Vivo MOUNT-VR01 Manuale utente
Clamp-on VR Headset Stand
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
Instruction Manual
https://vivo-us.com/products/mount-vr01
SKU: MOUNT-VR01
Chat live with an agent!
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
2
ASSEMBLY STEPS
PACKAGE CONTENTS
WARNING!
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a
qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may
cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. Do
not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly
or inappropriate use.
WARNING: CHOKING HAZARD
SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
A (x1)
Clamp
S-A (x5)
M6x8mm Screws
S-B (x5)
M6 Washer
T-A (x1)
4mm Allen
Wrench
B (x1)
Controller Mount
Set
C (x1)
Headset
Bracket
D (x1)
Pad
E (x2)
Rubber
Ring
STEP 1 STEP 2
Remove the protective film from Pad (D) and
place on inside of Clamp (A).
Place Rubber Rings (E) into Controller Mount
Set (B).
D
A
E
B
3
STEP 3
STEP 4
STEP 5
With flanges pointed down, attach Controller Mount Set (B) to underside of Clamp (A) using M6x8mm
Screws (S-A), M6 Washer (S-B), and 4mm Allen Wrench (T-A).
Secure Headset Bracket (C) to the back of Clamp (A) using M6x8mm Screws (S-A), M6 Washer (S-B),
and 4mm Allen Wrench (T-A).
Secure assembly to desktop by tightening hand bolt on Clamp (A). Use slots in Controller Mount
Set (B) to route cables.
VR mount is now ready for use.
Desk
Desk
S-A
S-A S-B
S-B
B
T-A
A
T-A
C
A
BA
LAST UPDATED: 01/24/2023
