Varytec 386284 Manuale utente

LED Typhoon PAR Outdoor 12x10,

LED Typhoon True PAR 12x10 Outdoor

LED outdoor PAR

User manual

Musikhaus Thomann

Thomann GmbH

Hans-Thomann-Straße 1

96138 Burgebrach

Germany

Telephone: +49 (0) 9546 9223-0

E-mail: [email protected]

Internet: www.thomann.de

25.01.2018, ID: 420255

Table of contents

1 General notes............................................................................................................................ 4

1.1 Further information........................................................................................................ 4

1.2 Notational conventions................................................................................................. 4

1.3 Symbols and signal words........................................................................................... 5

2 Safety instructions................................................................................................................. 6

3 Features....................................................................................................................................... 8

4 Installation................................................................................................................................. 9

5 Starting up............................................................................................................................... 11

6 Connections and controls................................................................................................ 12

7 Operating................................................................................................................................. 16

7.1 Starting the device....................................................................................................... 16

7.2 Main menu...................................................................................................................... 16

7.3 Menu overview.............................................................................................................. 19

7.4 Functions in 3-channel DMX mode........................................................................ 19

7.5 Functions in 6-channel DMX mode........................................................................ 20

7.6 Functions in 8-channel DMX mode........................................................................ 20

7.7 Functions in 10-channel DMX mode..................................................................... 20

7.8 Functions in 13-channel DMX mode..................................................................... 23

8 Technical specifications.................................................................................................... 26

9 Plug and connection assignment................................................................................. 27

10 Troubleshooting................................................................................................................... 28

11 Cleaning.................................................................................................................................... 29

12 Protecting the environment........................................................................................... 30

Table of contents

LED Typhoon PAR Outdoor 12x10, LED Typhoon True PAR 12x10 Outdoor 3

LED outdoor PAR

1 General notes

This manual contains important instructions for the safe operation of the unit. Read

and follow the safety instructions and all other instructions. Keep the manual for

future reference. Make sure that it is available to all those using the device. If you sell

the unit please make sure that the buyer also receives this manual.

Our products are subject to a process of continuous development. Thus, they are

subject to change.

1.1 Further information

On our website (www.thomann.de) you will find lots of further information and

details on the following points:

Download This manual is also available as PDF file for you to download.

Keyword search Use the search function in the electronic version to find the

topics of interest for you quickly.

Online guides Our online guides provide detailed information on technical

basics and terms.

Personal

consultation For personal consultation please contact our

technical hotline.

Service If you have any problems with the device the

customer service will gladly assist you.

1.2 Notational conventions

This manual uses the following notational conventions:

The letterings for connectors and controls are marked by square brackets and italics.

Examples: [VOLUME] control, [Mono] button.

Texts and values displayed on the device are marked by quotation marks and italics.

Examples: ‘24ch’, ‘OFF’.

Letterings

Displays

General notes

4LED Typhoon PAR Outdoor 12x10, LED Typhoon True PAR 12x10 Outdoor

LED outdoor PAR

The individual steps of an instruction are numbered consecutively. The result of a

step is indented and highlighted by an arrow.

Example:

1. Switch on the device.

2. Press [Auto].

ðAutomatic operation is started.

3. Switch off the device.

1.3 Symbols and signal words

In this section you will find an overview of the meaning of symbols and signal words

that are used in this manual.

Signal word Meaning

DANGER! This combination of symbol and signal word indicates

an immediate dangerous situation that will result in

death or serious injury if it is not avoided.

WARNING! This combination of symbol and signal word indicates

a possible dangerous situation that can result in death

or serious injury if it is not avoided.

NOTICE! This combination of symbol and signal word indicates

a possible dangerous situation that can result in mate-

rial and environmental damage if it is not avoided.

Warning signs Type of danger

Warning – high-voltage.

Warning – hot surface.

Warning – suspended load.

Warning – danger zone.

Instructions

General notes

LED Typhoon PAR Outdoor 12x10, LED Typhoon True PAR 12x10 Outdoor 5

LED outdoor PAR

2 Safety instructions

This device is intended to be used as an electronic illumination effect using LED tech-

nics. The device is designed for professional use and is not suitable for use in house-

holds. Use the device only as described in this user manual. Any other use or use

under other operating conditions is considered to be improper and may result in per-

sonal injury or property damage. No liability will be assumed for damages resulting

from improper use.

This device may be used only by persons with sufficient physical, sensorial, and intel-

lectual abilities and having corresponding knowledge and experience. Other persons

may use this device only if they are supervised or instructed by a person who is

responsible for their safety.

DANGER!

Danger for children

Ensure that plastic bags, packaging, etc. are disposed of properly and

are not within reach of babies and young children. Choking hazard!

Ensure that children do not detach any small parts (e.g. knobs or the

like) from the unit. They could swallow the pieces and choke!

Never let children unattended use electrical devices.

DANGER!

Electric shock caused by short-circuit

Do not modify the mains cable or the plug. Failure to do so could result

in electric shock/death or fire. If in doubt, seek advice from a registered

electrician.

DANGER!

Electric shock caused by high voltages inside

Within the device there are areas where high voltages may be present.

Never remove any covers.

There are no user-serviceable parts inside.

Do not use the device if covers, protectors or optical components are

missing or damaged.

WARNING!

Eye damage caused by high light intensity

Never look directly into the light source.

Intended use

Safety

Safety instructions

6LED Typhoon PAR Outdoor 12x10, LED Typhoon True PAR 12x10 Outdoor

LED outdoor PAR

WARNING!

Risk of epileptic shock

Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive

persons should avoid looking at strobe lights.

WARNING!

Risk of burns

The surface of the device can become very hot during operation.

Do not touch the device with bare hands during operation, and after

switching off wait for at least 15 minutes.

NOTICE!

Risk of fire

Do not block areas of ventilation. Do not install the device near any

direct heat source. Keep the device away from naked flames.

NOTICE!

Power supply

Before connecting the device, ensure that the input voltage (AC outlet)

matches the voltage rating of the device and that the AC outlet is pro-

tected by a residual current circuit breaker. Failure to do so could result

in damage to the device and possibly injure the user.

Unplug the device before electrical storms occur and when it is unused

for long periods of time to reduce the risk of electric shock or fire.

Safety instructions

LED Typhoon PAR Outdoor 12x10, LED Typhoon True PAR 12x10 Outdoor 7

LED outdoor PAR

3 Features

Due to its sturdy and weather-proof housing made of die-cast aluminium, the device

is especially suitable for outdoor use. With the very bright six-colour LEDs, it is partic-

ularly suitable for professional lighting tasks.

Special features of the device:

n12 × six-colour LEDs (RGBWAUV, each 10 W)

nControl via DMX and via buttons and display on the unit

nBuilt-in automatic show programmes

nMaster / Slave operation

nProtection class IP65

nSturdy double bracket for secure attachment to trusses or firm footing on the

ground

nConnections for power supply and DMX control by means of

– LED Typhoon PAR Outdoor 12x10 (item no. 386284): permanently connected

cables with splash-proof screwable and lockable plugs and couplings

– LED Typhoon True PAR 12x10 Outdoor (item no. 420255): splash-proof

screwable and lockable plugs and couplings

nMains power adapter with safety plug included

nRugged die-cast aluminium housing

nPressure compensation element (prevents condensation inside the device)

Equipment with protection class IP65 are dust-tight and completely protected

against contact (first code number). They are also protected against splash water

from any angle (second code digit). That is why this equipment can also be used out-

doors. Event technology equipment is generally only designed for temporary use

however (event lighting) and not for permanent use outdoors.

The specified protection class does not make a statement about the weather resist-

ance of the equipment (resistance to changing ambient conditions as well as against

the effects of sunlight and UV rays).

The seals and screw connections of the equipment must be checked regularly to

ensure a fault-free operation. In cases of doubt, consult a specialist workshop in due

time.

Information about protection class

IP65

Features

8LED Typhoon PAR Outdoor 12x10, LED Typhoon True PAR 12x10 Outdoor

LED outdoor PAR

4 Installation

Unpack and carefully check that there is no transportation damage before using the

unit. Keep the equipment packaging. To fully protect the device against vibration,

dust and moisture during transportation or storage use the original packaging or

your own packaging material suitable for transport or storage, respectively.

WARNING!

Risk of injury caused by falling objects

Make sure that the installation complies with the standards and rules

that apply in your country. Always secure the device with a secondary

safety attachment, such as a safety cable or a safety chain.

NOTICE!

Risk of overheating

Always ensure sufficient ventilation.

The ambient temperature must not exceed the limits stated in the

chapter Technical Specifications of the User Manual.

NOTICE!

Use of stands

When mounting the device onto a stand, ensure that the stand is in a

safe and stable position and that the weight of the device does not

exceed the maximum permissible load capacity of the stand.

NOTICE!

Possible data transmission errors

For error-free operation make use of dedicated DMX cables and do not

use ordinary microphone cables.

Never connect the DMX input or output to audio devices such as mixers

or amplifiers.

NOTICE!

Possible damage due to moisture

Moisture entering into open connectors (plugs and couplers) of DMX or

power cords can cause short circuits.

Close unused connectors with end caps intended for this purpose

(www.thomann.de).

Installation

LED Typhoon PAR Outdoor 12x10, LED Typhoon True PAR 12x10 Outdoor 9

LED outdoor PAR

You can install the unit in hanging or standing position. When in use, the device must

always be attached to a solid surface or an approved truss. Use the openings pro-

vided on the two-piece bracket for attaching.

Always work from a stable platform whenever installing, moving or servicing the

unit. In doing so, the area underneath the unit must be cordoned off.

The safety cable must be attached to the bracket (with item no. 386284) or to the

safety eyelet (item no. 420255).

Please note that this device must not be connected to a dimmer.

Mounting options

Installation

10 LED Typhoon PAR Outdoor 12x10, LED Typhoon True PAR 12x10 Outdoor

LED outdoor PAR

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Varytec Attrezzatura per DJ

Varytec

Varytec LED AccuWash MKII 12x8W RGBW IP65 Manuale utente

Varytec

Varytec Hero Spot Wash 80 Manuale utente

Varytec

Varytec LED Pad 7 Manuale utente

Varytec

Varytec LA VIDA Manuale utente

Varytec

Varytec LED PAR XS 7X15W RGBW IP65 Manuale utente

Varytec

Varytec Fan FX Manuale utente

Varytec

Varytec BAT.PAR 144 RGBW Manuale utente

Varytec

Varytec Giga Bar Pix 8 UV Manuale utente

Varytec

Varytec LED Magicball Manuale utente

Varytec

Varytec LED Pad Bar Compact ST RGB Manuale utente

Varytec

Varytec LED Pad 7 7x10W 6in1 RGBWAUV Manuale utente

Varytec

Varytec Hero Spot Wash 140 WH 2in1 Manuale utente

Varytec

Varytec LED Typhoon Strobe Manuale utente

Varytec

Varytec Star Shot Laser FX Manuale utente

Varytec

Varytec LED PAR 14x8W Manuale utente

Varytec

Varytec Studio Par Mini Manuale utente

Varytec

Varytec LED RealBeam 7 RGBW Manuale utente

Varytec

Varytec 103340 Manuale utente

Varytec

Varytec BAT.BALL 6in1 RGBWAP Manuale utente

Varytec

Varytec Spot 90 Manuale utente

Varytec

Varytec LED Street Bar MK II 16x8W RGBW 4in1 IP65 Manuale utente

Varytec

Varytec LPS 20 Manuale utente

Varytec

Varytec Progression II Manuale utente

Varytec

Varytec BAT.PAR 6 RGBWA Manuale utente

Manuali Attrezzatura per DJ popolari di altre marche

ALPHA LITE

ALPHA LITE ALPHA 1500 Manuale del proprietario

Chauvet

Chauvet OVATION E-930VW Manuale utente

Zumtobel

Zumtobel APHRODITE Home Manuale utente

Snow Masters

Snow Masters Zig Oscillator Manuale utente

EuroLite

EuroLite 50530554 Manuale utente

Beamz

Beamz BUV243 Manuale utente

thomann

thomann Stairville DJ Lase 40-G MK-III Manuale utente

Eagletone

Eagletone 6 Eyes Flower Manuale utente

EuroLite

EuroLite FLD-1508 Manuale utente

Technical Pro

Technical Pro LG8xSEA Manuale utente

JB Systems

JB Systems Lounge Laser DMX Manuale utente

Lightmaxx

Lightmaxx Vega Halo 90 Manuale utente

Elation

Elation FUZE WASH Z350 Manuale utente

Maverick

Maverick MK3 WASH Manuale utente

Infinity

Infinity TF-260C7 Fresnel Manuale utente

Chauvet

Chauvet EVE E-50Z Manuale utente

Eliminator Lighting

Eliminator Lighting E 138 Manuale utente

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manuale utente
