Viking Designer DDBB363 Manuale utente

Spe ifi ations (Designer Bottom-Mount)

24”

(61.0 cm)

35”

(88.9cm)

51–1/2”

(130.8cm)

23–1/16”

(58.5cm)

3–1/2”

(8.9cm)

9–5/32”

(23.3cm)

82–7/8”

(210.5 cm)

min.

84–1/16”

(213.5 cm)

max.

20–3/4”

(52.7 cm)

23–3/8”

(59.4 cm)

1–1/2”

(3.8cm)

26”

(66.0 cm)

36”

(91.5 cm)

Dimensions (Designer Bottom-Mount)

Designer 36” 36” Desig er Bottom-Mou t

Descriptio DDBB363

Overall width 36” (91.5 m)

Overall height from bottom 82-3/4” (210.2 m) min. to 84-1/16” (213.5 m) max.

Overall depth from rear To front edge of side trim: 23-3/8” (59.4 m)

To front of top grille: 24” (61.0 m)

To front of handle: 26” (66.0 m)

Cutout width 36” (91.5 m)

Cutout height 82-7/8” (210.5 m) min. to 84-1/16” (213.5 m) max.

Cutout depth 24” (61.0 m) min.

Ele tri al requirements 115 volt, 60 Hz, 15 amp dedi ated ir uit; 3-wire ord with

grounded 3-prong plug atta hed to produ t

Maximum amp usage 9.9 amps

Inlet water 1/4” opper tubing inlet waterline; minimum 20 psi;

Requirements maximum 120 psi

Overall interior dimensions

Refrigerator 15.2 u. ft. (431 Liters)

Freezer 5.1 u. ft. (145 Liters)

Total apa ity 20.3 u. ft. (576 Liters)

Approximate shipping weight 565 lbs. (254.3 kg)

One 2”x 4” Mounting Board

1–1/2” (3.8 cm) x3–1/2” (8.9 cm)

NOTE: If unit is installed deeper than 24” (61.0 cm), thenshim

behind the mounting board by the difference.

Bottom of anti-tip board is 3–7/8” (9.8 cm) belowopening height.

NOTE: Top of unit must be placed firmly under anti-tip board.

Anti-Tip Location

79–3/8”

(201.6 cm) min.

to bottomof

anti-tipboard

80–1/2”

(204.6 cm) max.

to bottomof

anti-tipboard

29”

(73.7 cm)

3–1/2”

(8.9 cm)

1–1/2”

(3.8 cm)

Anti-Tip Dimensions (Designer Bottom-Mount)

9”

(22.9cm)

73–3/8”

(186.4 cm)

82–7/8”

(210.5 cm) min.

anti-tip board&

opening height

84–1/16”

(213.5cm) min.

anti-tip board&

opening height

36”

(91.5 cm)

24”

(61.0 cm)

Electric Outlet Location

Water Line Entry Area

36”

(91.5 cm)

6–3/4”

(17.1 cm)

7–5/8”

(19.4 cm)

3”

(7.6 cm)

5/8”

(1.5 cm)

5/8”

(1.5 cm)

10–1/2”

(26.7 cm)

5/8”

(1.5 cm)

10–3/4”

(27.3 cm)

1”

(2.5cm)

3–5/8”

(9.2 cm)

Optional floor

water line entry

SeeAnti-Tip boardinstallation

6”

(15.2cm)

Cutout Dimensions (Designer Bottom-Mount)

36” Designer 36” Designer

Top View

Door

24”

(61.0 cm)

Standard

Cabinet

Depth

25”

(63.5 cm)

Countertop

Depth

Wall

3/4”

(1.9 cm)

Full End

Panel

Door

Wall

1”

(2.5 cm)

If standard

25” (63.5 cm)

standard

cabinet depth

is used

3/4”

(1.9 cm)

Full End

Panel

25”

(63.5 cm)

Flush

1”

(2.5 cm)

If standard

25” (63.5 cm)

standard

cabinet depth

is used

Flush

Cabinet Information (Designer)

Top View

Overlapping cabinet doors

Top View

Flush mount cabinet doors

Door

24”

(61.0cm)

Standard

Cabinet

Depth

24-3/4”

(62.9 cm)

Wall

3/4”

(1.9 cm)

Full End

Panel

3/4”

(1.9 cm)

If standard

25” (63.5 cm)

standard

cabinet depth

is used

Flush

Cabinet

Door

Wall

3/4”

(1.9 cm)

Full End

Panel

1”

(2.5 cm)

If standard

25” (63.5 cm)

standard

cabinet depth

is used

Flush

25”

(63.5 cm)

Cabinet

Depth

Cabinet

Door

Cabinet Information (Designer)

Designer models fit flush in standard 24” (61.0 m) deep abinet openings with no protrusion into the

room ex ept 2”(5.1 m) urved handle depth.

Designer models fit flush in standard 24” (61.0 m) deep abinet openings with no protrusion into the

room ex ept 2”(5.1 m) urved handle depth.
