Vivo STAND-MIC02 Manuale utente

Premium Microphone Boom Arm Desk Mount

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

Instruction Manual

https://vivo-us.com/products/stand-mic02

SKU: STAND-MIC02

[email protected]om www.vivo-us.com 309-278-5303

Chat live with an agent!

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

2

ASSEMBLY STEPS

STEP 1

PACKAGE CONTENTS TOOLS NEEDED

2.2lbs

(1kg)

DO NOT EXCEED WEIGHT CAPACITY.

Failure to do so may result in serious injury.

WARNING!

Phillips

Screwdriver

A (x1)

Arm

B(x1)

Clamp

If you do not understand these directions, or if you have any doubts about the safety of the

installation, please call a qualified technician. Check carefully to make sure there are no missing or

defective parts. Improper installation may cause damage or serious injury. Do not use this product

for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity.

We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or

inappropriate use.

NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED

S-A (x1)

Grommet Bolt

S-B (x1)

Grommet Wing Nut

C (x1)

Grommet Plate

TIPOVER WARNING

SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER:

• NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF MONITOR OR

STAND.

• USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL

USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIPOVER.

WARNING: CHOKING HAZARD

SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.

B

A

B

OPTION A: Clamp Installation

Install Clamp (B) to desktop. Insert post on Arm (A) into Clamp (B).

3

OPTION B: Grommet Installation

Disassemble the Clamp (B) using a Phillips Screwdriver. Slide Clamp Bracket (B2) out from Clamp

Base (B1). Then Remove the Clamp Plate (B3) from the Clamp Screw (B4).

STEP 1 (Continued)

Install Grommet Plate (C) into the Clamp Base (B1) as shown below. If your desktop does not already

have an existing grommet hole, use a 1/4” (6.5mm) drill bit to make one in the desired location. Then

install the Grommet Bolt (S-A) into the base assembly. Insert the Grommet Bolt (S-A) through the

hole on desktop, then install the Clamp Plate (B3) and then tighten the Grommet Wingnut (S-B).

Insert post on Arm (A) into Clamp Base (B1).

B

B2

B1

B3

S-A

C

B1

S-B

B3

A

STEP 2

To adjust the arm tension, tighten or loosen the adjustment screw located on the base of the Arm (A).

If your microphone uses 3/8” threading, remove the 5/8” to 3/8” threaded adatper. When using the

adapter, be sure to leave about 2mm gap between the lock knob and the base of the threading.

3/8”

5/8”

Tension

Adjustment

Screw

Lock

Knob

A

B1

B4

LAST UPDATED: 11/5/2021

REV1

Open Monday - Friday 7:00am - 7:00pm CST,

our dedicated support team can oer immediate assistance with rapid response times. If any

parts are received damaged or defective, please contact us. We are happy to replace parts to

ensure you have a fully functioning product.

FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com

[email protected] AVG. RESPONSE TIME (within oice hrs): 1HR 8M

- 23% within < 15m

- 38% within < 30m

- 61% within < 1hr

- 83% within < 2hr

- 92% within < 3hr

Love your new VIVO setup and want to share?

Tag us in your photo! @vivo_us

AVG. RESOLUTION TIME (within oice hrs): < 15 M

www.vivo-us.com

Chat live with an agent!

AVG. RESOLUTION TIME (within oice hrs): 5M 4S

309-278-5303
