WEB EDITION
SENSUS NAVIGATION
Text and symbols on the map
Car's current position + Pressure point for opening itinerary
Map scale
List of the itinerary's guidance points
Distance to destination/Arrival time at destination + Pressure point for
header change
Pressure point for list with itinerary's POI and Traffic information
Destination/final destination
Intermediate destination
Point for guidance
Car (blue triangle) on planned route
Traffic problem with information
Minimises (expanded view) or maximises (full screen) map image
Calculates detour
Repeats current voice guidance
Voice guidance temporarily On/Off
Pauses/resumes guidance
Enter destination/intermediate destination
POI (Restaurant)
Pressure point which resets the map to follow the car (blue triangle)
Pressure point for toggling between 2D and 3D
Compass + Pressure point for North up/Direction of travel up
SENSUS NAVIGATION
Sensus Navigation is a satellite based traffic information and route guid-
ance system.
Development work is constantly in progress to improve our product.
Modifications may mean that information, descriptions and illustrations in
this supplement differ from the equipment in the car. We reserve the
right to make modifications without prior notice.
2
INTRODUCTION
Quick guide to map navigation 6
Simple guidance to a destination 6
Displays and operating controls for
map navigation 7
Common operations during map nav-
igation 9
VOICE RECOGNITION
Voice recognition 14
Using voice recognition 14
Voice recognition and map navigation 15
Settings for voice recognition 16
SPECIFY A DESTINATION
General information about entering a
destination 20
Enter destination directly on the map 20
Specify destination with free text
searching 21
Specifying a destination with Latest/
Favourites/Library 23
Specifying a destination with POI 25
Specifying a destination with an address 26
Save the destination with "Send to Car" 26
TABLE OF CONTENTS
3
ITINERARY AND ROUTE
Itinerary and Alternative route 30
Guidance points in the Itinerary 31
POIs along route 32
Traffic disruptions along the route 33
Information cards on the map 33
Select detour 34
TRAFFIC INFORMATION
Traffic information 38
Real Time Traffic Information (RTTI) 38
SETTINGS
Map navigation in the driver display 42
Sensus Navigation settings 42
Map settings 43
Route settings 46
Traffic settings 47
Guidance settings 48
System settings 49
INTRODUCTION
INTRODUCTION
6
Quick guide to map navigation
The car's electrical system is activated automati-
cally when the driver's door is opened.
Navigation On/Off
On
"Home" button
Menu row "Navigation"
If the navigation system does not show a map on
the centre display - tap on the uppermost menu
row Navigation (2).
If the centre display does not show the
Navigation menu row - tap on the "Home" but-
ton (1) and then on the Navigation menu row
(2).
Then a map of the current area is shown with the
car symbolised by a blue triangle.
WARNING
Observe the following.
•Direct all your attention to the road and
make sure that all your concentration is
on driving.
•Follow applicable traffic legislation and
drive with good judgment.
•Due to weather conditions or time of year
affecting the road conditions, some rec-
ommendations may be less reliable.
Off
The navigation system cannot be switched off but
always works in the background - it is only
switched off when the driver locks and leaves the
car.
NOTE
The navigation system is also available when
the engine is switched off. When the battery
level gets too low the system switches off.
Related information
•Displays and operating controls for map navi-
gation (p. 7)
•Simple guidance to a destination (p. 6)
Simple guidance to a destination
Setting guidance to the desired destination with-
out having to first read the whole owner's man-
ual.
Selecting a destination on the map
Step Screen/
menu
Action
1 If the screen
does not
show a map
image, pro-
ceed as fol-
lows:
Press the rectangular
button under the screen
to come to the home
view.
2 The home
view is
shown.
Press Navigation on
the screen's upper
menu row.
3 A map is
shown.
If that button is visible
on the screen - press it
to maximise the map
view.
INTRODUCTION
}}
7
Step Screen/
menu
Action
4 A map is
shown.
Scroll to the desired
location on the map and
give a long press on the
position.
5 A field with
the text
Start navi-
gation is
shown on
the screen.
Press Start naviga-
tion.
6 A map with
highlighted
route is
shown.
Guidance starts - follow
the instructions on the
driver display.
Displays and operating controls for
map navigation
Volvo Sensus Navigation is presented and oper-
ated in several different ways, e.g. via the driver
display, Head-up display and voice commands.
The centre display screen
The centre display screen is used to define set-
tings and to select and search for destinations.
If the map image is not shown on the centre dis-
play:
•Press the home view's uppermost menu row
Navigation.
The driver display
The map is only shown in the 12" driver display.
During driving the driver is guided by voice guid-
ance and instructions on the driver display.
The right-hand steering wheel keypad
and the driver display
The right-hand steering wheel buttons can be
used to manage some of the map navigation
functions, e.g. Take me home.
||
INTRODUCTION
* Option/accessory, for more information, see Introduction.
8
Open/close
Left/Right
Up/Down
Confirm
Opening/closing the menu
–Press open/close (1)
> The menu with alternatives is opened/
closed - the menu closes automatically
after a period of inactivity or for certain
selections.
Navigating and selecting in the menu
1. Browse among the menus with Right/Left
(2).
2. Browse among the options with Up/Down
(3).
3. Confirm or highlight an option with (4).
> The function is activated and for some
selections the menu is closed.
HUD – Head-up-display*
Map navigation on the windscreen.
The driver can also receive guidance and infor-
mation from the navigation system display at the
bottom of the windscreen.
The position of the information field can be
adjusted. The HUD is comprehensively described
in the "Head-up-display" section.
Voice recognition
Many functions can also be performed with voice
commands.
Press the steering wheel but-
ton, wait for the signal, then
say, for example, “Drive Home”.
Voice recognition is comprehensively described
in the sections "Voice recognition", "Using voice
recognition", "Voice recognition and map naviga-
tion" and "Settings for voice recognition".
Related information
•Specify destination with free text searching
(p. 21)
•Voice recognition and map navigation
(p. 15)
•Voice recognition (p. 14)
•Using voice recognition (p. 14)
•Settings for voice recognition (p. 16)
