Product Description
Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning 5
Models
441483, 441484, 441485, 441486, 446756, 446757, 446758, 446759 - Sentinel Kinetic with Cooker
Hood and with summer bypass. An internal damper is activated when the outside temperature is equal to,
or greater than, the pre-set ‘Comfort Temperature’ (adjustable between 16 and 30°C). The damper opens
allowing cooler fresh air to bypass the Heat Recovery Cell and reduce the internal temperature to the pre-
set ‘Comfort Temperature’. When the inside air temperature reaches the pre set ‘Comfort Temperature’ the
bypass damper closes. (See page 10 within the Operation & Monitoring leaflet for further information).
Note that when the cooker hood is extended the heat recovery cell bypass opens ensuring that grease and
other contaminants from cooking do not reduce its efficiency during normal use.
Accessories
441838 - Plug-in integral humidity sensor. (Fitted as standard on models 446756,446757,446758 & 446759
441865 - Wireless enable kit (consists of wireless receiver and one wireless switch).
437827 - Additional wireless switch (up to four may be connected).
443131 –Wired remote control.
A range of sensors can be used to manage system demand and control the ventilation rate. These include an
internal humidity sensor, humidity sensors for independent mounting in rooms, wireless receiver and wireless
boost switches, CO2sensor, manual switches and pull cords. For these alternative control options, see
www.vent-axia.com
User Information
Operation of Cooker Hood
The unit is operated in boost mode when the telescopic hood is pulled out. Close it to return the unit to its
Normal Flow Rate.
Important Note:
Do not hold on to or place any object on telescopic hood whilst is open, since this can cause damage to its
functioning component parts
Operation of Cooker Hood Light
Access can be gained to the light switch when the telescopic hood is opened. The light may be left on with the
hood closed if required. However, make sure you switch it off when you have finished using it.
Cleaning Instruction
Refer to page 15 of this document.
