Installation Guide

V940D Network Dome Cameras

XX292-00

Vicon Industries Inc. does not warrant that the functions contained in this

uipment will meet your requirements or that the operation will be entirely error

free or perform precisely as described in the documentation. This system has not

been designed to be used in life-critical situations and must not be used for this

purpose.

Document Number: 8009-8292-00-00

Product specifications subject to change without notice.

Vicon Industries Inc.

Tel: 631-952-2288) Fax: 631-951-2288

Toll Free: 800-645-9116

24-Hour Technical Support: 800-34-VICON

(800-348-4266) UK: 44/(0) 1489-566300

www.vicon-security.com

Notice

This manual may not be reproduced in any form or by any means to create any

derivative such as translation, transformation, or adaptation without the prior

written permission of Vicon Industries.

Vicon Industries reserves the right to change this manual and the specifications

without prior notice. The most recent product specifications and user

documentation for all Vicon Industries products are available on our web site

www.vicon-security.com.

Trademarks

Vicon and its logo are registered trademarks of Vicon Industries.

All other trademarks that may appear belong to their respective proprietors.

FCC Warning

The V940D Series Dome Cameras comply with the FCC rules.

Operation is subject to the following two conditions:

This device will not cause harmful interference.

This device must accept any interference received, including interference that

may cause undesired operations.

The V940D Series HD IR IP Dome Camera have been tested and found to

comply with the limits for a Class A digital device, pursuant to the FCC rules.

With these rules and regulations being obeyed to maintain the good working

condition of device, the operation is not supposed to be affected by the external

interruptions under certain circumstances. This device is electromagnetic, so all

the installation and application processing along the device has to follow strictly

to the manual or it may hamper telecommunications around. Meanwhile, there is

no guarantee that interference will not occur in a certain particular installation

situation.

Read this manual carefully before installation. This manual

should be saved for future use.

Important Safety Instructions and Warnings:

Electronic devices must be kept away from water, fire or high magnetic

radiation.

Clean with a dry cloth.

Provide adequate ventilation.

Unplug the power supply when the device is not to be used for an extended

period of time.

Only use components and parts recommended by manufacturer.

Position power source and related wires to assure to be kept away from ground

and entrance.

Refer to qualified personnel for all service matters.

Save product packaging to ensure availability of proper shipping containers

for future transportation.

Indicate that the uninsulated components within the product may carry a

voltage harmful to humans.

Indicate operations that should be conducted in strict compliance with

instructions and guidelines contained in this manual.

Warning: To avoid risk of fire and electric shock, keep the product away

from rain and moisture!

CONTENTS

Chapter I System Introduction ................................................................ 1

1.1 Product Description............................................................................... 1

1.2 Product Model....................................................................................... 2

1.3 Product Features.................................................................................... 2

1.4 System Requirement ............................................................................. 4

1.5 Specifications........................................................................................ 4

1.6 Notes..................................................................................................... 8

Chapter II Installation.............................................................................. 9

2.1 Installation Precautions......................................................................... 9

2.2 Dimensions........................................................................................... 9

2.3 Installation of Surface-Mounted Camera ............................................ 10

Chapter III IE Browser Settings............................................................ 16

3.1 Equipment Connection........................................................................ 16

3.2 Software Installation........................................................................... 16

Chapter IV Basic Function Operation................................................... 19

4.1 Live View............................................................................................ 19

4.2 System ................................................................................................ 23

4.2.1 System Information..............................................................................23

4.2.2 Time Settings.......................................................................................23

4.2.3 Advanced Settings................................................................................25

4.3 Network Settings................................................................................. 28

4.3.1 Network Settings..................................................................................29

4.3.2 FTP Settings.........................................................................................30

4.3.3 SMTP Settings.....................................................................................30

4.3.4 HTTPS Settings...................................................................................31

4.3.5 802.1X Settings....................................................................................31

4.3.6 QoS Settings ........................................................................................32

4.3.7 IGMP Settings......................................................................................33

4.3.8 SIP Settings..........................................................................................34

4.3.9 DDNS Settings.....................................................................................35

4.3.10 UPnP Settings....................................................................................36

4.3.11 NAS Settings......................................................................................37

4.3.12 RTSP..................................................................................................38

4.3.13 IP Filter..............................................................................................38

4.3.14 Monitor Connect................................................................................40

4.4 Camera Settings.................................................................................. 41

4.4.1 Basic Settings ......................................................................................41

4.4.2 Exposure Settings ................................................................................42

4.4.3 Effect Settings......................................................................................43

4.4.4 White Balance......................................................................................45

4.4.5 Focus Settings......................................................................................46

4.4.6 IR Set...................................................................................................48

4.4.7 Reset....................................................................................................48

4.5 Video and Audio Settings.................................................................... 49

4.5.1 Video Settings......................................................................................49

4.5.2 OSD.....................................................................................................52

4.5.3 Motion Detection.................................................................................55

4.5.4 Privacy Mask.......................................................................................56

4.5.5 ROI......................................................................................................57

4.5.6 Storage Path.........................................................................................58

4.5.7 Audio Settings......................................................................................58

4.6 Video Contents Analysis Functions..................................................... 59

4.6.1 Camera Tampering...............................................................................60

4.6.2 Line Cross Detection............................................................................61

4.6.3 Intrusion Detection ..............................................................................63

4.7 Alarm Settings..................................................................................... 64

4.8 Storage Management........................................................................... 67

4.8.1 Record Settings....................................................................................67

4.8.2 Replay..................................................................................................68

4.9 User Settings....................................................................................... 69

4.10 System Log....................................................................................... 72

Appendix I Questions & Solutions......................................................... 73

CHAPTER I SYSTEM INTRODUCTION

1.1 Product Description

The information in this manual provides installation and setup procedures for the

V940Dseriesnetwork cameras.

The V940D Series Dome Camera uses a progressive scan CMOS sensor with an

internal HD motorized zoom lens. The camera has an internal Smart IR

technology that provides 98 ft/30m IR distance. The IR LEDs output power can

be adjusted automatically according to the brightness of the scene so that the IR

LEDs do not work at full capacity. The power consumption of the complete unit

is greatly lowered and the service life is lengthened.

V940D Series offers 2MP cameras and 4MP cameras; the 4MP cameras can

support up to 2592×1520@20fps video output. All cameras use H.265/H.264/M-

JPEG encoding, providing output with excellent definition and color

reproduction, more detailed and accurate information and the accuracy of smart

analysis that can, effectively, be guaranteed.

V940D Series cameras boast smart functions, including camera tampering, to

detect if the camera/lens has been moved, blocked, low/high brightness or

defocused; intrusion detection, providing protection for key areas; and line cross

detection, providing border protection, which are important features for many

enterprises. These cameras can be widely used in sites that demand high

definition image quality in low lighting environments, such as ordinary buildings,

supermarkets, hotels, shops, parks, schools, factories, warehouses, underground

parking lots, etc.

The compact design makes it easy to install and provides 3-axis adjustment, for

easy adjustment of the monitoring angle.

1.2 Product Model

This manual is for the following models:

V942D-W312MIR HD Megapixel IR IP Dome Camera, WDR,

Intelligence, 2.0MP, 1/3"CMOS, day/night,

H.265/H.264/M-JPEG, with audio/alarm, 2.7~12mm

motorized zoom lens, 98ft/30m IR distance, IP67,

PoE/12VDC/24VAC

V944D-W312MIR HD Megapixel IR IP Dome Camera, WDR,

Intelligence, 4MP, 1/3"CMOS, day/night,

H.265/H.264/M-JPEG, with audio/alarm, 2.7~12mm

motorized zoom lens, 98ft/30m IR distance, IP67,

PoE/12VDC/24VAC

V942D-W310MIR-XW HD Megapixel IR IP Dome Camera, WDR,

Intelligence, 2.0MP, 1/2.8"CMOS, day/night,

H.265/H.264/M-JPEG, with audio/alarm, 3~10.5mm

motorized zoom lens, 98ft/30m IR distance, IP67,

PoE/12VDC/24VAC

V942D-W312MIR-XS HD Megapixel IR IP Dome Camera, WDR,

Intelligence, 2.0MP, 1/1.9"CMOS, day/night,

H.265/H.264/M-JPEG, with audio/alarm, 3.6~10mm

motorized zoom lens, 98ft/30m IR distance, IP67,

PoE/12VDC/24VAC

1.3 Product Features

Progressive scan CMOS sensor

IR-Cut Removable (ICR) Filter for Day/Night switching

98ft/30m IR distance

Uses Smart-IR technology; auto-adjusts IR LED power according to ambient

illumination

Supports multi-frame integration WDR

Smart functions, such as camera tampering, line cross, and intrusion detection

Built-in motorized zoom lens, supporting assistant focusing

H.265/ H.264/M-JPEG video encoding, three streams

Maximum resolution of V944D-W312MIR supports 2592×1520@20fps,

2560×1440@25fps

Bi-directional audio, G.711a/G.711u/AAC

Supports corridor mode

Local PC recording

Supports TF card (also referred to as SD card) storage/NAS storage

Supports alarm recording and event recording (including broken network)

Supports alarm snapshot and event snapshot

Supports multiple alarm trigger methods such as I/O input, motion detection,

smart detecting, SD card out, network link down, heart beat lost,etc.; supports

flexible alarm association settings like I/O output, emails, FTP picture

uploading, audio, TF card recording and alarm information push

Up to eight ROI (Region of Interest) areas

Supports motion detection, 4 areas configurable

Supports privacy mask, 4 privacy areas configurable

Supports live access and parameter setting via Web Server from multiple

users

Compatible with Vicon Valerus VMS software

Standard SDK provided for easy integration with other video surveillance

software

ONVIF Profile S and Profile G compliant

Surface mount; mounting accessories available

3-axis adjustment

IP66 rating

Rugged design (IK10)

Supports PoE/12VDC/24VAC power supply

Provides analog video output

1.4 System Requirement

Configuration of the computer to display image and control the camera:

CPU: Intel Pentium 4, 2.4 GHz or above

RAM:512MB or greater

Network Port: 100M Ethernet port

Operating System:Microsoft Windows 10, Windows 7, Windows XP

IE browser version: Microsoft Internet Explorer 8.0 or above

1.5 Specifications

Model

numbers

V942D-W312MIR

V944D-W312MIR V942D-

W310MIR-XW

V942D-

W312MIR-XS

I mage Sensor 1/3" CMOS 1/3" CMOS 1/2.8" CMOS 1/1.9" CMOS

Lens

Configuration

Motorized zoom

lens, F1.4,

f=2.7~12mm

Motorized zoom

lens, F1.4,

f=2.7~12mm

Motorized

zoom lens,

F1.4,

f=3.0~10.5mm

Motorized

zoom lens,

F1.5,

f=3.6~10mm

Lens Mount Φ14

IR Lamp

Wave Length

850nm

Night Vision

Distance

30m

Camera Angle

Adjustment

X (Panning): 0°~360°;

Y (Tilting): 0°~72°;

Z (Rotating): 0°~360°

Day/Night

Switching

ICR

Sensitivity Color mode:

0.01 lux@F1.4

(30IRE, AGC

ON);

B/W mode: 0 lux

(IR ON)

Color mode: 0.01

[email protected] (30IRE,

AGC ON);

B/W mode: 0 lux

(IR ON)

Color mode:

[email protected],

AGC ON

B/W mode:

[email protected],

AGC ON

0 lux (IR ON)

Color mode:

0.002@F1.5,

AGC ON

B/W mode:

0.0006@F1.5,

AGC ON

0 lux (IR ON)

Exposure Scene, Manual, Shutter

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Vicon Telecamera di sicurezza

Vicon

Vicon V15CCM-IR-2 Series Rouchneck Manuale utente

Vicon

Vicon Roughneck V920D Series Istruzioni per l'installazione e il funzionamento

Vicon

Vicon V661-N-1 Series Istruzioni operative

Vicon

Vicon Cruiser SN663V-A Manuale utente

Vicon

Vicon surveyor 2000 XX004 Istruzioni operative

Vicon

Vicon Roughneck AI V2008B-W310LPR Manuale utente

Vicon

Vicon G-Cam/EFD-3266 Manuale utente

Vicon

Vicon VC-700WDR Manuale utente

Vicon

Vicon ROUGHNECK V-CELL-HD-B Manuale utente

Vicon

Vicon V9360-6 Series Manuale utente

Vicon

Vicon V992-N Manuale utente

Vicon

Vicon Cruiser SN693V Manuale utente

Vicon

Vicon V940D Manuale utente

Vicon

Vicon VC-700W Manuale utente

Vicon

Vicon Surveyor MKII Series XX282-40-01 Guida rapida

Vicon

Vicon ROUGHNECK V910V4 Manuale utente

Vicon

Vicon Roughnec V922D Series Manuale utente

Vicon

Vicon V9360W Manuale utente

Vicon

Vicon V988D Manuale utente

Vicon

Vicon V662-D Istruzioni operative

Vicon

Vicon V661D-312N-1 Istruzioni operative

Vicon

Vicon V922B-W551-A1 Manuale utente

Vicon

Vicon V682-PTZ Manuale utente

Vicon

Vicon VC-620 Manuale utente

Manuali Telecamera di sicurezza popolari di altre marche

Okina USA

Okina USA SIR36-870VF650LP Manuale utente

Divio

Divio NDR155PA Manuale utente

Canon

Canon VB-C500D Manuale utente

Easy Access

Easy Access EasyGuard Manuale utente

Vivotek

Vivotek FD9389-EHV-v2 Manuale utente

TUYA

TUYA COSMO W2 Manuale utente

Eusso

Eusso UNC7500-IR Guida all'installazione

urmet domus

urmet domus 1096/204 Manuale utente

VC VC20 series Manuale utente

Axis

Axis Q1614 Manuale utente

ieGeek

ieGeek DD201 Manuale utente

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuale utente

Grundig

Grundig GCH-K0274P Manuale utente

Lorex

Lorex VANTAGE LBC7032 Manuale utente

4xem

4xem WPT Manuale utente

Samsung

Samsung SCV-3082 Manuale utente

Vitek

Vitek VTC-C544 Manuale utente

Lumens

Lumens VC-A50PNW Manuale utente
