Vaporesso XROS MINI Manuale utente

USER MANUAL

VAPORESSO XROS MINI

Thank you for choosing Vaporesso

product. Please read this instruction

carefully before use to ensure a perfect

experience. If there is any additional

requirement about this product, please

consult the local agent or contact us

through our website: www.vaporesso.com

EXPLODED VIEW

Dimensions: 98.9 x 23.4 x 13.5mm

POD Capacity: 2ml

POD Resistance: 1.2Ω or 0.8Ω

Battery Capacity: 1000mAh

Charging Current: DC 5V/1A, Type-C

Display: Single 3-Color LED Indicator

SPECIFICATIONS

Drip Tip

Filling Hole

Replaceable POD

LED Indicator

Type-C USB Port

PACKING LIST (1.2ΩVersion)

PACKING LIST (0.8ΩVersion)

1 x VAPORESSO XROS MINI Battery

1 x VAPORESSO XROS Series 1.2Ω POD (2ml)

1 x Type-C USB Cable

1 x User Manual

1 x Warranty Card

1 x VAPORESSO XROS MINI Battery

1 x VAPORESSO XROS Series 0.8Ω MESH POD (2ml)

1 x Type-C USB Cable

1 x User Manual

1 x Warranty Card

Figure 1: Replace the POD

Figure 2: Fill the E-liquid

ENGLISH

USE INSTRUCTIONS

1. Replace the POD

1) Pull out the used POD from the device;

2) Put the new POD into the device rmly.

2. Fill the E-liquid

- Snap off the drip tip from the POD;

- Gently insert the e-liquid lling bottle tip into the lling slot;

- Press down and squeeze the e-liquid through the slot;

- Install the drip tip back and conrm it’s shut rmly;

- Please wait 5 minutes for the e-liquid to soak into the coil completely.

3. Start Vaping

Inhale directly to enjoy extraordinary vaping experience.

4. Battery Level

LED Color Battery Status

High (70%-100%)

Medium (30%-70%)

Low (0%-30%)

PROTECTIONS

5. Charge the Battery

After connecting the Type-C cable to the device, the LED indicator will breathe in red light.

Once the battery is fully charged, the indicator will turn into green light.

Protections Situation Indicator

Low Resistance Protection The device detects an ultra-low resistance. x 5 Stop Output

Short-circuit Protection The device detects a short circuit. x 5 Stop Output

No Load Protection The device does not detect an atomizer. x 5 Stop Output

High Resistance Protection The device detect an ultra-high resistance. x 5 Stop Output

Low Voltage Protection The battery voltage drops too low. x 3 Stop Output

Over Charge Protection The device is fully charged. Stop Charging

Over Discharge Protection The battery voltage drops too low during

vaping.

x 3 Stop Output

Auto-Shut off Protection Constantly vape for 8 seconds or more. x 3 Stop Output

CAUTIONS

1. Please turn off the device when it is not in use.

2. Do not leave the charging device unattended.

3. Do not drop, throw or abuse your device, which may cause damage.

4. Please use a standard USB output charger with proper charging current and voltage range.

5. Keep away from the water or any ammable gas, liquid .

6. Do not expose the device to direct sunlight, dust, moisture or mechanical shock.

7. Do not expose the device to extreme temperature. (Recommended temperature range:

-10~60℃ /14~140 ℉ while using and -10~45℃ /14~113 ℉ while storing).

8. EEE Recycling: the product should not be treated as household waste, instead, it should

be handed over to the applicable collection point for the recycling of electrical and electronic

equipment.

9. Battery Recycling: the product battery should not be treated as household waste, instead, it

should be handed over to the applicable used battery collection point for recycling.

10. Only have your device repaired by Vaporesso. Do not attempt to repair it by yourself as damage

or personal injury may occur.
