Direct Draw Dispenser
Standard Features
• Draft Beer Column, Hoses, CO2 Tank, Regulator Gauge and
Connected Hoses
• Stainless Steel Top with Drip Tray
•
One Piece Molded Plastic Interior Liner
• Field Reversible Door with Self-Adjusting Magnetic Gaskets
• Front Grille Thermostat with Temperature Range of 33oF to 52oF
• Durable Black Textured Black Finish Exterior
• High Performance Refrigeration System Using Environmentally
Friendly R-134a Refrigerant
• Automatic Defrost
• Listed Under NSF-7 For the Storage and/or Display of Packaged
and Bottled Products
• Two-Year Warranty on Parts and Labor and a Five-Year Warranty on
the Compressor (U.S.A. only)
• Cord and Plug
Optional Features and Accessories
• 4 Easy Roll Casters
• Stainless Steel Models (Exterior)
VDD-24-B-B
VDD MODELS —
Textured, Black Steel Exterior
with Stainless Steel Counter Top
and One Piece Molded Plastic
Interior Liner.
VDD-24-B-B
Victory Refrigeration specification sheets
are available online at www.victory-refrig.com.
Approvals:
Project:
Location:
Item #:
Quantity:
Victory Refrigeration, Inc. I 110 Woodcrest Road I Cherry Hill, NJ 08003 USA I Phone: 856.428.4200 I Fax: 856.428.7299 I E-mail: [email protected]
Victory participates in the KCL CADalog, the most current source of CAD symbols for foodservice designers worldwide. Symbols include
standard equipment in plan, side, front and 3-D views, layered for FEDA/FCSI recommended guidelines.
Continuous product development may necessitate specification changes and design without notice.
VViiccttoorryyRReeffrriiggeerraattiioonn,,IInncc..DDiirreeccttDDrraawwDDiissppeennsseerr
crated dim. & wts.
Ht. Width Depth Lbs
VDD-24-B-B 36.75” 27.87” 38.75” 130
Dimensional tolerance ± 1/4” Metric dimensions (MM)
Copyright January 2007
Printed in U.S.A.
PART OF AGA FOODSERVICE GROUP
CHARACTERISTICS VDD-24-B-B
Width, Overall 24.23”
Depth, Overall 22”
Height, Overall 35.85”
Barrel Capacity (quarter barrel) 1
Straight Wall Capacity (half barrel) 1
Number of Doors 1
Refrigerant R-134a
Cabinet Voltage 115/60/1
Total Amperes 3
Compressor Size (BTU) 461
3/$19,(:
7<3
'22523(1,1*
'22523(1,1*
)5217(/(9$7,21
)5217(/(9$7,21
VDD-24-B-B
5,*+76,'(9,(:
