VistaLab Ovation 9060-1011 Guida

Multicha el Nozzle

Reco ditio i g Kit

Note: Wear gloves

1. Push the ejector slide in until it clicks

to fully expose the pipette’s nozzles.

2. Remove an existing seal y slipping

the end of a very small screwdriver or

tweezers under the edge of seal,

taking care not to score or scratch

nozzle surface. Stretch it up and over

the end of the nozzle.

3. Place a new seal on the countertop,

with the ri line closest to counter

surface.

4. Pick up the pipette and align the

nozzle with the new seal. Press down

to ease the seal over the end of the

nozzle and into place.

Proced re:

Nozzle Seal Replaceme t I structio s

L060-0100-001 Rev. B

2 Geneva Road

Brewster, NY 10509 USA

1-888-652-6520 • www.vistalab.co

The Nozzle Reconditioning Kit contains

complete nozzles and components that

can e replaced as needed.

Applicable Catalog Nu bers:

9060-1011

9060-2011

9060-3011

Package includes:

• 2 complete nozzle assem lies

• 24 replacement filters

• 24 replacement seals

• Filter insertion tool

• Tu ing

• Instructions

Note: Same nozzle filter is used for all models

When to replace Nozzles:

If a nozzle is leaking or does not aspirate, a complete nozzle can e replaced.

When to replace Nozzle Filters:

Nozzle filters are made of a cellulose material which prevents liquid from

entering the interior of the pipette. If the filter ecomes wet, the channel will

not aspirate or dispense until the filter is replaced.

When to replace Nozzle Seals:

Nozzle seals may need to e replaced when a channel leaks during pipetting,

or the seal is visi ly worn or torn.

1. Push the ejector slide in until it clicks to

fully expose the pipette’s nozzles.

(For 0.5-20µL models, see note on reverse)

2. Remove the affected nozzle(s) y placing

the ru er tu ing provided onto nozzle,

and unscrew it in a counterclockwise

direction.

3. Place ru er tu ing ack onto a new or

reconditioned nozzle, and screw the

nozzle onto the pipette in a clockwise

direction. Firmly tighten and remove

tu ing from nozzle.

Nozzle Replaceme t I structio s

Note: Wear gloves

1. Push the ejector slide in until it clicks

to fully expose the pipette’s nozzles.

(For 0.5-20µL models, see note on reverse)

2. Remove the affected nozzle(s) y

placing the ru er tu ing provided

onto nozzle, and unscrew it in a

counterclockwise direction.

3. Remove the filter inside the nozzle(s)

y inserting a straightened paperclip

into the small hole in the tip end of

the nozzle, and push the filter out

through the wide (threaded) opening.

4. Pick up a new nozzle filter with

tweezers and place it into the wide

(threaded) end of the nozzle.

NOTE: Make sure the narrow end is

inserted first

5. Use the filter insertion tool to push

the filter into position. Press down

until the end of the tool makes

contact with the inside ottom of the

nozzle.

Proced re:

Nozzle Filter Replaceme t I structio s

6. Tap the nozzle on the counter to

remove any loose cellulose material.

7. Place ru er tu ing ack onto the

nozzle, and screw the nozzle onto the

pipette in a clockwise direction. Firmly

tighten and remove tu ing from nozzle.

Special Note for 0.5–20µL Models:

To remove a nozzle(s) on 0.5–20µL

models, the rear panel of the ejector

sleeve needs to e removed.

Remove two screws on the panel, and

slide it away as shown. Remove springs

from posts, and remove affected nozzle(s)

with tu ing provided.

After filter(s) has een replaced, reinstall

springs, rear panel and screws.

2–125µL

0.5–20µL 5–250µL 25–850µL

Nozzle Reco ditio i g Kit 9060-1011 9060-2011 9060-3011

Contains 2 nozzles, 24 seals, 24 filters & tool

MU L T I C H A N N E L MO D E L

Applicable Nozzle Reconditioning Kits

9060-1011

Catalog Number
