Volvo S60 Series Manuale utente
ENGINE
Petrol engines
Five-cylinder petrol engine, with or without turbo. Double overhead
camshafts, 20 valves. Continuously variable valve timing (CVVT) on the
inlet side (engines without turbo), exhaust side (engines with turbo) or both
the inlet and exhaust sides (Volvo S60 AWD). Electronic engine
management. Three-way catalytic converter with Lambda sensor. Engines
with turbo also with charge-air cooler (Intercooler).
Diesel engines
All-aluminium direct-injection common rail turbodiesel with five cylinders.
Double overhead camshafts, 20 valves. Variable turbocharger. Charge-air
cooler (Intercooler). Two-way catalytic converter with EGR. Electronic
engine management.
Bi-Fuel engines
Five-cylinder Bi-Fuel engine which runs on gas (methane or LPG) with
petrol as the reserve fuel. Double overhead camshafts, 20 valves.
Continuously variable valve timing (CVVT) on the inlet side. Three-way
catalytic converter with Lambda sensor. Electronic engine management.
DRIVELINE
Front-wheel drive (Volvo S60 AWD with an electronically-controlled all-
wheel drive system). Transverse engine. Five-speed manual all-synchromesh
gearbox. As an alternative there is a five-speed, electronically controlled
automatic transmission with adaptive shifting pattern, winter mode and a
lock-up function that reduces fuel consumption when cruising. The 210-bhp
and 250-bhp turbo engines are also available with five-speed Geartronic
adaptive automatic transmission, which allows manual shifts.
ELECTRICAL SYSTEM
Multiplex digital electrical system with OBD (On Board Diagnosis). Battery
capacity 12 V, 520 A (Volvo S60 2.4D and D5 680 A). Alternator 120 A.
STEERING GEAR
Power assisted rack and pinion steering gear. Steplessly adjustable steering
wheel, vertically and horizontally. 2.8–3.0 turns between end stops
(depending on tyres). Turning circle 10.8–11.8 m (depending on tyres).
BRAKES
Power-assisted anti-locking disc brakes (ABS), ventilated at the front.
Electronic brake distribution between front and rear brakes (EBD). Diagonal
split brake system.
Emergency Brake Assistance (EBA) in combination with DSTC.
CHASSIS
Front suspension with spring struts. Anti-dive and anti-lift function. Multi-
link independent rear suspension with aluminium subframe. Anti-roll bars
front and rear.
Options: Volvo’s anti-spin system (STC). Volvo’s anti-skid system (DSTC).
Automatic levelling.
LOAD CAPACITY
With rear-seat backrest up: 424 litres
With rear-seat backrest 1/3 down: 578 litres
With rear-seat backrest completely down: 808 litres
Max load: 425 kg
Max roof load: 100 kg
Max trailer weight: 1600 kg
WEIGHT
Kerb weight: 1427 kg
Max total weight: 2050 kg
FUEL TANK
70 litres
23m3 methane/30 litres petrol (Bi-Fuel methane/petrol)
50 litres LPG/30 litres petrol (Bi-Fuel LPG/petrol)
VOLVO S60 2.4 (140 BHP)
Engine type: Five-cylinder petrol engine
Displacement: 2435 cc
Power output: 103 kW (140 bhp) at 4500 rpm
Torque: 220 Nm at 3300 rpm
Acceleration 0–100 km/h, man/auto: 10.2/11.1 sec
Top speed, man/auto: 210/205 km/h
Fuel consumption litres/100 km, mixed driving, man/auto*: 8.9(8.8)/9.6(9.5)
CO2 emission, g/km, man/auto*: 212(209)/229(226)
Environmental classification:Specific for each market
Transmission: Five-speed manual gearbox or five-speed adaptive automatic
* May vary depending on the car’s equipment level.
VOLVO S60 2.4 (170 BHP)
Engine type: Five-cylinder petrol engine
Displacement: 2435 cc
Power output: 125 kW (170 bhp) at 6000 rpm
Torque: 225 Nm at 4500 rpm
Acceleration 0–100 km/h, man/auto: 8.7/9.6 sec
Top speed man/auto: 210/210 km/h
Fuel consumption litres/100 km, mixed driving, man/auto*: 9.0(8.9)/9.6(9.5)
CO2 emission, g/km, man/auto*: 215(212)/229(226)
Environmental classification: Specific for each market
Transmission: Five-speed manual gearbox or five-speed adaptive automatic
* May vary depending on the car’s equipment level.
VOLVO S60 2.0T (180 BHP)
Engine type: Five-cylinder petrol light-pressure turbo engine
Displacement: 1984 cc
Power output: 132 kW (180 bhp) at 5300 rpm
Torque: 240 Nm at 2200–5300 rpm
Acceleration 0–100 km/h, man/auto: 8.8/9.5
Top speed, man/auto: 210/210 km/h
Fuel consumption litres/100 km, mixed driving, man/auto*: 9.2(9.1)/10.1
(9.9)
CO2 emission, g/km, man/auto*: 218(215)/240(236)
Environmental classification: Specific for each market
Transmission: Five-speed manual gearbox or five-speed adaptive automatic
* May vary depending on the car’s equipment level.
VOLVO S60 AWD (210 BHP)
Engine type: Five-cylinder petrol light-pressure turbo engine
Displacement: 2521 cc
Power output: 154 kW (210 bhp) at 5000 rpm
Torque: 320 Nm at 1500-4500 rpm
Acceleration 0-100 km/h, man/auto: 7.3/7.7 sec
Top speed, man/auto: 210/210 km/h
Fuel consumption litres/100 km, mixed driving, man/auto:* 9.8(n.a)/10.5
(10.3)
CO2 emission, g/km, man/auto*: 234(na.)/251(246)
Environmental classification: Specific for each market
Transmission: Five-speed manual gearbox, five-speed adaptive automatic or
five-speed Geartronic
http://vcc.volvocars.se/pp/s60/default.asp (3 of 6)24/09/2003 21:03:38
* May vary depending on the car’s equipment level.
VOLVO S60 T5 (250 bhp)
Engine type: Five-cylinder petrol high-pressure turbo engine
Displacement: 2319 cc
Power output: 184 kW (250 bhp) at 5200 rpm
Torque: 330 Nm at 2400–5200 rpm
Acceleration 0–100 km/h, man/auto: 6.8/7.1
Top speed, man/auto: 250/245 km/h
Fuel consumption litres/100 km, mixed driving, man/auto*: 9.3(9.2)/10.2
(10.0)
CO2 emission, g/km, man/auto*: 222(219)/240(236)
Environmental classification: Specific for each market
Transmission: Five-speed manual gearbox, five-speed adaptive automatic or
five-speed Geartronic
* May vary depending on the car’s equipment level.
VOLVO S60 2.4D (130 BHP)
Engine type: Five-cylinder direct-injection common rail turbo-diesel engine
Displacement: 2401 cc
Power output: 96 kW (130 bhp) at 4000 rpm
Torque: 280 Nm at 1750-3000 rpm
Acceleration 0-100 km/h, man/auto: 11.6/11.9 sec
Top speed,man/auto: 200/195 km/h
Fuel consumption litres/100 km, mixed driving, man/auto*: 6.5(6.3)/7.6(7.5)
CO2 emission, g/km, man/auto*: 171(167)/201(199)
Environmental classification: Specific for each market
Transmission: Five-speed manual gearbox or five-speed adaptive automatic
* May vary depending on the car’s equipment level.
VOLVO S60 D5 (163 BHP)
Engine type: Five-cylinder direct-injection common rail turbo-diesel engine
Displacement: 2401 cc
Power output: 120 kW (163 bhp) at 4000 rpm
Torque: 340 Nm at 1750-3000 rpm
Acceleration 0 100 km/h, man/auto: 9.5/9.9 sec
Top speed, man/auto: 210/210 km/h
Fuel consumption litres/100 km, mixed driving, man/auto*: 6.5(6.3)/7.6(7.5)
CO2 emission, g/km, man/auto*: 171(166)/201(199)
Environmental classification: Specific for each market
Transmission: Five-speed manual gearbox or five-speed adaptive automatic
* May vary depending on the car’s equipment level.
VOLVO S60 BI-FUEL METHANE/PETROL (140 BHP)
Engine type: Five-cylinder Bi-Fuel engine
Displacement: 2435 cc
Power output: 103 kW (140 bhp) at 5800 rpm
Torque: 192 Nm at 4500 rpm
Acceleration 0-100 km/h, man/auto: 10.7/11.6 sec
Top speed, man/auto: 210/205 km/h
Fuel consumption m3/100 km, mixed driving, man/auto*: 8.2(8.1)/9.1(9.0)
CO2 emission, g/km, man/auto*: 161(159)/178(176)
Environmental classification: Specific for each market
Transmission: Five-speed manual gearbox or five-speed adaptive automatic
* May vary depending on the car’s equipment level.
NB! All Bi-Fuel data refers to gas power. For specifications on petrol power,
see the Volvo S60 2.4, 140 bhp.
VOLVO S60 BI-FUEL LPG/PETROL (140 BHP)
Engine type: Five-cylinder Bi-Fuel engine
Displacement: 2435 cc
Power output: 103 kW (140 bhp) at 5100 rpm
Torque: 214 Nm at 4500 rpm
Acceleration 0-100 km/h, man/auto: 10.3/11.2 sec
Top speed, man/auto: 210/205 km/h
Fuel consumption (LPG) litres/100 km, mixed driving, man/auto*: 11.4
(11.2)/12.9(12.7)
CO2 emission, g/km, man/auto*: 185(182)/209(206
Environmental classification: Specific for each market
Transmission: Five-speed manual gearbox or five-speed adaptive automatic
* May vary depending on the car’s equipment level.
NB! All Bi-Fuel data refers to gas power. For specifications on petrol power,
see the Volvo S60 2.4, 140 bhp.
Warranty: 12-month international warranty without mileage limitation.
NB! Some of this information may be incorrect due to product
changes which may have occurred after publication. Some of the
equipment described or shown may now be available only at
extra cost. Before ordering, please ask your Volvo dealer for the
latest information. The manufacturer reserves the right to make
changes at any time, without notice, to prices, colour, materials,
specifications and models.
