Vornado FIT Manuale utente
vornado.com
COMPACT AIR CIRCULATOR
OWNER’S GUIDE
model FIT
2English
vornado.com
800-234-0604
We expect this
product to be
perfect.
If it is not, we
will make it
right.
English 3
Important Safety Instructions ....................................................................................... 4
Controls......................................................................................................................... 9
Cleaning ...................................................................................................................... 10
Troubleshooting ......................................................................................................... 11
Warranty...................................................................................................................... 12
CONTENTS
4English
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
This owner’s guide and any additional inserts are considered part of the
product. They contain important information about safety, use and disposal.
Before using the product, please familiarize yourself with all operating and
safety instructions. Please keep all documents for future reference and pass
these documents on, together with the product, to any future owner. See
www.vornado.com/circulators-manuals to view, download and print the most
current version of these instructions.
INTENDED USE: This product is intended to circulate the air in indoor living
spaces only in the United States. This product is not intended for commercial
or industrial use. The manufacturer assumes no responsibility for damage
or injury due to unauthorized use or product modication. Failure to follow
these directions will void the product warranty.
WARNING: Risk to Children and Impaired Persons
Supervision is required during the installation, operation, cleaning and
maintenance of this product by children 12 years of age and younger and
anyone with reduced physical, sensory or mental capabilities. Children
should be supervised to ensure that they do not play with the appliance, its
parts and packaging material.
INSTALLATION WARNING—To reduce risk of re, electrical shock and
injury to persons, observe the following:
- Place this product away from curtains, draperies, tablecloths and other
English 5
fabrics, since they may be drawn into the product, damage the motor and/
or cause a re.
- No part of this product (the appliance, power cord, plug, packaging,
etc.) should be placed near furnaces, replaces, stoves or other high
temperature heat sources. Do not use this product in a window, on an
uneven or unstable surface, or near water.
- The appliance, power supply, power cord and plug cannot come into
contact with water. Do not use this product on wet surfaces. Do not use this
product in a bathtub or shower or position product where it may fall into a
bathtub, laundry, swimming pool or other water container. Do not use this
product outdoors or expose it to weather or elements.
- Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from trafc area and where it will not be
tripped over. The cord should not hang over edges of counters or be
placed where it can be crimped or closed in doors. Place appliance near an
easily accessible outlet so the product can be unplugged quickly during an
emergency.
SAFE USE WARNING—To reduce risk of re, electrical shock and injury
to persons, observe the following:
- WARNING: To reduce likelihood of circuit overload, re and electric shock,
do not operate with a solid state speed device, such as a dimmer control
switch.
- Do not operate any fan with a damaged cord or plug. Discard fan or return
to an authorized service facility for examination and/or repair.
- Do not operate unit if the unit has been dropped or damaged. Do not
6English
use this product if it has a damaged power cord or plug. To avoid risk of
electrical shock, do not attempt to repair or replace parts. Only original
replacement parts may be used. If the power cord is damaged, it must be
replaced by the manufacturer, its service agent, or similarly qualied persons
in order to avoid a hazard. Contact Vornado Consumer Service at 1-800-
instructions about replacement and repair.
- Before plugging power cord into electrical outlet, be sure that all electrical
information on the rating label, including voltage, is compatible with your
outlet’s power supply.
- Do not sit or stand on product.
- Never use the cord as a handle or otherwise yank, strain or stretch the
power cord.
- While the product is plugged in, do not insert or allow foreign objects to
enter any input or output opening as this may cause risk of electric shock or
re, or damage the product.
- A loose t between wall outlet (receptacle) and plug may cause overheating
and distortion of the plug. Discontinue use of the product in this outlet.
Contact a qualied electrician to replace loose or worn outlets.
- This appliance has a polarized plug (one blade is wider than the other.) To
reduce the risk of electric shock, this plug is intended to t in a polarized
outlet only one way. If the plug does not t fully in the outlet, reverse the
plug. If it still does not t, contact a qualied electrician. Do not attempt to
defeat this safety feature.
- Before moving, repositioning, servicing, cleaning and when not in use, use
the product controls to turn off the power and then unplug. To disconnect
from outlet, grasp and pull only the plug. Also, power off and unplug if the
English 7
product will be left unattended for an extended period of time or during
electrical storms.
SERVICING WARNING—To reduce risk of re, electrical shock and injury
to persons, observe the following:
- Clean your product regularly, only as is instructed in this manual. Prior
to cleaning, turn off the power on your product and unplug. Do not use
gasoline, thinners, solvents, ammonias or other chemicals for cleaning.
Refer to the CLEANING instructions provided.
- Do not open appliance housing while product is plugged in. To avoid risk
of shock, all service and/or repairs must be done by a Vornado Authorized
Service Center.
- This product employs overload protection (fuse). A blown fuse indicates
an overload or short-circuit situation. If the fuse blows, unplug the product
from the outlet. Replace the fuse as per the user servicing instructions
(follow product marking for proper fuse rating) and check the product.
If the replacement fuse blows, a short-circuit may be present and the
product should be discarded or returned to an authorized service facility for
examination and/or repair.
User Servicing Instructions
1. Using the product controls, turn off the appliance.
2. Grasp the plug (not the cord) and disconnect from the outlet.
3. Risk of Fire. Replace fuse only with 2.5 Amp, 125 Volt fuse as approved
by Vornado Consumer Service. For an authorized replacement fuse,
please contact Vornado Consumer Service.
8English
4. Once the replacement is received, use a small at-head screwdriver to
slide open the fuse cover (located on the plug) (See Fig. A).
5. Remove fuse by using the screwdriver to gently lift each end of the
fuse (See Fig. B).
6. Install the replacement fuse by using the screwdriver to gently push
each metal end of the fuse into the receptacle one at a time. Do not
push on the center of the fuse—it is fragile and may break.
7. Slide the fuse cover closed using the screwdriver. When closed, the
cover should t completely in the plug. No part of the cover should
stick out (See Fig. C).
8. Plug your appliance into the outlet and turn the power on.
9. If the replacement fuse blows, a short-circuit may be present and the
product should be discarded or returned to an authorized service
facility for examination and/or repair.
- Risk of re. Do not replace attachment plug. Contains a safety device (fuse,
AFCI, LCDI) that should not be removed. Discard product if the attachment
plug is damaged.
SAVE THESE INSTRUCTIONS
Fig. A Fig. B Fig. C
English 9
Your FIT™ personal air circulator is completely assembled and ready for immediate
use. Simply plug in your FIT and enjoy its cooling effect. The FIT personal air circulator
features Vornado’s signature Vortex Technology, allowing for you to direct the beam
towards you for a nice, gentle breeze or away from you to create swirling currents of air,
rejuvenating and cooling your personal space.
CONTROLS
DIRECT AIRFLOW
Direct the airow
where you want it.
POWER ON/OFF
Select High (II) or
Low (I) fan speed or
power off (O).
10 English
To Clean Grille:
Unplug unit. Remove screw and rotate the grille
counterclockwise to unlock and then lift off. To reinstall
the grille, position the grille with the logo rotated
slightly to the left and rotate clockwise. Dust or wash
with a mild dish washing soap. Do not place grille in the
dishwasher. The excessive heat can distort the plastic.
To Clean Blade:
Pull the blade straight out from the shaft. Wipe with a
damp cloth. To reattach - be certain the at side of the
shaft aligns directly with the corresponding at side on
the blade’s socket. Push the blade all the way on the
shaft until it bottoms out. If your Air Circulator is used in
a greasy environment, such as a kitchen, mild soap or a
common household cleaner may be necessary. Do not
use solvents.
To Clean Base:
Wipe with a damp cloth.
To Clean Motor Cap and Inlet Ribs:
Use a common household vacuum. Do not use water to
clean these parts of the Air Circulator.
Because your FIT moves air it will require regular cleaning.
CLEANING
GRILLE & BLADE REMOVAL Screwdriver required.
WARNING: To reduce the risk of electrical shock and injury to persons, unplug the circulator
before removing grille and blade.
