Varytec LED Magicball Manuale utente

Manual

LED Magicball

2 / 8

3 / 8

Table of contents

Safety instructions............................................................................................................................ 4

1.1.

FOR SAFE AND EFFICIENT OPERATION............................................................................ 4

Introduction....................................................................................................................................... 5

2.1.

Modes...................................................................................................................................... 6

2.1.1.

Sound-to-light .................................................................................................................. 6

2.1.2.

Automatic programs ........................................................................................................ 6

Technical data.................................................................................................................................. 6

4 / 8

1. Safety instructions

•This device is suitable for indoor use (not outdoors) only.

•All modifications to the device will void the warranty.

•Repairs are to carry out by skilled personnel only.

•Use only fuses of the same type and original parts as spare parts.

•Protect the unit from rain and humidity to avoid fire and electric shocks.

•Make sure to unplug the power supply before opening the housing.

1.1.FOR SAFE AND EFFICIENT OPERATION

Be careful with heat and extreme temperature

Avoid exposing it to direct rays of the sun or near a heating appliance.

Not put it in a temperature bellow 32°F /0°C, or exceeding 104°F /40°C.

Keep away from humidity, water and dust

Do not place the set in a location with high humidity or lots of dust.

Containers with water should not be placed on the set.

To avoid placing on un-stable location

Select a level and stable location to avoid vibration.

Do not use chemicals or volatile liquids for cleaning

Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.

If out of work, contact sales agency immediately

Any troubles arose, remove the power plug soon, and contact with an engineer for repairing,

do not open the cabinet by yourself, it might result a danger of electric shock.

Take care with the power cable

Never pull the power cable to remove the plug from the receptacle, be sure to hold the plug.

When not using the device for an extended period of time, be sure to disconnect the plug

from the receptacle

5 / 8

Important: Damages caused by the disregard of this user manual are not subject to

warranty. The dealer will not accept liability for any resulting defects or problems. Make sure

the electrical connection is carried out by qualified personnel. All electrical and mechanical

connections have to be carried out according to the European safety standards.

2. Introduction

Thank you for purchasing the "LED Magic Ball", a light effect for domestic use. The device is supplied

with a remote control and is only with this to use. You can choose between two different sound-to-light

modes and 7 different automatic programs via the remote.

1. ON/OFF: With this button you switch the device on or off.

2. Sound-activate: With this button you can choose between two sound-to-light modes.

3. Auto programs: With these buttons you can choose between 7 automatic programs.

6 / 8

2.1.Modes

2.1.1. Sound-to-light

S1 Sound trigger color change: Strobe, ON, OFF

S2 Sound trigger color change, no strobe

2.1.2. Automatic programs

A1 Color change: Red, Red/Yellow, Red/Pink

A2 Color change: Green, Red/Green, Green/Yellow

A3 Color change: Blue, White

A4 Color change (3 colors)

A5 Color change (7 colors)

A6 Color change, no strobe

A7 Strobe

3. Technical data

Power supply AC 90-240V; 50/60Hz

LED 6x1W LED

Power consumption Max. 8W

Modes Automatic, Sound-to-Light

Control via remote (IR)

Weight 0.56 kg

7 / 8

8 / 8

Importer:

B & K Braun GmbH

Industriestraße 2

D-76307 Karlsbad

www.bkbraun.com

info@bkbraun.com
