Velleman VM120 Manuale utente
VM120
12V light effect generator 3
12V tien kanaals lichteffect generator 12
10-Kanal-Lichteffektgenerator, 12V 30
Generador de efectos luminosos de 10 canales, 12V 39
12V LIGHT EFFECT GENERATOR
Générateur d’effets lumineux à 10 canaux, 12V 21
3
Thank you for purchasing this module. Please read the instructions carefully to ensure correct and safe use of this device.
WARRANTY
This product is guaranteed against defects in components and construction from the moment it is purchased and for a period of ONE YEAR starting from the
date of sale. This guarantee is only valid if the unit is submitted together with the original purchase invoice. VELLEMAN components Ltd limits its responsibi-
lity to the reparation of defects or, as VELLEMAN components Ltd deems necessary, to the replacement or reparation of defective components. Costs and
risks connected to the transport, removal or placement of the product, or any other costs directly or indirectly connected to the repair, will not be reimbursed by
VELLEMAN components Ltd. VELLEMAN components Ltd will not be held responsible for any damages caused by the malfunctioning of a unit.
CONTENTS :
FEATURES & SPECIFICATIONS......................................................................................................................................................... 4
OPTIONS .............................................................................................................................................................................................. 5
CONNECTION....................................................................................................................................................................................... 6
LIGHT EFFECTS .................................................................................................................................................................................. 8
SAFETY & WARNING INSTRUCTIONS............................................................................................................................................ 11
Warnings and contents
READ THE OPERATING AND MAINTENANCE INSTRUCTIONS IN
THIS USER’S GUIDE CAREFULLY.
4
Specifications & features
SPECIFICATIONS & FEATURES
FEATURES
Ten, 12V/400mA outputs
To control cold-cathode fluorescent lamps (using FLPS adapter), light bulbs, LED’s and “solid state” relays, ...
For use as advertisement lighting, party lights, disco, eye-catcher, ...
Ten pre-programmed light patterns selectable with a push button.
The number of used channels is adjustable.
Non volatile memory for last used light effect
Adjustable speed
LED indication for every output.
12V operation possible for use in cars.
SPECIFICATIONS
Power supply : 12V DC
Outputs : 12V DC/400mA per channel (Total : max 4A)
Dimensions : 140 x 100 x 27mm / 5,5 x 3,9 x 1,1”
5
Supply adaptor 12V output 5.5A: PSS1255
Cut off the connector, determine the adapter's polarity and connect the
adapter to the module. RESPECT THE POLARITY!!!
Power supply for cold-cathode fluorescent lamps : FLPS (300mm) or FLPS1 (100mm)
Cold-cathode fluorescent lamps : FL(xx) – (100 or 300mm)
SOLID-STATE relays VR25SS1A or VR3SS1A to drive mains voltage lamps
Options
VR25SS1AVR3SS1A
OPTIONS
6
Connection
OR !
12VDC / max 4A
12VDC/400mA per
channel
HIGH
VOLTAGE!
12VINPUT
Cold-cathode
fluorescent lamps
Inverter FLPS
12V bulb
400mA max.
CONNECTION
Speedadjust
7
Connection
Connect this module according to the connection diagram:
Connect a 12V DC power supply to the – 12 + connections. Respect the polarity! When polarity is reversed, the fuse will
blow.
Up to 10 loads can be connected to the outputs. These can be small lamps, relays or cold-cathode fluorescent lamps. The
current in each separate channel cannot surpass 400mA. Respect the polarity!
When a correct power supply is connected, LED LD1 will light up. All 10 red LEDs will already display a light effect .
Be careful when connecting the cold cathode fluorescent lamps: the ‘FLPS1’ power supply module generates a
life-threatening voltage over the lamp connectors, which may cause electroshocks.
Settings:
Before switching on the module, set the jumper to indicate how many lamps are connected.
For example : to make a 4-channel running light, set the jumper to ‘4 CH’.
If the module is powered on without the jumper, the 10 channels will flash simultaneously ; this way the module can be used
as a 10-channel flashing light with adjustable speed.
8
Choosing light effects :
The SW1 ‘Effect select’ pushbutton switch allows you to choose between ten programs. Keep SW1 pressed to see the se-
lected effect – the LED corresponding to that effect will light up. The effect starts when you release SW1. Press SW1 briefly
to select the next effect.
SW2 allows you to (de)activate all channels at once. Press SW1 to restart the selected light effect.
The speed of the light effect can be adjusted with RV1.
The last selected effect is saved in the internal memory in case of a power failure.
Select a random light effect:
Keep SW2 pressed during power-up (the other light effects will not work!).
HINTS:
• In case of an overload or a short circuit on one of the outputs, the control transistor of that channel (T1...T10) will be
damaged. Replace it by a transistor of the same type (BC640).
• Velleman cannot be held responsible and all warranty becomes void in case of user modifications to the module.
• A blown fuse always has to be replaced by a fuse of the same type (4A – FAST) to avoid fire hazard.
LIGHT EFFECTS
Light effects
9
L
L
L
L
L
Light effect 1 Light effect 2 Light effect 3 Light effect 4 Light effect 5
LED 1 / CHANNEL 1
LED 2 / CHANNEL 2
LED 3 / CHANNEL 3
LED 4 / CHANNEL 4
LED 5 / CHANNEL 5
LED 6 / CHANNEL 6
LED 7 / CHANNEL 7
LED 8 / CHANNEL 8
LED 9 / CHANNEL 9
LED 10 / CHANNEL 10
Light effects
10
L
L
LED 1 / CHANNEL 1
LED 2 / CHANNEL 2
LED 3 / CHANNEL 3
LED 4 / CHANNEL 4
LED 5 / CHANNEL 5
LED 6 / CHANNEL 6
LED 7 / CHANNEL 7
LED 8 / CHANNEL 8
LED 9 / CHANNEL 9
LED 10 / CHANNEL 10
Light effect 6 Light effect 7 Light effect 8 Light effect 9
Light effects
Light effect 10 is a sequence of light effects 1
to 9, each played 5 times.
