Vivo MOUNT-SP01CB/CW Manuale utente
Clamp-on Speaker Stand - 2 Pack
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
Instruction Manual
https://vivo-us.com/products/mount-sp01cb
SKU: MOUNT-SP01CB/CW
Chat live with an agent!
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
2
ASSEMBLY STEPS
PACKAGE CONTENTS
WARNING!
If you do not understand these directions, or if you have any doubts about the safety of the
further assistance. Check carefully to make sure there are no missing or defective parts. Improper
installation may cause damage or serious injury. Do not use this product for any purpose that is not
explicitly specified in this manual. Do not exceed weight capacity. We cannot be liable for damage or
injury caused by improper mounting, incorrect assembly or inappropriate use.
S-C (x2)
Conical Washer
C(x4)
So Pad
A(x2)
Mount
S-A (x2)
M8x25mm Screw
S-B (x2)
M8 Spacer
B(x2)
Speaker Plate
T-A(x1)
5mm Allen Wrench
STEP 1
Loosen the clamp on Mounts (A) and assemble them to the desktop by re-tightening the clamps.
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
33lbs
(15kg)
WARNING: CHOKING HAZARD
SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
A
3
STEP 3
Remove the adhesive backing from So Pads
(C) and stick them to the top surface of Speaker
Plates (B).
STEP 2
Loosen the knobs on the front of Mounts (A) to adjust the height. Insert the Safety Pin (A1) into the
holes located on the sha, and re-tighten the knob to lock the postion.
STEP 4
Assemble Speaker Plates (B) to Mounts (A)
using M8x25mm Screws (S-A) with M8 Spacers
(S-B) and Conical Washers (S-C). Tighten using
5mm Allen Wrench (T-A).
STEP 5
Place speakers on top of the assembled stands. Make tilt and height adjustments as necessary. If
desired, rotate Speaker Plate (B) so the lip is in the front for the speaker to rest on.
T-A
S-A
S-B
S-C
A
C
B
B
B
A
A1
LAST UPDATED: 08/15/2023
REV1
Open Monday - Friday 7:00am - 7:00pm CST,
our dedicated support team can oer immediate assistance with rapid response times. If any
parts are received damaged or defective, please contact us. We are happy to replace parts to
ensure you have a fully functioning product.
FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com
- 23% within < 15m
- 38% within < 30m
- 61% within < 1hr
- 83% within < 2hr
- 92% within < 3hr
Love your new VIVO setup and want to share?
Tag us in your photo! @vivo_us
AVG. RESOLUTION TIME (within oice hrs): < 15 M
www.vivo-us.com
Chat live with an agent!
AVG. RESOLUTION TIME (within oice hrs): 5M 4S
309-278-5303
