Vauxhall 2013 Combo Manuale utente

COMBO

©Copyright by Vauxhall Motors Ltd., England.

Reproduction or translation, in whole or in parts, is not

permitted without prior written consent from Vauxhall Motors

Ltd.

All rights as understood under the copyright laws are explicitly

reserved by Vauxhall Motors Ltd.

All information, illustrations and specifications contained in this

manual are based on the latest production information

available at the time of publication.

The right is reserved to make changes at any time without

notice.

Edition: January 2007.

TS 1649-B-07

COMBO

Operation, Safety and Maintenance

Owner’s Manual

VAUXHALL Combo

Operation, Safety, Maintenance

Data specific to your vehicle

Please enter your vehicle’s data here to keep it ea sily accessible.

This information is available under the section "Technical data " as well as on the identification plate and in the Service Booklet.

Fuel

Designation

Engine oil

Grade

Viscosity

Tyre pressure

Tyre size for loa d with 1 p erson and

lig ht lugga ge

wi th full load

Summer tyres Front Rear Front Rear

Winter tyres Front Rear Front Rear

Weights

Permissible gross vehicle weight

– ECkerbweight

=Loading

Your Combo

Developed to the latest findings of

automobile research, it offers technical

sophistication and exceptional comfort.

Your vehicle represents an intelligent

synthesis of advanced technology,

outstanding safety, environmental

compatibility and economy.

It now lies with you to drive your vehicle

safely and to see it it performs perfectly.

This Owner’s M anual provides you with all

the necessary information to that end.

Make sure your passengers are aware

of the possible risk of accident and injury

which may result from improper use of the

vehic le.

You must always comply w ith the sp ecific

laws of the country that you are travelling.

These laws m ay differ from the information

in this Owner’s Manual.

The Owner’s Manualshould always be kept

in the vehicle: Ready to hand in the glove

compartment.

Make use of the Owner’s Manual:

zThe "In Brief" section will give you an

initial overview.

zThe table of contents at the start of the

Owner’s Manual and in each individual

chapter will help you find your way.

zIts index will help you find what you

want.

zIt w ill fa miliarise you with the

sophisticated technology.

zIt will increase your pleasure in your

vehicle.

zIt will help you to handle your vehicle

expertly.

The Owner’s Manual is designed to be

clearly laid out and easily understood.

This sym bol signifies:

6Continue reading on next page.

3The asterisk signifies equipment not

fitted to all vehicles (model variants,

engine options, models specific to one

country, optional equipment, Genuine

Vauxhall Parts and Accessories).

Yellow arrows in the illustrations serve as

points of reference or indicate some action

to be performed.

Black arrows in the illustrations indicate

a reaction or a second action to be

performed.

Thank you for choosing a Vauxhall. We

wish you many hours of pleasurable

driving.

Your Vauxhall Team

9Warnin g

Text marked 9Warning provides

information on risk of accident or injury.

Disregard of the instructions may lead to

injuries or endanger life.

Inform your passengers accordingly.

Contents Commitment to customer

satisfaction:

Our ai m: to keep you happy with your

vehicle. All Vauxhall Authorised Repairers

offer first-class service at competitive

prices. Experienced, factory-trained

technicians w ork according to factory

instructions. Your Authorised Repairer can

supply you with GENUINE VAU XHALL-

APPROVED PARTS, which have undergone

stringent quality and precision checks, and

of course useful and attractive

VAUXHALL-APPROVED ACCESSORIES.

Our name is your guarantee!

For d eta ils of the

Va uxhall Authorised Rep airer Ne tw ork,

pleasering this number; 0845 090 2044

In Brief ................... .... ..... .......................... . 2

Instrum ents ............ ......... ......... ......... ...... 24

Keys, Doors, Bonnet ................ .... ..... ...... 44

Seats, Interior ..... .... ............................... .. 63

Safety system s ....... ......... ......... ............... 75

Lighting ..... .... ..... .......................... ..... .... .. 93

Windows .......................... .... ..... ............... 98

C lim ate c ontrol .. ........ ......... ......... ......... 101

Easytronic ........................... ..... .... ......... 111

Driving hints ...... .... .... ........................... 117

Saving Fuel,

Protecting the Env ironment ............. 119

Fuel consum ption, fuel, refuelling ...... 121

Catalytic converter, exhaust gases .... 124

Brakes ... ..... .... ........................... .... ..... .... 128

Wheels, tyres ............................ .... ..... .... 132

Roof racks,

Carava n and trailer towing ........ .... 138

Self-help ............. .... .... ........................... 143

If you ha ve a problem ... ......... ......... .... 178

Maintenance, Inspec tion S ystem .... .... 180

Vehicle care ........... .... ..... ...................... 191

Technical Data ..... .... ........................... 196

Index . .... ............................... ..... .... ......... 212

2InBrief

In Brief

Picture no: 15760t.tif

Key nu mbers,

Code numbers

Remove key number from keys.

The key number is specified in the vehicle

docum ents and in the Car Pass 3.

Alloy wheels 3, towing e quip ment 3: make

a note of the key identifier codes.

Electronic imm obilizer, infotainment

sy ste m 3: The code numb ers are specifie d

in the Ca r Pass.

Do not keep the Car Pass in the vehicle.

For key with retractable blade 3, press the

button to extend.

6Further information – see pages 44, 45,

vehicle recommissioning – page 190.

Picture no: 18079s.tif

To unlock the vehicle and

open the doors:

With key in lock

turn key towards front of

vehicle or press button q

on the remote control 3,

pull door handle and open door or

sliding door 3.

Unlocking the door from inside:

Pull up on lock button.

6Sliding door 3 – see page 54.

door locks, child safety locks 3–

see page 46,

electronic immobilizer – see page 45,

radio frequency remote control 3 –

see page 47,

central loc king system 3 – see page 51,

Vauxhall alarm system 3– see page 58.

3In Brief

Picture no: 18080s.tif

To unlock and open tailgate 3:

Turn key to horizontal position or

press bu tto n qon the remote

control 3,

press bu tto n a nd

open tailgate upwards.

When using the remote control, the tailgate

is only unlocked if the key slot in the b utton

is in the horizonta l position.

If the key slot is in the vertical position, the

tailgate is always locked.

6 Radio frequency remote control 3 –

see page 47,

central locking system 3 – see page 51,

Vauxhall alarm system 3– see page 58,

tailgate 3 – see page 55.

Picture no: 18081s.tif

To unlock and open rear doors 3:

Turn key to vertical position or

press button q on the remo te

control 3,

pull handle and open rear door.

To open the left rear, pivot the

handle on the inside.

When using the remote control, the rear

doors are only unlocked if the keyslot in the

lock is in the vertical position.

If the key slot is in the horizontal position,

the rear doors are always locked.

6 Radio frequency remote control 3 –

see page 47,

central locking system 3 – see page 51,

Vauxhall alarm system 3– see page 58,

rear doors 3 – see page 56.

Picture no: 13189s.tif

To adjust fron t seat 3:

Pull handle,

slide seat,

release handle,

allow seat to audibly latch into

position

Never adjustthe seat whilst driving. Itcould

move in an uncontrolled manner when the

handle has been pulled.

6Sea t position – see pa ge 63.

9Warnin g

Important: Do not sit nearer than 10

inches (25 cm) from the steering wheel,to

permit safe airbag deployment.

4InBrief

Picture no: 13714s.tif

To adjust front seat backrests:

Turn handwheel

Move seatbackresttosuitseating position.

Do not lean on sea t backrest whilst

adjusting it.

6Seat position – see page 63.

Picture no: 12429s.tif

To adjust front seat height 3:

Pull lever at side

Liftlever and relieve some weightfrom seat

to raise it or pressdown on seat with body

weight to lower it.

Never adjustthe driver’s seat whilstdriving.

It could move in an uncontrolled manner

when the lever has been pulled.

6Seat position – see page 63.

Picture no: 11536s.tif

To fold front seat backrest 3:

Raise lever

To enter and leave the rear seat area, tilt

front seat back forwards.

6Sea t position – see pa ge 63.

5In Brief

Picture no: 13781s.tif

To adjust height 3of front and

outboard rear head restraints:

Tip forward to release,

hold and adjust h eigh t,

release

6Head restraint p osition – see page 63,

further information, removal –

see page 64,

centre rear head restraint 3 – see page 64.

Picture no: 18082s.tif

To adjust interior mirror:

Swivel mirror housing

Swivel lever on underside of mirrorhousing

to reduce dazzle at night.
