VeriFone Carbon Mobile 5 Manuale utente
EN
Verifone Android
Carbon Mobile 5 with Printer
Document APM Version 5
Software Version: CM5-O-3.11.4
User Guide
Alternative Payment CM5P
2
EN
Table of Contents
ALTERNATIVE PAYMENT.......................................................................................................................................................... 3
Purchase transaction with Swish......................................................................................................................................... 4
Refund transaction with Swish ............................................................................................................................................ 5
Purchase transaction with Klarna........................................................................................................................................ 9
Refund transaction with Klarna ......................................................................................................................................... 12
Purchase transaction with MobilePay ...............................................................................................................................15
Purchase transaction with Vipps ....................................................................................................................................... 17
User Guide
Alternative Payment CM5P
3
EN
ALTERNATIVE PAYMENT
Description
Alternative payment methods are defined as a way of paying for goods or
services which are not made via cash or major card schemes (Visa,
MasterCard etc).
The merchant is prompted to enter the amount of the transaction. The
transaction amount is validated to ensure that the maximum amount is
not exceeded. Purchase transactions with amount 0.00 are not allowed.
User action
Selecting the “Card” button starts the card payment.
Selecting the “Other” button presents the user with other transaction
options such as refund.
Pressing the “C” button will reset the current amount. The top left menu
gives access to administrative functions.
Description
After the amount has been entered, and the button “Card” has been
selected, the customer can select other payment options.
User action
The user must choose between offered other payment options. (this guide
describes APMs such as Klarna, MobilePay, Swish and Vipps)
User Guide
Alternative Payment CM5P
4
EN
Purchase transaction with Swish
Description
After the user has selected the Swish icon at the card prompt, the terminal
will display a QR code.
User action
The customer must use the Swish application on mobile device, to scan
the QR code.
The customer must complete the required steps in Swish mobile
application to complete the payment.
The user can cancel the transaction, by selecting the “Cancel” button.
Description
After the customer has finished payment processing in Swish application,
the device will show options to print customer receipt. These options may
differ depending on the configuration.
User action
To print the customer receipt, the user must select the “Print” button.
To email the customer receipt, the user must select the “Email” button.
To print and email the customer receipt, the user must select the “Print &
Email” button.
If the customer does not want a receipt, the user must select the “No
Thanks” button.
User Guide
Alternative Payment CM5P
5
EN
Description
After the receipts are printed, the device will show approval screen which
indicates that transaction has been successful.
Refund transaction with Swish
Description
To perform a refund transaction with Swish application, the user needs to
know the total amount and the Gateway Transaction ID of the original
Swish transaction.
The merchant is prompted to enter the amount of the transaction. The
transaction amount is validated to make sure it does not exceed the
maximum amount. Refund transactions with an amount of 0.00 are not
allowed.
Pressing the ”C” button will reset the current amount.
The top right menu allows the merchant to clear the amount.
The top left menu gives access to administrative functions.
Selecting the “Other” button presents the user with other transaction
options such as refund.
User action
The user must select the “Other” button to access the refund option.
User Guide
Alternative Payment CM5P
6
EN
Description
By selecting the “Other” button, the terminal will display the non-
purchase transaction types.
User action
The user must select the “Refund” button.
Description
If the user authentication feature is enabled, the user is prompted for the
passcode before performing refund transaction.
User action
The user must enter the cashier, the merchant or the admin passcode, to
proceed with the processing of the refund transaction.
User Guide
Alternative Payment CM5P
7
EN
Description
After user authentication the customer can choose between other
payment options.
User action
The user selects the Swish icon.
Description
After the “Swish” icon has been selected, the user can choose between
refund options.
User action
The user can enter Transaction ID (Gateway Transaction ID can be found
on the purchase receipt) to refund a transaction. After the transaction ID
is entered, the user must press the “Submit” button.
The user can select the “Previous Swish Transaction” button to refund last
successful Swish transaction.
User Guide
Alternative Payment CM5P
8
EN
Description
After the user has selected preferred refund option for Swish transaction,
the terminal indicated that it is processing the payment data, by showing
“Please Wait…” screen.
User action
The user is not required to do any action at this stage.
Description
When the payment data has been processed, the terminal will show a
“Refunded” screen. This informs the customer that the transaction has
completed successfully. The device will show options to print customer
receipt. These options may differ depending on the configurations.
User action
To print the customer receipt, the user must select the “Print” button.
To email the customer receipt, the user must select the “Email” button.
To print and email the customer receipt, the user must select the “Print &
Email” button.
If the customer does not want a receipt, the user must select the “No
Thanks” button.
User Guide
Alternative Payment CM5P
9
EN
Description
After the receipts are printed, the device will show approval screen which
indicates that transaction has been successful.
Purchase transaction with Klarna
Description
After the user has selected the Klarna icon at the card prompt, the
terminal will display a QR code.
User action
The customer must use a mobile device camera, to scan the QR code. The
code will lead the customer to the Klarna webpage, where the customer
must fill in all required data.
The customer can choose to receive the link to Klarna webpage via SMS
by selecting the “SMS” button.
The user can cancel the transaction, by selecting the “Cancel” button.
User Guide
Alternative Payment CM5P
10
EN
Description
After the user has selected the “SMS” button, the terminal will display a
phone number input field.
User action
The user must enter phone number to which an SMS with link to the Klarna
web page will be sent and the button “Submit” must be selected to
proceed.
The customer must click on the link, which will lead the customer to the
Klarna webpage, where the customer must fill in all required data.
The user can return to the QR display, by selecting the “QR Code” button.
The user can cancel the transaction, by selecting the “Cancel” button.
Description
After the customer has scanned the QR code, or clicked on the link, which
was sent to the customers mobile device, the device will indicate that the
customer is filling out the requested data at the Klarna web site.
User action
The customer must fill out the requested data at the Klarna web site.
