Verilux VF03 Manuale utente

VF03

Dear Customer,

Thank you for purchasing the Verilux Heritage™ Deluxe

Natural Spectrum®Floor Lamp. You have received a

quality product, backed by a one-year limited warranty.

As a Verilux customer, your satisfaction means

everything to us. We look forward to serving you now

and in the future.

Many other healthy lighting products are available

through our

catalog and online. Visit us on the web at

www.verilux.com

to request a free catalog and learn

more about all our quality Verilux products, or call our

toll-free number 1-800-454-4408.

Have a Bright Day!

Nicholas Harmon

President, Verilux, Inc.

SAVE THESE INSTRUCTIONS

Thank you for purchasing the Heritage™ Deluxe Natural Spectrum®Floor

Lamp. Please read the following safety information before using. To reduce

the risk of ﬁre, electrical shock or injury to persons:

• Do NOT dismantle.

• Do NOT alter power cord.

• Turn off/unplug and allow to cool before replacing bulb or cleaning.

• For indoor use only.

Important Safety Instructions

General Precautions

• The lamp is an electrical device. DO NOT USE NEAR WATER.

• Before plugging in the lamp, check to make sure the voltage of the

wall socket does not exceed 120 volts.

• Not for use with light dimmers, timers, motion detectors or extension

cords.

• This product may cause interference with radios, cordless

telephones or devices that use a wireless remote control such as

televisions. If interference occurs, move the product away from the

device, plug the product or device into a different outlet or move the

lamp out of the line of sight of the remote control receiver.

• Unplug from electrical outlet for extended periods of non-use or

during lightning storms to ensure protection of the electronics.

• WARNING: Do NOT use lubricating agent in assembly; please see

troubleshooting section if you are having difﬁculty assembling your

lamp.

• WARNING: Do not use the lamp outside or in wet locations such as

bathrooms. It is intended for indoor, dry use only.

• WARNING: This product contains Mercury in the bulb. Dispose of

bulb per local regulations.

Getting Started

Main Parts & Controls

A. Optix®Glare Control Filter

B. Switch

C. Lamp Head Swivel Knob

D. Lamp Arm

E. Height Adjusting Collar

F. Upper Shaft

G. Lower Shaft

H. Lamp Base

I. Power Cord

J. Power Supply (Ballast)

K. Bulb

Close-up of Lamp Head

CAUTION:

DO NOT LIFT THE LAMP BY THE LAMP ARM. THE LAMP

SHOULD BE LIFTED BY THE VERTICAL SHAFT.

Please Read Operating Instructions Carefully Before Using the

Heritage™ Deluxe Natural Spectrum®Floor Lamp:

Assembly Instructions

Fig. 1

Assembly Detail

1. Set lamp base on the ﬂoor and insert the

lower lamp shaft (G) onto the base and

screw clockwise to tighten (Fig.1).

2. Pull the slack of the electrical cord

through the lamp base (I).

3. Loosen the height adjusting collar (E) to

free lamp arm (D).

4. With one hand holding the lamp arm (D),

screw the upper shaft (F) onto the lower

shaft (G) (see assembly detail below).

5. Tighten height adjusting collar to secure

lamp arm.

6. To lift lamp head, loosen swivel knob (C),

adjust head to desired angle. Tighten

swivel knob.

Assembly Instructions — continued

8. Attach the ballast to the power

cord. Use care to align the 4-pin

plug properly. DO NOT FORCE.

The 4-pin plug was designed to ﬁt

in only one orientation (Fig. 3). Fig. 3

9. Plug ballast into a standard 120V 50/60Hz

outlet. Turn lamp on. The green LED indicator

on center of the ballast should be illuminated

(Fig. 4). If the LED indicator does not illuminate,

please refer to the troubleshooting section of

this manual (see page 9).

10. If bulb does not illuminate instantly, please

refer to the troubleshooting section of this

manual.

11. Adjust lamp brightness to the desired level.

WARNING: Do not block vents on ballast. Vents

are necessary for proper function of the ballast;

blocking them may cause overheating of the ballast.

Fig. 4

Vents

Note: Do not

touch material

7. Attaching the Optix®glare control

ﬁlter:

• Remove glare control ﬁlter from

protective plastic bag. Take

care to hold ﬁlter by the edges

only.

• Insert tabs on bottom of ﬁlter

into opening. (Fig. 2)

• Press into place using

thumb tab.

Do not touch or press

on the ﬁlter material itself. Fig. 2

Adjusting the Heritage™ Floor Lamp

3. To adjust lamp head angle up

or down – loosen swivel knob

counterclockwise, place head at

desired angle, tighten swivel knob

to secure (Fig. 7).

4. To tilt lamp head toward you or

away from you – simply move

head to desired position (Fig. 8).

Fig.5

Fig. 7

Fig. 8

Swivel

Knob

The Heritage Floor Lamp

adjusts several ways:

1. To adjust lamp height – hold upper

shaft (F) with one hand, loosen height

adjusting collar. Raise or lower lamp

arm (D) to desired height. Tighten

collar (Fig. 5).

Note: Do not stand on cord or otherwise

restrict its movement while raising or

lowering the height of the lamp.

Height

adjusting

collar

2. To rotate the lamp head right or

left, loosen height adjusting collar,

swing lamp arm to desired position.

Tighten collar. Lamp arm rotates a

full 360º (Fig. 6). Fig. 6

Bulb Replacement Instructions

Removal

1. Unplug lamp from power source.

2. To access the bulb, remove Optix®

glare control ﬁlter by depressing the

thumb tab and lifting it out.

3. Firmly hold bulb base (B) and pull

bulb (C) from the socket (A) in an

outward motion (Fig. 9).

Installation

1. Unplug lamp from power source.

2. Firmly hold base (B) and push bulb

3. Be sure bulb is ﬁrmly seated in the

socket (see below) and snapped into

the metal bulb clip (D) (Fig. 10).

4. Replace Optix glare control ﬁlter.

gap

Notice

large gap

Correctly seated bulb Incorrectly seated bulb

YES NO

Fig. 9

Fig. 10

CAUTION: ALWAYS UNPLUG LAMP BEFORE PERFORMING BULB

REPLACEMENT OR INSTALLATION.

Troubleshooting

Before requesting service on your Verilux®lamp, please read

the following:

• Make sure all power connectors, cords and plugs are inserted fully

and securely.

• Be sure the bulb is securely seated into the socket (see page 8).

• Make sure there is power to the wall outlet or try another outlet.

WARNING: Do not block vents on ballast. Vents are necessary for proper

function of the ballast; blocking them may cause overheating of the

ballast and increase risk of ﬁre.

PROBLEM CHECK SOLUTION

Light Won’t

Come On

Blackening/Darkening

at Ends of Bulb

Light Flickers

Has the plug come

loose?

Is the bulb old?

Is the bulb connected

securely into socket?

Is the bulb new?

Is the bulb old?

Has the plug come

loose?

Is the bulb connected

securely to the socket?

Is the lamp connected

to a dimmer switch?

Insert plug securely into wall outlet.

Check bulb for blackening/darkening at bottom of spiral where it joins the

base (an indicator of bulb life) and replace bulb.

Be sure the bulb is securely seated into socket, repeat the bulb

installation process.

Sometimes when a new bulb is turned on for the first time the tube will

darken, but this will fade after a few minutes.

With older bulbs, darkening of the tube indicates end of bulb life (this

doesn’t affect operation except to reduce the amount of light available

since the phosphor in that area has become inactive). Bulb replacement

is recommended.

Insert plug securely into wall outlet.

Connect lamp plug only to wall outlet without dimmer switch.

Be sure the bulb is securely seated into the socket, repeat the bulb

installation process. CAUTION: DISCONNECT LAMP FROM OUTLET

PRIOR TO REPEATING THE BULB INSTALLATION PROCESS.

Care and Cleaning

Your lamp is made from high quality materials that will last for many

years with minimum care. You may want to periodically clean the lamp

using a mild non-abrasive cleaner and soft cloth. When cleaning, make

sure you have turned off and unplugged the unit and allowed sufﬁcient

time for the unit to cool. All liquid should be properly wiped away and

dried prior to restoring power.

CAUTION: DO NOT USE SOLVENTS OR CLEANERS CONTAINING

ABRASIVES, OR AMMONIA BASED CLEANERS.

WARNING: All moisture should be properly wiped away and dried prior

to restoring power.

Note: Do not use any cleaning agents, including window cleaner, on the

Optix®glare control ﬁlter. If needed, dust with a clean, dry cloth.
