Volt VPL-3024-BBZ Manuale utente

VOLT®Low Voltage Landscape Lighting

VOLT®Elevator Path & Area Light

VPL-3024-BBZ

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

reserved. [email protected] • 813.978.3700

- 1 -

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

VOLT®Elevator Path & Area Light

VPL-3024-BBZ

Important: Please Read Before Installation

INSTALLATION INSTRUCTIONS

www.voltlighting.com

- 2 -

This xture is intended for installation in accordance with local codes

and the National Electric Code (NEC). Failure to adhere to these codes

and instructions may result in serious injury, property damage and void

the warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situation.

1. Make sure that the power is turned OFF before installing or servicing

this xture.

2. Warning: this xture is not intended to be installed within 10 feet [3

meters] of a pool, spa or fountain.

3. This xture is intended to be used only with a power supply

(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.

4. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in

order to connect to the main low voltage cable.

5. Wiring connections must be made with wire connectors that are suitable

for outdoor use.

6. Position the wire connector so that it is located within 6 inches (15.2

cm) from a building structure, a luminaire, or tting.

Important Safety Instructions

LIGHTED LAMP IS HOT!

WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.

1. Turn o/unplug and allow to cool before reducing lamp.

2. Lamp gets HOT quickly!

3. Do not touch the hot lens, guard or cowl.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time.

6. Use a soft cloth.

7. Oil from skin may damage lamp.

8. Do not operate the xture with a damaged or missing lens or shield.

[email protected] • 813.978.3700

Package Contents

A. (1) Fixture Body

B. (1) Extension Pole

C. (1) Stake

Parts Required (sold separately)

A. (1) LED Lamp

Product Dimensions

24.5”

2.5”

4”

2”

- 3 -

INSTALLATION INSTRUCTIONS

VOLT®Elevator Path & Area Light

VPL-3024-BBZ

Remove Faceplate

Install/Replace Lamp

Unscrew the faceplate, then remove

it from the xture body.

Insert the lamp with the correct

wattage and type marked on the

xture label.

CAUTION: Do not exceed maximum

wattage marked on luminaire label.

NOTE: DO NOT touch lamp with

bare hands. Use soft cloth to handle

lamp.

NOTE: The “Wafer” Bi-Pin LED lamp

also can be used in this xture.

Fixture Body

Faceplate

Socket

Lamp

www.voltlighting.com

- 4 -

“Wafer” Bi-pin LED Lamp

[email protected] • 813.978.3700

Install Faceplate

Screw the Faceplate back onto the

xture body. Hand tighten until snug.

Faceplate

Fixture

Body

- 5 -

INSTALLATION INSTRUCTIONS

VOLT®Elevator Path & Area Light

VPL-3024-BBZ

www.voltlighting.com

- 6 -

Install Fixture to Stake

Fixture

Pigtail

Wireway Slot

Stake

Install Stake

Board

Stake

Soil

Ground

Clear away an area on the ground

at the wireway slot on top of

the stake. Lay the luminaire

pigtail into the wireway slot and

thread the xture onto the stake.

Tighten until snug using the lock

nut to secure it to the base.

Determine the desired location for

mounting the xture. Hammer the

stake into the ground until the ange

of the stake is ush to grade. To avoid

damage to the stake, place a board on

top of the stake while hammering.

NOTE: If the ground is hard and the

stake is dicult to install, make a

crosscut in the ground using a at

shovel.

[email protected] • 813.978.3700

Wire Connections

Pigtail

Main Supply Cable

Wire Connectors

- 7 -

Strip both leads from the luminaire pigtail. Using two wire connectors

(sold seperately), connect the leads from the luminaire to the main

supply cable leads.

is-VPL-3024-BBZ-ver3.pdf

Specications and product details subject to change without notice.

reserved. [email protected] • 813.978.3700

www.voltlighting.com

- 8 -
