from globally sourced components.
Collier Equipment, Inc. Ph: (256) 229-6595 / Fx: (256) 229-6779
100 Mill Creek Circle / PO Box 175 / Lexington, Alabama 35648
60 Hemmed & Stacked
Jeans Pockets per Minute
for Over 35 Years!
VMW Model 1700
for Short Sleeves
VMW Model 1500
for Back Pockets & Watch Pockets
AUTOMATED APPAREL EQUIPMENT
Model
#1500 Hems Back Pockets and Watch Pockets
#1700 Hems Pockets and Short Sleeves
Sewing
Head
Pfaff 5642 / Pegasus TM625 Needle Feed or Union Special 56500,
Pegasus W522 or Kansai Special WX-8000 Drop Feed Machines.
Model #1700: 5" x 5" through 18" x 24"
Cut & Stack Handles watch Pockets to large Coverall Pockets with 1 adjustment
Curved
Conveyor Holds 1,000 pockets and returns them to the operator
SPECIFICATIONS
Training Time One to Two weeks
Electronics
Installation
Efka DC1500 / AB221A & VMW Stacker Board
Usually within 1 day
Production
60 Pockets-per-Minute capacity
500-600 dozen pair of pockets per eight-hour-day,
depending on operator (usually 14,000 per shift)
300 dozen pair of short sleeves per eight-hour-day (7,000 units)
Material Poplin and Twill to 16-ounce Denim
Material
Sizes
Model #1500: 3½" x 3½" through 9" x 9"
Payback Usually within 1 year (one shift per day)
Serving the Sewn Products Industry for Over 40 Years
(NEW 2019) All-New / ALL-ELECTRONIC Versions are available
Collier Equipment, Inc. Ph: (256) 229-6595 / Fx: (256) 229-6779
100 Mill Creek Circle / PO Box 175 / Lexington, Alabama 35648 USA
OPERATION MANUAL
#800 POCKET HEMMER
#1500 POCKET HEMMER
#1700 SLEEVE & POCKET HEMMER
AUTOMATED APPAREL EQUIPMENT
VMW AUTOMATED APPAREL EQUIPMENT
In June of 2016, our Friend Mr. Jerry Kear decided to retire and sell his business to the Collier Family in
Lexington Alabama where his equipment developments would be manufactured and maintained with a good
family name. We strive to keep the integrity and maintain the long lasting reputation Jerry presented to the
industry for so many years. He will forever be missed and loved by many of us. RIP to our good friend.
Serving the Sewn Products Industry for Over 40 Years
Collier Equipment, Inc. Ph: (256) 229-6595 / Fx: (256) 229-6779
100 Mill Creek Circle / PO Box 175 / Lexington, Alabama 35648 USA
Section 1
Introduction
Section 2
Installation and Checklist
Section 3
Operation
Section 4
Adjustments 1
1.
Removing the Pocket Conveyor
2.
Conveyor Feed End Height Adjustment
Section 4
Adjustments 2
3.
Conveyor Center Height Adjustment
4.
Edge Guide Adjustment
Section 4
Adjustments 3
5.
Pre-folder Adjustment
6.
Stitch Position Alignment
Section 4
Adjustment 4
7.
Conveyor Speed Control Adjustment
8.
Thread Cut and Vacuum
Section 4
Adjustments 5
9.
Stacking system
Section 5
Troubleshooting
Recommended Customer Stock Level for Spare Parts
Complete Model #1500 Spare Parts List
AUTOMATED APPAREL EQUIPMENT
TABLE OF CONTENTS
List of parts shown in sections 2 - 4
Collier Equipment, Inc. Ph: (256) 229-6595 / Fx: (256) 229-6779
100 Mill Creek Circle / PO Box 175 / Lexington, Alabama 35648 USA
AUTOMATED APPAREL EQUIPMENT
Section 1 - Introduction
The VMW Pocket Hemmer has been factory adjusted to
begin operation immediately. This manual has been
provided to assist the Tehnicians who will care for the
machine. All necessary adjustments are included on the
following pages. Additional assistance is available during
the hours of 8 a.m. - 5:00 p.m Central Standard Time,
Monday through Friday at (256) 229-6595 or eMail us at
your convenience.
Contact us for all of your Sewing Equipment, parts and
service requirements.
In order to avoid down-time, please maintain your spare
parts inventory as indicated in this manual.
Collier Equipment, Inc. Ph: (256) 229-6595 / Fx: (256) 229-6779
100 Mill Creek Circle / PO Box 175 / Lexington, Alabama 35648 USA
Date:
Installed By:
Assemble and attach thread stand and power pole with mirror.
Check machine rotation.
Check oil level in sewing head.
Sew a few samples (preferably watch pockets).
Check seam margin (overall fold width).
Check stitch to fold (top of pocket) margin.
Check stitch length and stitch quality.
Check for venturi and clippers are trimming clean with no
thread tails.
Check for dead spots in table top conveyor (Places where
the conveyor belt does not make contact with the folder plate
or cutting plate).
Check stacker for proper cycling.
Material clamp tips making contact with pocket.
Material clamp releasing at the proper time.
Clamp returning slow enough to allow pocket to fall onto
the return conveyor.
Adjust return conveyor so that it indexes far enough to allow
pockets to move out of the way of the stacker.
Check for extra chain flight in drawer.
Check for service manuals for hemmer and sewing head.
Comments:
AUTOMATED APPAREL EQUIPMENT
VMW POCKET HEMMER INSTALLATION CHECKLIST
Collier Equipment, Inc. Ph: (256) 229-6595 / Fx: (256) 229-6779
100 Mill Creek Circle / PO Box 175 / Lexington, Alabama 35648 USA
Air Lock-Out
IMPORTANT!
AUTOMATED APPAREL EQUIPMENT
Install electrical conduit (A).
Pull the electric cord through the
conduit and attach to your plug.
The machine requires 220 Single
Phase electricity. Connect to your
plug and confirm the proper
rotation of the motor.
SECTION 2 - INSTALLATION
Install air supply (B). A minimum of 80 psi is required to begin operation of the
machine. During operation, the air supply cannot drop below 50 psi. An air lock-
out device is located near the regulator. This device allows a Technician to
depressurize the air system during service of the pneumatic components.
Attach the mirror to the conduit. The operator should be able to see the pockets
as they enter the cut and stack operation ( C ).
Confirm the proper oil level in the
sewing head at (D).
The machine is now ready for
operation.
Collier Equipment, Inc. Ph: (256) 229-6595 / Fx: (256) 229-6779
100 Mill Creek Circle / PO Box 175 / Lexington, Alabama 35648 USA
AUTOMATED APPAREL EQUIPMENT
The machine can be operated in either
manual or automatic mode. Push the
"RUN" switch to manually operate the
machine.
Power is transferred to the sewing
machine shaft through belt (F) and to a
variable speed gearbox through a belt
(G). The output shaft of the gearbox is
directly coupled to the conveyor belt
drive pulley (H).
The moving belt of the pocket
conveyor moves the pockets through
the sewing machine (I) and on to the
cut and stack operation (J).
Automatic operation is controlled by the
button "0" on the Efka Controller and
turns on the photo-cell (L).
You should press the "0" button and be
in service / manual mode before
performing any maintenance to the
sewing head.
Before turning on main switch, confirm
that any foot pedals are free and that
the start pedal isn’t pressed.
The main power switch ( E ) turns the
motor controls on/off. Check the head
for proper rotation of the motor. 'The
pocket conveyor will always move in the
correct direction and is not a good check
for the direction of the motor drive.
CAUTION!
SECTION 3 - OPERATION
Collier Equipment, Inc. Ph: (256) 229-6595 / Fx: (256) 229-6779
100 Mill Creek Circle / PO Box 175 / Lexington, Alabama 35648 USA
This unit has been adjusted at the factory. However, you may need to make
adjustments due to shipping and when you change fabrics.
1. Removing the Pocket Conveyor
1 - Remove bolt from the eccentric nut
To Reattach
Pocket:
should meet belt
at this point.
AUTOMATED APPAREL EQUIPMENT
(M) by loosening bolt at (S) (See section
4 - 3).
2 - Loosen conveyor feed end height
adjustment (Q) (See Section 4 - 2).
3 - Remove U-joint (N) at gearbox.
1 - Reattach, but do not
tighten U-joint at gearbox.
2 - Tighten conveyor feed
end height adjustment
until the end of the belt is
touching the folder plate
at (O).
3 - Tighten eccentric nut
until the end of the conveyor
belt is touching the end of the
stacking plate at (P).
The adjusting screw (Q) is used to control
the clearance between the pocket conveyor
belt and the folder plate. The adjustment is
made at the point where the pockets begin
under the conveyor. Loosen the conveyor
clamp nut ( R ) and back it out. Use a single
piece of fabric as a guide. Insert the fabric
between the conveyor belt and the folder
plate. Tighten the adjusting screw until a
slight binding of the fabric occurs at a point
directly below the center line of the conver
shaft. Tighten the wing nut.
2. Conveyor Feed End Height
Adjustment.
SECTION 4 - ADJUSTMENTS 1
Collier Equipment, Inc. Ph: (256) 229-6595 / Fx: (256) 229-6779
100 Mill Creek Circle / PO Box 175 / Lexington, Alabama 35648 USA
N
P
O
AUTOMATED APPAREL EQUIPMENT
3. Conveyor Center
Height Adjustment
The bolt (S) and eccentric nut (M)
controls the clearance between the
conveyor assembly (T) and folder
plate (U). Loosen bolt and rotate
the nut counterclockwise (See
Section 4-1 to increase pressure
between the conveyor belt and the
folder plate. Rotate the nut
clockwise to decrease pressure.
4. Edge Guide Adjustment
SECTION 4 - ADJUSTMENTS 2
The pocket guide (V) and
support (V2) control the amount
of fabric in the fold. The guide
has been preset at the factory.
You should mark the original
position of the guide before
making any changes. Loosen
adjustable handles (W) and
move the edge guide toward the
left (as shown) for less material
in the fold. Move it to the right
for more material. Reattach
bolts. Check sewn pockets for
proper amount of material in the
fold.
Collier Equipment, Inc. Ph: (256) 229-6595 / Fx: (256) 229-6779
100 Mill Creek Circle / PO Box 175 / Lexington, Alabama 35648 USA
