Installation Guide
Range/Rangetop Rear Trim Accessories
& Range Curb Base Fronts
2
A
X
(Illustration II)
Grasp the trim on each end and carefully place in the channels (B) located at each rear corner of the
product. Align the screw holes (A) at each end of the trim device with the holes (A) in each rear channel
of the product. Secure with the 4 enclosed screws.
A
BB
B
A
B
RANGETOP
REAR VIEW
RANGE REAR
VIEW
(Illustration I)
HIGH SHELF
Rear Trim Accessories
ATTACHING REAR TRIM (Illustration I)
ATTACHING SHELF ON HIGH-SHELF (Illustration II)
All rear trim devices are installed in the same basic way.
Place the top rolled edge (X) over the front lip of the high-shelf back trim and secure with the 4
enclosed screws, two at each end.
WARNING
To reduce the risk of fire or injury to
persons, check to make sure all packaging
has been removed from the outside and
inside parts of the rear trim device before
installing. MAKE SURE ALL CORRUGATED
MATERIAL IS REMOVED FROM INSIDE
THE HIGH SHELF.
NOTE: High shelf is already installed on
Designer models.
3
Rear Trim Accessories
Backguards come equipped with Nylon Spacers (See Figure 1), which are needed to space the
range off a combustible wall a prescribed safe distance.
Note: If the back wall is Non-
Combustible, these spacers can be
removed. (See Figure 2)
These spacers can also be removed if used with any
of the models listed below:
• 30”, 36” and 48” VGCC/CVGCC
• VDSC530/CVDSC530
• VDSC536/CVDSC36
• VGRT530/CVGRT530
• VGRT536/CVGRT536
ATTACHING BACKGUARD (Illustration III)
Figure 1
(Illustration III)
Figure 2
On VGSC530/CVGSC530, VGSC536/CVGSC536
and VGSC548/CVGSC548 models there is a
regulator cover supplied with the backguard that
must be attached to the oven, with the supplied
screws, before the backguard is attached.
(See Figure 3)
Figure 3
*If you have one of these models, the
spacers are not required, even if with
a combustible wall.
4
IMPORTANT: USE OF ISLAND TRIM WITH AND WITHOUT 6” (15.2 CM) CLEARANCE.
Normal installation for island trim on either a range or rangetop is in an island/peninsula or where there is a
minimum clearance of 6”(15.2 cm) to any type of wall at the rear of the unit. Ranges and rangetops with an
island trim installation can be installed at zero clearance to the rear wall as long as the wall is non-combustible.
The responsibility for ensuring that the rear wall is non-combustible and heat resistant lies with the individual
owner and/or end user. Only in those cases where the island trim is installed with 6” (15.2 cm) of minimum
clearance to a rear wall, or when a truly non-combustible material is used, will the warranty apply. In no case will
Viking Range, LLC accept responsibility for any claims which may result from heat damage against a rear wall,
including cosmetic damage. It is the total responsibility of the owner/end user to ensure that the material
utilized in such applications is not only non-combustible, but is also truly heat-resistant.
Once you determine whether or not your product needs the provided spacers, the backguard is ready
to be attached.
Simply slide the backguard down onto the rear of the unit and attach using the (4) screws provided.
(See Figure 5)
A
Figure 5
Rear Trim Accessories
Custom VGIC ranges and 60” VGCC ranges require that two 1” standoff spacers be attached to the
back of the range when using a range with a backguard against a combustible surface. (See Figure 4)
Figure 4
5
Curb Bases
Alternate Curb Base View
for Custom Ranges
STANDARD CURB BASE FRONT
1. The standard curb base front (A) is completely assembled.
2. Remove the assembly from the carton and simply clip onto the front range legs.
3. The assembly is adjustable about 2” (5.1 cm) front to back so that alignment with the cabinet
toe front is possible. Loosen brackets on each side, but allow snug fit. Clip assembly onto
range legs; determine front to back setting; remove, tighten bolts, and reattach.
A
Important Note: The range must be installed as specified in the range installation guide for proper
airflow when using the standard curb base.
6
CUSTOM CURB BASE FRONT
1. Remove the standard curb base front assembly from the carton.
2. Remove the front (A) from the mounting assembly (B).
3. Attach locally supplied front (C) to the mounting assembly (B) and simply clip onto the front
range legs.
Important Note: The locally supplied front must not be any taller than 3-1/8” (7.9 cm) tall. Fronts taller
than 3-1/8” (7.9 cm) could obstruct the airflow.
4. The assembly is adjustable about 2” (5.1 cm) front to back so that alignment with the cabinet
toe front is possible. Loosen brackets on each side, but allow snug fit. Clip assembly onto
range legs; determine front to back setting; remove, tighten bolts, and reattach.
B
C
Curb Bases
Important Note: The range must be installed as specified in the range installation guide for proper
airflow when using the custom curb base.
7
A
COUNTERTOP REAR TRIM
1. Locate screw hole openings (A) on back of island trim near the top.
2. Align screw hole openings on countertop rear trim with the ones on the back of the island trim.
3. Attach rear trim to island trim with enclosed screws.
Curb Bases
Viking Range, LLC
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information
call 1-888-845-4641
F1448N EN (100113)
