Viking Designer DMOR200SS Guida

FINISH DETAILS

• Stainless Steel (SS)

R E L E A S E D 9 / 2 2 / 1 0

PLANNING AND DESIGN GUIDE

V I K I N G R A N G E . C O M • 1 - - V I K I N G 1

Both ovens include

• Capacity—1.1 cu. ft. (31.2 lit.)

o 29-15/16”W. x 16-1/4”H. x

15-9/16”D.

o 14-1/ ” (36.0 cm) diameter turntable

• Commercial-type styling and design

• Instant sensor settings for cooking,

reheating, and popcorn

• Instant sensor settings for cooking,

reheating foods and popping popcorn

• Fast action keys save time and make

microwaving easy

• Defrost programs quickly defrost meat

and poultry by weight

• Add-a-minute allows you to add a

minute to cooking time by simply

touching a button

• Warm/hold feature allows you to keep

food warm for up to 30 minutes

• Child lock safety feature locks the con-

trol panel to prevent unwanted opera-

tion

• Built-in exhaust system

• 300 CFM blower

• May be vented out the top, back or

converted to recirculate

• Large 14-1/ ” diameter turntable

• Exterior dimensions—

• 29-15⁄16”W. x 16-1⁄4”H. x 15-9⁄16”D

• Interior oven cavity—

• 1.5 cubic ft.

• For use over 30”W. Viking Designer

cooking products

• Suitable for use over 24”W. and 30”W.

Viking surface cooking products (non-

grill)

Standard Features & Accessories

Model Options

COOKING

Designer Conventional Microwave Hood

ORDERING INSTRUCTIONS

First specify model number, and then color code (DMOR200SS).

DMOR 00

Designer

Microwave Hood

COOKING

Designer Conventional Microwave Hood

PLANNING AND DESIGN GUIDE

V I K I N G R A N G E . C O M • 1 - - V I K I N G 1

R E L E A S E D 9 / 2 2 / 1 0



Please see

Installation Notes

and Accessories for

important information,

including filters.

All Models

Overall width 29-1 /16” (6 .9 cm)

Overall height (from bottom) 16-1/4” (41.3 cm)

Overall depth (from rear) 1 -9/16” (39. cm)

Approx. ship weight 8 lbs. (38.6 kg)

Dimensions & Specifications

PRODUCT DIMENSIONS

29-15/16”

(65.9cm)

16-1/4”

(41.3cm)

15-9/16”

(39.5cm)

DESIGNER

DMOR 00

Designer

Microwave Hood

R E L E A S E D 9 / 2 2 / 1 0

PLANNING AND DESIGN GUIDE

V I K I N G R A N G E . C O M • 1 - - V I K I N G 1

COOKING

Designer Conventional Microwave Hood

DMOR 00

Designer

Microwave Hood

30”

(76.2 cm)

2”

(5.1 cm) min.

36” min.

(91.4 cm) or more

from cooking

surface

15.5”

(39.4 cm)

12”

(30.5 cm)

12”

(30.5 cm)

72”

(182.9 cm) min.

72”

(182.9 cm) min.

Dimensions & Specifications

CLEARANCE DIMENSIONS

DMOR 00

Designer

Microwave Hood

COOKING

Designer Conventional Microwave Hood

PLANNING AND DESIGN GUIDE

V I K I N G R A N G E . C O M • 1 - - V I K I N G 1

R E L E A S E D 9 / 2 2 / 1 0

30”

(76.2 cm)

Ground

receptacle

Opening for

power cord

15-1/2”

(39.4 cm)

12”

(30.5 cm)

12”

(30.5 cm)

All models

Cutout width 30” (76.2 cm) min.

Cutout height 1 -1/2” (39.4 cm) min.

Cutout depth 12” (30. cm) min.

UTILITY

REQUIREMENTS

GAS

•Not applicable

ELECTRICAL

•3.5-foot power cord

included

• 120 VAC/60 Hz

•Maximum amp

usage—

13.2 (1.6 kW)

PLUMBING

Not applicable

Installation Requirements

ACCESS REQUIREMENTS

COOKING

Designer Conventional Microwave Hood

PLANNING AND DESIGN GUIDE

V I K I N G R A N G E . C O M • 1 - - V I K I N G 1

R E L E A S E D 9 / 2 2 / 1 0

Replacement Air Filter

• Recommended replacement every 6 – 12 months

Compliance Information

WARRANTY INFORMATION*

• One-year full warranty—complete product

• Five-year limited warranty—magnetron tube

• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items

*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

Installation Notes & Accessories

Model Description Approx. ship wt. lbs. (kg)

CFOR Air filter for 30”W. microwave hood lbs (.91)
