Volvo 2003 S60 Manuale utente

VOLVO S60, V60, XC60, V70, XC70 & S80

ROAD AND TRAFFIC INFORMATION SYSTEM (RTI)

Web Edition

OPERATING MANUAL

Road type Colour

Motorway Orange

Primary road Dark grey

Smaller primary road Grey

Ordinary road Light grey

Local road White

Text and symbols on screen

Event at next guidance point

Distance to next guidance point

Name of next road/street

Facility (Restaurant)

Planned route final destination

Symbol for destination/final destination

Calculated arrival time at final destination

Planned route waypoint

Calculated remaining distance to destination

Maximum permitted speed - at car's current position (17)

Compass

Traffic information

Section covered by traffic information

Current road/street name - at car's current position (17)

Next guidance point

Planned route

The car's current position

Stored location

Completed planned route

Planned route start

Map scale

ROAD AND TRAFFIC INFORMATION - RTI

Volvo's navigation system is a traffic information and road

navigation system developed by Volvo. The system guides

you to a destination and gives information along the route. It

informs of situations that can affect the drive, such as accidents, road

works and shows alternative routes.

It is possible to create an itinerary, search for facilities along the route,

store special places etc. The system displays the car's exact position

and in event of a wrong turning always corrects to guide you to the

destination.

You will see just how intuitive it is to use. Try it out. In order to get

along with the system we recommend that you familiarise yourself

with the information in this manual.

By facilitating accessibility and shortening driving distances, Volvo's

navigation system contributes to a better environment.

License agreement NAVTEQ DATABASE

For information for the end user - see page 74.

Table of contents

01 Quick Guide

Quick start................................................... 8

02 Get to know your navigation

system

Manual...................................................... 12

Before starting.......................................... 13

Overview................................................... 14

Controls.................................................... 17

Voice recognition...................................... 19

Keyboard................................................... 23

DVD disc, screen...................................... 25

Maps, road types and compass............... 28

Menus....................................................... 30

Menu tree in three levels........................... 32

03 Planning your trip

Specify a destination................................ 38

Itinerary..................................................... 45

Current position........................................ 48

Settings..................................................... 49

Simulation................................................. 57

Table of contents

04 Traffic information

General...................................................... 60

Reading information.................................. 62

Handling traffic problems.......................... 64

05 Symbols on the map

Facilities.................................................... 68

06 Questions and answers

Frequently asked questions...................... 72

EULA - License agreement....................... 74

Table of contents

07 Alphabetical Index

Alphabetical Index.................................... 78

Table of contents

Quick start................................................................................................. 8

QUICK GUIDE

01 Quick Guide

Quick start

Activating the system

The car's electrical system must first be acti-

vated:

1. Press the remote control key into the igni-

tion switch and activate key position I(see

the owner's manual for the car).

2. If the navigation system does not start

within a few seconds - press the centre

console's NAV button.

Disclaimer

When the navigation system is started the dis-

play screen shows a text which must be con-

firmed:

•Press the OK button.

For more information, see page 13.

Controls

Volvo's GPS navigator can be operated in sev-

eral ways:

•With the steering wheel's right-hand key-

pad

•With the controls in the centre console

•With a remote control

•With voice recognition.

For a functional description, see page 17.

Main commands

The steering wheel keypad is used in the fol-

lowing two examples to give guidance to an

Address or Facility.

•Scroll/select in the menus with the Thumb-

wheel (1).

•Activate selections with a brief press on

the Thumbwheel (abbreviated in the fol-

lowing example with "+ OK".

•Go back in menus and/or undo using

EXIT (2).

Centre console controls

If the centre console keypad is used instead of

the steering wheel keypad then the following

applies:

Keypad in the

steering wheel

Centre console

Turn the Thumb-

wheel

Turn TUNE

Press the Thumb-

wheel

Press OK

Press EXIT Press EXIT

Guidance to a street address

Display screen/

Action

If the display screen

does not show a

map image, proceed

as follows:

Press the centre

console button

NAV.

Map Press OK to bring up

a menu.

Navigation menu Mark Set destina-

tion + OK.

Set destination Mark Address +

OK.

Address: Mark City: + OK.
