ViewSonic PJD8333s Manuale utente

The ViewSonic® PJD8333s is anadvanced networkable XGA DLP® ultrashort throw projectorthat offers advanced

connectivity for classrooms and meeting rooms. Withan ultrashort throwlens, the PJD8333s can project a70" image from

only 2.2 feet away. Equipped withCrestron® LANcontroller, the PJD8333s makes it easy for IT admin to remotely control

and manage multiple projectors from their workstations. Built with BrilliantColor™ technology, this projector produces vibrant

colors, while 3000 ANSI lumens and 15000:1 contrast ratio deliver bright, razor-sharp images. Certified with AMX® Device

Discovery™,the PJD8333s easily integrates into any size campus or enterprise.Inaddition,the PJD8333s is packed with

advanced features including wired and wireless LAN display, LAN control, USB display, a mobile app for smart phones and

tablets, capability for PC-less presentations, HDMI that is 3D Blu-ray ready, DynamicEco™, and integrated 16w speaker. The

www.viewsonic.com PJD8333s Scan for more information

Bright Images for Classrooms & Meeting

Rooms

Packed with 3,00Packed with 3,000 lumens and a high

contrast ratio of 15,000:1 (w/ DynamicEco™), the

PJD8333s is guaranteed to produce bright images in

classrooms and corporate environments.

Wireless & Wired LAN Display

Withits advanced networking capability, the projector can

project images viawireless, or wired, LAN. The LAN display

offers a quad split screen for simultaneously projecting

content from up to 4 PCs, with the ability to broadcast from

up to 8 projectors. The WPD-100 wireless adapter is

required for wireless display.

Project Large, Stunning Images in Small

Places

With an ultra short throwlens, the PJD8333s can project a

70" image from only 2.2 feet away—making it perfect for

small rooms with space limitations. In addition, blinding

lights infront of the presenter, distracting shadows on the

projected image, or glaring hotspots onthe whiteboard, are

all eliminated because the projector’s lightsource is closer

to the screen.

Mobile App for Smart Phones & Tablets

Withthe optional WPD-100 wireless USB adapter, you can

use ViewSonic's app on your Android™ or iOS devices as

a remote control for the projector. In addition, you can send

and project content such as MS Office documents, PDFs,

videos, or images directly from your mobile device. The

ViewSonic mobile app also offers live draw and live cam

functions to create an interactive experience for your

presentation.

PJD8333s is the perfect projectorfor small spaces and corporate environments.

www.viewsonic.com PJD8333s Scan for more information

PC-less Presentation

Jump start your presentation without waiting for the PC to

boot up. With a PC-less presentation feature, you can

display MS Office documents, PDFs, videos or images

directly from a USB flash drive.

Long Lamp Life up to 7000 Hours

New and advanced lamp technologyextends the projector’s

lamp life up to 7000 hours*,resulting inhuge savings on

lamp replacement costs.

Network Monitoring & Control

IT admin can monitor, schedule, and manage the projector

remotely, as well as receive projector status alerts, with the

integrated Crestron® e-Control™ system and RoomView

Express™ management software. Because the PJD8333s

is Crestron® and AMX® certified, IT admin can control and

monitor multiple projectors for any size campus or

enterprise.

Plug n’ PlayUSB Display

Project your presentations using a quick

and simple plug-andplay USB connection

without running a bulky VGA cable. Plug

n’ Play also features automatic resolution

detection for the best imaging

experience.

3D Blu-rayReadyHDMI

HDMI delivers the highestpicture and

sound quality without degradation.

Equipped withthe latest HDMI,

ViewSonic's PJD8333s projector can

display 3D images directly from 3D

Blu-ray® players—perfect for connecting

to any HDMI-enabled devices such as

PCs, laptops, tablets, and media players.

Type

Resolution

Technical Specifications

0.55" Digital Micromirror Device (DLP™)

1024x768

Display

www.viewsonic.com PJD8333s Scan for more information

Lens

Size

Throw Distance

Lamp

Brightness

Contrast Ratio

Keystone Correction

Aspect Ratio

Speakers

Analog

Frequency

Mac

RGB Input

RGB Output

Composite Video

S Video

Component Video

Digital

Audio

Control

USB

Power

Network

Voltage

Consumption

Temperature

Fixed zoom / Manual optical focus

60 - 250 inch

0.5m - 2.0m

240 watt /7000 hours Eco Mode

3000 ANSI Lumens

15,000:1

Vertical digital keystone correction (+/- 40º)

4:3 (native)

16-watt (x1)

NTSC M(3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60), SECAM (B,

D, G, K, K1, L), SD 480i and 576i, ED 480p and 576p, HD 720p, 1080i,

1080p

Fh: 31-100KHz; Fv: 24-120Hz

VGA to 1600x1200 UXGA

Up to UXGA (may require MAC adaptor)

15-pinmini D-sub (x2)

15-pinmini D-sub

RCA jack

4-pinmini-DIN

15-pinmini D-sub (x2, shared withRGB)

HDMI

Input:3.5mm mini jack (x2)

Output: 3.5mm mini jack

Microphone Input3.5mm mini jack (shared withAudio 2)

RS-232 (DB-9)

Type A (card reader and wireless dongle)

Type B (mouse control and service)

Mini Type B (USB display)

DC 12V Trigger(3.5mm plug 12V/1A)

RJ45

100~240VAC (Auto Switching), 50/60Hz (universal)

320W (max) / <0.5W (stand-by mode)

32ºF–104ºF (0ºC–40ºC)

Audio

Input Signal

Compatibility

Connector

Power

Operating Conditions

www.viewsonic.com PJD8333s Scan for more information

Humidity

Physical

Net

10%–90% (non-condensing)

335mm (width) x 128.3mm (height) x 265mm (depth)

3.6 kg

CB, UL/cUL, FCC-B, NOM, KC, REACH, ErP, SVHC UL-Argentina, PSB,

C-tick, SASO, CE, GOST-R, CCC, RoHS, WEEE, UkrSEPRO

PJD8333s projector, power cable, VGA cable, remote control with

batteries, carrying case, Quick Start Guide, ViewSonic Wizard DVD (with

User Guide)

Dimensions

Weight

Regulations

Package Contents

www.viewsonic.com PJD8333s Scan for more information
