VT-PTZ10 Ultra-Compact PTZ Camera with 10x Optical Zoom

•Built-In 3.8-38mm Lens with 10x Optical / 10x Digital Zoom.

•High Performance 1/4” CCD with 500 TV Lines.

•True Day/Night function with ICR.

•128 Presets programmed with view direction, zoom, and BLC.

•4 Patterns record and play back user preference of surveillance path

up to 120º sec.

•8 Scans: 8 speed steps from slow to medium panning with smooth

Diagonal Scan.

•4 Tours: Each tour consists up to 32 Presets, Patterns, and/or Scans.

•4 Alarm inputs with 1~4 priority / 1 Auxiliary output with

programmable NC & NO.

•8 Privacy Zones: Video off or up to 8 masked blocks

•64 steps of variable speed from 0.4º/sec to 90º/sec. Max manual

speed 190º/sec with Turbo key pressed, Preset speed is 380º/sec.

•Built-in RS-485 receiver driver.

•Built-in power-line surge protection and lightning protection.

•Optional Wall Mount, Indoor/Outdoor pendant housing, and Heater &

Blower Kit

FEATURES

Flush Mounted

Optional Wall Mount

VT-PTZ10 Inside

BLACKYELLOWMAGENTACYAN

(888) VITEK-70 | WWW.VITEKCCTV.COM

28492 Constellation Road Valencia, CA 91355

VT-PTZ10 Ultra-Compact PTZ Camera with 10x Optical Zoom

Detailed Specifications

Image Sensor

Picture elements

Horizontal Resolution

Lens

View angle

Minimum Illumination

S/N ratio

Certification

Input Voltage

Power Requirement

Power Consumption

Alarm Output

Alarm Input

Control

Access Time

ID (Camera Address)

Pan Angle

Speed

Repeatability

Flip

Autoscan

Preset Position

Tour

Pattern

On-Screen Display

Operating temperature

Operating humidity

Storage temperature

Dimension (W x H)

Weight

1/4" Interline Transfer CCD(Sony)

NTSC : 768x494 Approx. 380K pixels / PAL : 752x582 Approx. 440K pixels

500 TV Lines

10x optical zoom with auto focus / 10x digital zoom / F1.8 to F3.0, f=3.8mm to 38mm

Approx. 51.2° (WIDE end) to 5.58° (TELE end)

0.7 lux(F1.8,normal shutter speed) / 0.02 lux (F1.8, IR Cut Filter Removed) / 0.005 lux (F1.8, DSS Auto with IR Cut Filter Removed)

more than 50dB

CE EMC, FCC CLASS A

18 to 30 VAC; 24 VAC nominal, built-in power-line surge

24 VAC/VDC 700mA

Maximum 15W / 30W(Heater Use)

1 Normal relays 24 VDC/1A Max (selectable NC/NO)

4 Normal dry contact (selectable NC/NO)

RS-485 baud rate:2400~38400bps (default:9600bps)

0.75 second maximum preset recall time

Physical 99, Logical 3999

360° continuous rotation

0.4° to 90°/sec. (proportional to zoom) / 190°/sec. maximum (with Turbo key pressed) / Preset Speed : 380°/sec

0.2°

Rotate 180° at bottom of tilt

4 auto scan include vector scan/1 Auto Pan

128 positions with camera status (16-character title)

4 tours

4 patterns, 120 second

Displays camera ID and area name on screen

0°C to 50°C (32°F to 122°F) / -30°C to 50°C (-22°F to 122°F)

0 to 90%RH (non-condensing)

-20°C to 60°C (4°F to 140°F)

5.65" x 5.51"

Approx. 2.4lbs. (1.2 kg)
