant vaping with Polar!
Please read this manual carefully to ensure proper use. For additional
information or questions regarding to this product or its use, please
visit www.vaporesso.com
MAIN FEATURES
● With the most rapid, stable yet safe firing rate of
0.001s
, Insta-fire
quick heating system brings you rich flavor and denser clouds from
the very first puff.
● Upgraded
OMNI BOARD 4.0
Additional
Super Player Mode (0.03-5Ω)
which is adaptive to
all Mainstream RDA Tanks.
● With a 2" TFT color screen, giving the eyes a true visual experience.
● Revolutionary triangular air flow producing a smoother, denser cloud.
● Unique Isolation Structure, allowing consistent, intense flavors with
every puff.
●
Child-Proof Lock Mechanism
, effectively avoid accidently
opening top cap and leaking e-juice.
SPECIFICATIONS
Dimension: 45x28x144mm
Display: 2" TFT Color Screen
Batteries: 2 x 18650 (Not Included)
Power Range: 5-220W
Voltage Range: up to 9V
Resistant Range: 0.03-5Ω(Super Player Mode Only)
Power Button
+
TFT
Mode Button
USB Charging Port
Drip tip
Top Lid
Air Flow Ring
Base
Pyrex glass tube
HOW TO USE
1. Switching On/Off
Press the fire button 5 times in quick succession within 2 seconds to turn
the device on. Using the same way, the device can be powered off after
5 presses.
2. Vaping
Hold the fire button and inhale through the mouthpiece. Release the fire
button and exhale.
3. Screen Display
Being switched on, the Color Screen displays voltage resistance, battery
level, temperature, output wattage etc. The display will change to Real
Time Clock after 10 seconds if unused and the Real Time Clock will be
shut off after 15 minutes if unused. Press “+” or “-“ or Mode button once
and the screen will be lit with Real Time Clock display, press button again
and the screen will be lit with main menu. Press the fire button at any time,
the screen will be lit with main menu.
4. Adjustment Buttons Lock/Unlock
Pressing mode and “+” button simultaneously for two seconds when the
device is powered on, then the up and down buttons will be locked and
the screen will display “SYSTEM LOCKED”. In the same way, pressing
the “+” and mode button can be unlocked and the screen will display
“SYSTEM UNLOCKED”.
5.Smart ON/OFF Setting
"When you turn on the smart function, it can change intensity according to
the coils resistance levels within a safe limit in VW-H/N/S mode."
How to operate: System Menu > SET > SMART ON/OFF
6.Auto ON/OFF
The Auto function taking away any operation difficulties switching between
VW-H and VW-N or between VT-H and VT-N.
How to operate: System Menu > SET > AUTO ON/OFF
7. Switch Vaping Modes
Long press the mode button for three seconds to switch among :
Smart VW(H/N/S) / VT(SS, Ni, Ti) / TCR(M1, M2) / BYPASS / CCT /
CCW / VV / CCV / Super Player (0.03-5Ω). Common mode introduction
is in below:
1) Smart VW Mode
As an advanced Variable Wattage mode, there are 3 levels of VW: H stands for High;
N stands for Normal; S stands for Soft. The default setting is Normal. VW(H/N/S) will
guarantee your mod’ s ability to skillfully select the adequate average wattage for your
atomizer, according to its resistance reading, automatically.
2) BYPASS Mode
Direct output voltage system is applied in Bypass mode. The higher the battery level is,
the higher the output voltage is. When set in this mode, the device can support a coil whose
resistance is within the range of 0.05-5ohm.
3) SUPER PLAYER Mode (Additional)
Adaptive to all Mainstream RDA Tanks
8. Adjustment of Air Flow
The bottom airflow system can be adjusted by twisting the airflow ring.
9. Filling E-liquid
Lift and twist the top lid counter clockwise to the fullest extent. Add your
favorite E-juice through the opening and slide the lid back. Allowing the
safety locking mechanism to secure the lid.
OPEN
3.50
CLOSE
WARNING:
When inserting the batteries into the new mod, remember to make
sure they are new, and that they are one of a pair. Unevenly
charged batteries, used batteries, or non-matching batteries may
cause significant delays in charging and affect the performance of
the device.
BATTERY PROTECTION
If you vape for more than 10 seconds without stopping, it will shut itself
down for your safety. OMNI Board also contains a lot of protections:
Short Circuit Protection / Low Voltage Protection / Overcharge Protection /
No Load Protection etc.
11. Charging
The Polar uses the Quick Charge and equalizing charge system. Simply
plug in the USB cable to charge the battery, the color screen will display
the current battery status.
10. Changing Atomizer
Remove base to unscrew the GT meshed coil and insert the new one.
Secure the base back onto the device. There are a variety of GT coils
available for Cascade Tank series. Please select the coil you desire.
OPEN
CLOSE
OPEN
CAUTION
1. It is intended for usage by people over 18, NOT by non-smokers,
children, pregnant or breastfeeding women, people with or at risk of
heart disease, or people taking medication for depression or asthma.
The electronic cigarette is not a smoking cessation device.
2. Please keep this unit out of reach of children or pets;
3. Please don't drop, throw or abuse your Mod,it may cause damage.
4. Do not place it in extremely temperatures;
5. Do not try to disassemble the battery.
This refillable electronic cigarette is intended for use with
compatible liquid, which may contain nicotine. Nicotine is an
addictive substance and its use is not recommended for use by
the following:
- Non smokers or persons under the legal smoking age
- Pregnant or breastfeeding women
- Persons experiencing heart disease, stomach or duodenal ulcers,
liver or kidney problems, long-term throat disease or difficulty breath-
ing due to bronchitis, emphysema or asthma.
- Persons with an overactive thyroid gland or experiencing phaeo-
chromocytoma (a tumour of the adrenal gland that can affect blood
pressure)
- Those taking the medications Theophylline, Ropinirole or Clozapone
You may experience the following side effects if you use nicotine
containing
e-liquid in combination with this product. If this happens, please
consult a
healthcare professional and show them this leaflet if possible:
Manufacturer:Shenzhen Smoore Technology Limited
Designed in California
Add:Building 8,Dongcai Industrial Park,Gushu Town,
Baoan District,Shenzhen, China 518102
Management System of SMOORE factory has been assessed
and registered under the Norm cGMP, ISO13485, ISO9001
and ISO14001.TM and ©2016 Vaporesso All rights reserved
- Feeling faint / - Nausea /- Dizziness /- Headache /- Coughing
- Chest palpitationspain or an irregular heart rate /- Irritation of the
mouth or throat
- Stomach discomfort /- Hiccups /- Nasal congestion/- Vomition
This device should not be used by persons under the age of
18 or non-smokers.
